Raynor Airman II 8155RGD Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

CONTRACTOR Series
1/2 hp Belt Drive
Garage Door Opener
Model 8155RGD
FOR RESIDENTIAL USE ONLY
■ Please read this manual and the enclosed safety materials carefully!
■ Fasten the manual near the garage door after installation.
■ The door WILL NOT CLOSE unless the Protector System
aligned.
■ Periodic checks of the garage door opener are required to ensure safe operation.
■ The model number label is located on the front panel of your garage door opener.
■ This garage door opener is ONLY compatible with MyQ
accessories.
■ ONLY enable the Timer-to-Close or MyQ
garage door opener is installed on a sectional door.
NOTE: If you are installing the garage door opener on a one-piece door, visit
www.raynor.com for installation instructions.
. .
is connected and properly
®
and Security+ 2.0™
®
remote operation feature when the
®
Write down the following information for
future reference:
Serial Number:
Date of Purchase:
CONTENTS
Preparation . . . . . . . . . . . . . . . .1-2
Assembly . . . . . . . . . . . . . . . . .3-4
Installation . . . . . . . . . . . . . . . 5-12
Install the Door Control . . . . . . 13-14
®
. . 15-18
Power. . . . . . . . . . . . . . . . . . 19-20
Adjustments . . . . . . . . . . . . . 21-23
Operation . . . . . . . . . . . . . . . 24-29
Maintenance . . . . . . . . . . . . . . . 30
Troubleshooting. . . . . . . . . . . 31-32
Accessories. . . . . . . . . . . . . . . . 33
Warranty. . . . . . . . . . . . . . . . . . 34
Repair Parts . . . . . . . . . . . . . 35-36
Notes . . . . . . . . . . . . . . . . . . 37-38
www.raynor.com
Raynor Garage Doors
1101 E. River Rd.
Dixon, Illinois 61021

Advertisement

Table of Contents
loading

Related Manuals for Raynor Airman II 8155RGD

Summary of Contents for Raynor Airman II 8155RGD

  • Page 1: Table Of Contents

    ® garage door opener is installed on a sectional door. NOTE: If you are installing the garage door opener on a one-piece door, visit www.raynor.com for installation instructions. Write down the following information for future reference: Serial Number: www.raynor.com...

  • Page 2: Preparation

    Preparation Check the Door Tools Needed 1. Disable locks and remove any ropes connected to the garage door. 2. Lift the door halfway up. Release the Safety Symbol and Signal Word door. If balanced, it should stay in place, Review supported entirely by its springs.
  • Page 3 Preparation Installation Hardware Carton Inventory Hex bolt 5/16"-18 x 7/8" (4) Lock washer 5/16" (4) Accessories will vary depending on the garage door opener model purchased. Depending on your Lag screw 5/16"-9 x 1-5/8" (2) Self-threading screw 1/4"-14 x 5/8" (2) specific model, other accessories may be included with your garage door opener.

  • Page 4: Assembly

    Assembly 1 Attach the Rail to the Garage Door Opener Hex Screws 8x3/8" Washered Bolts 5/16"-18x1/2" Sprocket (Mounted in Cover the garage door opener) To avoid possible SERIOUS INJURY to finger from moving garage door opener: ALWAYS keep hand clear of sprocket while operating opener. Securely attach sprocket cover BEFORE operating.
  • Page 5 Assembly 2 Tighten the Belt (To motor unit) Spring Trolley Nut 1. By hand, thread the spring trolley nut on the threaded shaft until it is finger tight against the trolley. Do not use any tools. 2. Insert a flathead screwdriver tip into one of the nut ring slots and brace it firmly against the trolley.

  • Page 6: Installation

    8. NEVER wear watches, rings or loose clothing while installing or servicing opener. They could garage doors. To be enabled ONLY when operating a sectional door. be caught in garage door or opener mechanisms. NOTE: If you are installing the garage door opener on a one-piece door, visit www.raynor.com for installation instructions.
  • Page 7 To be enabled ONLY when operating a sectional door. (Optional) NOTE: If you are installing the garage door opener on a one-piece door, visit www.raynor.com for installation instructions. Close the door and mark the inside vertical centerline of the garage door.
  • Page 8 Installation OPTION B 2 Install the Header Bracket CEILING INSTALLATION 1. Extend the vertical centerline onto the ceiling as shown. You can attach the header bracket either to the wall above the garage door, or to the ceiling. Follow the 2.
  • Page 9 Installation 4 Position the Garage Door Opener 3 Attach the Rail to the Header Bracket 1. Align the rail with the header bracket. Insert the clevis pin through the holes in the header bracket and rail. Secure with the ring fastener. NOTE: Use the packing material as a protective base for the garage door opener.
  • Page 10 Installation 5 Hang the Garage Door Opener HARDWARE To avoid possible SERIOUS INJURY from a falling garage door opener, fasten it SECURELY to Lock Washer 5/16" Hex Bolt 5/16"- 18x7/8" Nut 5/16"-18 structural supports of the garage. Concrete anchors MUST be used if installing ANY brackets into masonry.
  • Page 11 Installation 6 Install the Light Bulbs 7 Attach the Emergency Release Rope and Handle To prevent possible SERIOUS INJURY or DEATH from a falling garage door: To prevent possible OVERHEATING of the endpanel or light socket: If possible, use emergency release handle to disengage trolley ONLY when garage door is DO NOT use short neck or specialty light bulbs.
  • Page 12 Installation 8 Install the Door Bracket Wood Doors: Use top and bottom or side to side door bracket holes. Drill 5/16” holes through the door and secure bracket with 5/16"-18x2" carriage bolts, lock washers and nuts (not provided). (Figure 4) NOTE: The 1/4"-14x5/8" self-threading screws are not intended for use on wood doors. HARDWARE Fiberglass, aluminum or lightweight steel garage doors WILL REQUIRE reinforcement BEFORE installation of door bracket.
  • Page 13 Installation HARDWARE 9 Connect the Door Arm to the Trolley IMPORTANT: The groove on the straight door arm MUST face away from the curved door arm. 1. Close the door. Disconnect the trolley by pulling the emergency release handle. Slide the outer trolley back (away from the door) about 2"...

  • Page 14: Install The Door Control

    2 Smart Control Panels or 4 of any other Security+ 2.0™ door controls. NOTE: Older Raynor door controls and third party products are not compatible. Install the door control within sight of the door at a minimum height of 5 feet (1.5 m) where small children Drywall Anchor 6-32x1"...
  • Page 15 Install the Door Control 2 Wire the door control to the garage door opener 3 Attach the warning labels 1. Attach the entrapment warning label on the wall near the door control with tacks or staples. HARDWARE 2. Attach the manual release/safety reverse test label in a visible location on the inside of the garage door.

  • Page 16: Install The Protector System

    ® Install the Protector System Introduction When installing the safety reversing sensors check the following: Sensors are installed inside the garage, one on either side of the door. Sensors are facing each other with the lenses aligned and the receiving sensor lens does not receive direct sunlight.
  • Page 17 ® Install the Protector System OPTION B 1 Install the Safety Reversing Sensors WALL INSTALLATION If additional clearance is needed an extension bracket (not provided) or wood blocks can be used. Make HARDWARE sure each bracket has the same amount of clearance so they will align correctly. 1.
  • Page 18 ® Install the Protector System OPTION C 2 Wire the Safety Reversing Sensors FLOOR INSTALLATION Use an extension bracket (not provided) or wood block to raise the sensor bracket if needed. PRE-WIRED INSTALLATIONS: If your garage already has wires installed for the safety reversing 1.
  • Page 19 ® Install the Protector System OPTION B PRE-WIRED INSTALLATION Pre-installed 1. Cut the end of the safety reversing sensor wire, making sure there is enough wire to reach the Safety reversing wires 7/16" sensor wires pre-installed wires from the wall. (11 mm) 2.

  • Page 20: Power

    Power 1 Connect Power THERE ARE TWO OPTIONS FOR CONNECTING POWER: OPTION A TYPICAL WIRING 1. Plug in the garage door opener into a grounded outlet. 2. DO NOT run garage door opener at this time. TYPICAL WIRING To prevent possible SERIOUS INJURY or DEATH from electrocution or fire: Be sure power is NOT connected to the opener, and disconnect power to circuit BEFORE removing cover to establish permanent wiring connection.
  • Page 21 Power 2 Ensure the Safety Reversing Sensors are Aligned IF THE AMBER LED ON THE SENDING SENSOR IS NOT GLOWING: 1. Make sure there is power to the garage door opener. The door will not close if the sensors have not been installed and aligned correctly. 2.

  • Page 22: Adjustments

    Adjustments PROGRAMMING BUTTONS Introduction The programming buttons are located on the left side panel of the garage door opener and are used to program the travel. PROGRAMMING BUTTONS Without a properly installed safety reversal system, persons (particularly small children) could be UP Button SERIOUSLY INJURED or KILLED by a closing garage door.
  • Page 23 Adjustments PROGRAMMING BUTTONS 1 Program the Travel UP Button Adjustment Button Without a properly installed safety reversal system, persons (particularly small children) could be SERIOUSLY INJURED or KILLED by a closing garage door. DOWN Button Incorrect adjustment of garage door travel limits will interfere with proper operation of safety reversal system.
  • Page 24 Adjustments ® 2 Test the Safety Reversal System 3 Test the Protector System Without a properly installed safety reversal system, persons (particularly small children) could be Without a properly installed safety reversing sensor, persons (particularly small children) could be SERIOUSLY INJURED or KILLED by a closing garage door. SERIOUSLY INJURED or KILLED by a closing garage door.

  • Page 25: Operation

    Operation IMPORTANT SAFETY INSTRUCTIONS WARNING To reduce the risk of SEVERE INJURY or DEATH: 1. READ AND FOLLOW ALL WARNINGS AND INSTRUCTIONS. 10. Safety reversal system MUST be tested every month. Garage door MUST reverse on 2. ALWAYS keep remote controls out of reach of children. NEVER permit children to operate or contact with 1-1/2"...
  • Page 26 If the door senses an obstruction or is interrupted while opening the door will stop. When NOTE: Older Raynor remote controls, door controls, and third party products are not compatible. the door is in any position other than closed and the garage door opener is activated the door will close.
  • Page 27 Operation Using the Door Control The following features are accessible by lifting up the push bar: LEARN A DEVICE ® Any compatible remote controls, wireless keyless entry, or MyQ accessories can be programmed to the SYNCHRONIZE THE DOOR CONTROL garage door opener by pressing the LEARN button on the door control, see page 28. To synchronize the door control to the garage door opener, press the push bar until the garage door opener activates (it may take up to 3 presses).
  • Page 28 Operation Control Panel Setup LIGHT FEATURE (Default is Active) Deactivate: LOCK Press and hold the LIGHT button until the garage Command LED NOTE: Your remote controls will NOT work when door opener lights turn on, then off again.* Command LED LOCK mode is active however your keyless entry Activate: will still allow access to your garage.
  • Page 29 Your remote control has been programmed at the factory to operate with your garage door opener. 2. Press and immediately release the Learn button. The Learn LED will glow steady for 30 Older Raynor remote controls are NOT compatible, see page 33 for compatible accessories. seconds. Within 30 seconds...
  • Page 30 Operation To Open the Door Manually To prevent possible SERIOUS INJURY or DEATH from a falling garage door: If possible, use emergency release handle to disengage trolley ONLY when garage door is CLOSED. Weak or broken springs or unbalanced door could result in an open door falling rapidly and/or unexpectedly.

  • Page 31: Maintenance

    Maintenance Maintenance Schedule The Remote Control Battery EVERY MONTH Manually operate door. If it is unbalanced or binding, call a trained door systems technician. Check to be sure door opens and closes fully. Adjust if necessary, see page 22. To prevent possible SERIOUS INJURY or DEATH: Test the safety reversal system.

  • Page 32: Troubleshooting

    Troubleshooting Diagnostic Chart Your garage door opener is programmed with self-diagnostic capabilities. The UP and DOWN arrows on the garage door opener flash the diagnostic codes. DIAGNOSTIC CODE SYMPTOM SOLUTION Up Arrow Down Arrow Flash(es) Flash(es) The garage door opener will not close and the light Safety sensors are not installed, connected or wires may be cut.
  • Page 33 Troubleshooting DIAGNOSTIC CODE SYMPTOM SOLUTION Up Arrow Flash Down Arrow (es) Flash(es) Door is moving stops and or reverses. Manually open and close the door. Check for binding or obstructions, such as a broken spring or door lock, correct as needed. If the door is binding or sticking contact a trained door systems technician.

  • Page 34: Accessories

    Monitor open/closed status for MAX Remote Control: Displays temperature, time and Internet enabled accessory up to 4 MyQ ® compatible garage Compatible with Raynor ® garage system diagnostics; includes which connects to the computer door openers or gate operators door openers manufactured...

  • Page 35: Warranty

    Warranty RAYNOR ONE-YEAR LIMITED WARRANTY 10 YEAR BELT LIMITED WARRANTY & LIFETIME MOTOR LIMITED WARRANTY RAYNOR (“Seller”) warrants to the first retail purchaser of this product, for the residence in which this product is originally installed, that it is free from defect in materials and/or workmanship for a period ®...

  • Page 36: Repair Parts

    Repair Parts Rail Assembly Parts Installation Parts Description Part Number Description Part Number Master link kit 4A1008 Multi-function door control panel 041A7185-2 Belt pulley bracket 41B5424 1 Button remote control 891RGD Complete trolley assembly 41B3869-1 3V CR2032 Lithium battery 10A20 One-piece rail - 7’...
  • Page 37 Logic Board 045ACT Logic Board End Panel 041D0239 Contact Information Address repair parts order to: For installation and service information Raynor Garage Doors call: 1101 E. River Rd. 1-800-472-9667 Dixon, Illinois 61021 Or visit us online at: www.raynor.com Before calling, please have the model number of the garage door opener. If you are calling about a Troubleshooting issue, it is recommended that you have access to your garage door opener while calling.

  • Page 38: Notes

    Notes...
  • Page 39 Notes...
  • Page 40 © 2015, The Chamberlain Group, Inc. 114A4726B All Rights Reserved...
