- Page 1 KVM105, KVM110, KVM115 KVM105, KVM110, KVM115 INSTALLER AND USER’S MANUAL v5.1 REV. 07/2021...
- Page 2 01. SAFETY INSTRUCTIONS This product is certified in accordance with European Community (EC) safety standards. 02. AUTOMATISM KVM105, KVM110 AND KVM115 This product complies with Directive 2011/65/EU of the TECHNICAL CHARACTERISTICS European Parliament and of the Council, of 8 June 2011, on...
- Page 3 01. SAFETY INSTRUCTIONS GENERAL WARNINGS the motorized door or gate from being triggered involuntarily. • This manual contains very important safety and usage information. WARNINGS FOR TECHNICIANS very important. Read all instructions carefully before beginning the installation/usage procedures and keep this manual in a safe place •...
- Page 4 01. SAFETY INSTRUCTIONS RESPONSABILITY • Attach the permanent label for the manual release as close as possible to the release mechanism. • Supplier disclaims any liability if: • Disconnect means, such as a switch or circuit breaker on the electrical •...
- Page 5 02. AUTOMATISM KVM105, KVM110 AND KVM115 PACKAGE KVM105, KVM110 and KVM115 are spindle drive automatims for sectional industrial door automation, In the kit you will find the following components: with the possibility of horizontal or vertical application. The ease of installation, configuration and maintenance make it ideal for all sectional doors.
- Page 6 02. AUTOMATISM MOTOR AND CONTROL PANEL DIMENSIONS a’ b’ KVM105 KVM110 KVM115 400x236x110 450x300x200 450x240x110 • Motor Dimensions (a x b x c) • Reducer Width (c') • Total Motor Height (a) • Control Panel Dimensions 170x200x100 • Motor Depth (b) •...
- Page 7 03. INSTALLATION AUTOMATISM INSTALLATION • The gearmotor must be installed in a protected area of shocks. • The fixation surface should be solid. • Should be used accessories with capacity to fixing the engine to surface. • Install suitable tubes for the passage of electrical cables, to ensure the complete protection against mechanical damage.
- Page 8 03. INSTALLATION 03. INSTALLATION ADJUSTMENT OF LIMIT SWITCHES FIX CONTROL PANEL ON THE WALL Screw A correspondes to general tuning and B is the fine tuning screw. Do not only use fine tuning if you want make a full adjustment, this may damage the tuning rings.
- Page 9 04. INSTALLATION MAP INSTALLATION GUIDE You can install the engine horizontally or vertically, the procedure is the same. See detail A. KVM105 / KVM110 / KVM115 Motor DETAIL A Control Panel with control board 1500mm...
