Sergeant

STANDARD Series

DC Chain Drive

Wi-Fi

Garage Door

Opener

Model 8160WRGD

FOR RESIDENTIAL USE ONLY

■ Please read this manual and the enclosed safety materials carefully!

■ Fasten the manual near the garage door after installation.

■ The door WILL NOT CLOSE unless the Protector System

aligned.

■ Periodic checks of the garage door opener are required to ensure safe operation.

■ The model number label is located on the front panel of your garage door opener.

■ This garage door opener is ONLY compatible with MyQ

■ ONLY enable the Timer-to-Close or MyQ

garage door opener is installed on a sectional door.

NOTE: If you are installing the garage door opener on a one-piece door, visit

www.raynor.com for installation instructions.

SERIAL NUMBER:

Please write the MyQ Serial number in the box above. See page 2.

is connected and properly

Security+ 2.0

accessories.

remote operation feature when the

CONTENTS

Preparation . . . . . . . . . . . . . . . .2-5

Assembly . . . . . . . . . . . . . . . . . . 6

Installation . . . . . . . . . . . . . . . 7-14

Install the Door Control . . . . . . 15-16

Install the Protector System

. . 17-20

Power. . . . . . . . . . . . . . . . . . 21-22

Adjustments . . . . . . . . . . . . . 23-25

Operation . . . . . . . . . . . . . . . 26-32

Maintenance . . . . . . . . . . . . . 33-34

Troubleshooting. . . . . . . . . . . 35-36

Accessories. . . . . . . . . . . . . . . . 37

Warranty. . . . . . . . . . . . . . . . . . 38

Automatic Garage Door Opener

Safety & Maintenance Guide . . 39-40

Repair Parts . . . . . . . . . . . . . 41-42

www.raynor.com

Raynor Garage Doors

1101 E. River Rd.

Dixon, Illinois 61021

Table of Contents

Summary of Contents for Raynor Sergeant II Standard 8160WRGD

Page 1: Table Of Contents
NOTE: If you are installing the garage door opener on a one-piece door, visit www.raynor.com for installation instructions. SERIAL NUMBER: Please write the MyQ Serial number in the box above. See page 2.
Page 2: Preparation
Preparation Safety Symbol and Signal Word Review This garage door opener has been designed and tested to offer safe service provided it is installed, Serial Number operated, maintained and tested in strict accordance with the instructions and warnings contained in this manual.
Page 3 Preparation Before You Connect with Your Smartphone Check the Door ® Monitor and control your garage door from anywhere using the MyQ app. You will need: Wi-Fi enabled smartphone, tablet or laptop Broadband Internet Connection To prevent possible SERIOUS INJURY or DEATH: Wi-Fi signal in the garage (2.4 Ghz, 802.11b/g/n required) ALWAYS call a trained door systems technician if garage door binds, sticks, or is out of Password for your home network (router's main account, not guest network)
Page 4 Preparation Tools Needed 5/32 3/16 7/16 5/16 7/16 9/16...
Page 5 Preparation Carton Inventory - Model 8160W Hardware Accessories will vary depending on the garage door opener model purchased. Depending on your Installation Door Control Hardware specific model, other accessories may be included with your garage door opener. The instructions for Hex bolt 5/16"-18 x 7/8"...
Page 6: Assembly
Assembly 1 Attach the Rail to the Garage Door Opener 2 Tighten the Chain 1. Loosen the inner nut and lock washer on the trolley threaded shaft. 2. Tighten the outer nut until the chain is a 1/2 inch above the base of the rail at the midpoint of the rail.
Page 7: Installation
8. NEVER wear watches, rings or loose clothing while installing or servicing opener. They could be Unattended devices and features are to be used ONLY with sectional doors. caught in garage door or opener mechanisms. NOTE: If you are installing the garage door opener on a one-piece door, visit www.raynor.com for installation instructions.
Page 8 Installation 1 Determine the Header Bracket Location OPTIONAL Unﬁnished CEILING Ceiling MOUNT FOR HEADER Header Wall BRACKET To prevent possible SERIOUS INJURY or DEATH: Header bracket MUST be RIGIDLY fastened to structural support on header wall or ceiling, Vertical Centerline otherwise garage door might NOT reverse when required.
Page 9 Installation 2 Install the Header Bracket OPTION B - CEILING INSTALLATION 1. Extend the vertical centerline onto the ceiling as shown. You can attach the header bracket either to the wall above the garage door, or to the ceiling. Follow the 2.
Page 10 Installation 3 Attach the Rail to the Header Bracket 4 Position the Garage Door Opener 1. Align the rail with the header bracket. Insert the clevis pin through the holes in the header bracket and rail. Secure with the ring fastener. NOTE: Use the packing material as a protective base for the garage door opener.
Page 11 Installation 5 Hang the Garage Door Opener HARDWARE To avoid possible SERIOUS INJURY from a falling garage door opener, fasten it SECURELY to Lock Washer 5/16" Hex Bolt 5/16"- 18x7/8" Nut 5/16"-18 structural supports of the garage. Concrete anchors MUST be used if installing ANY brackets into masonry.
Page 12 Installation 6 Install the Light Bulbs 7 Attach the Emergency Release Rope and Handle To prevent possible OVERHEATING of the end panel or light socket: To prevent possible SERIOUS INJURY or DEATH from a falling garage door: Use ONLY A19 incandescent (100W maximum) or compact fluorescent (26W maximum) light If possible, use emergency release handle to disengage trolley ONLY when garage door is bulbs.
Page 13 Installation 8 Install the Door Bracket Metal, insulated or light weight factory reinforced doors: Drill 3/16" fastening holes. Secure the door bracket using the self-threading screws. (Figure 3) Wood Doors: Use top and bottom or side to side door bracket holes. Drill 5/16” holes through the door and secure bracket with 5/16"-18 x 2"...
Page 14 Installation 9 Connect the Door Arm to the Trolley HARDWARE IMPORTANT: The groove on the straight door arm MUST face away from the curved door arm. 1. Close the door. Disconnect the trolley by pulling the emergency release handle. Slide the outer trolley back (away from the door) about 2"...
Page 15: Install The Door Control
2 Smart Control Panels or 4 of any other Security+ 2.0 door controls. Drywall Anchor NOTE: Older Raynor door controls and third party products are not compatible. 6-32 x 1" Install door control within sight of garage door, out of reach of small children at a minimum height of 6AB x 1"...
Page 16 Door Control 2 Wire the door control to the garage door opener 3 Attach the warning labels PRE-WIRED INSTALLATIONS: When wiring the door control to the garage door opener make sure 1. Attach the entrapment warning label on the wall near the door control with tacks or staples. 2.
Page 17: Install The Protector System
Install the Protector System ® Introduction Be sure power is NOT connected to the garage door opener BEFORE installing the safety reversing sensor. To prevent SERIOUS INJURY or DEATH from closing garage door: Correctly connect and align the safety reversing sensor. This required safety device MUST NOT be disabled.
Page 18 Install the Protector System ® 1 Install the Safety Reversing Sensors OPTION B - WALL INSTALLATION If additional clearance is needed an extension bracket (not provided) or wood blocks can be used. HARDWARE Make sure each bracket has the same amount of clearance so they will align correctly. Carriage Bolt 1.
Page 19 Install the Protector System ® 2 Wire the Safety Reversing Sensors OPTION C - FLOOR INSTALLATION Use an extension bracket (not provided) or wood block to raise the sensor bracket if needed. PRE-WIRED INSTALLATIONS: If your garage already has wires installed for the safety reversing 1.
Page 20 Install the Protector System ® OPTION B - PRE-WIRED INSTALLATION Pre-installed 1. Cut the end of the safety reversing sensor wire, making sure there is enough wire to reach the Safety reversing wires 7/16" sensor wires pre-installed wires from the wall. (11 mm) 2.
Page 21: Power
Power 1 Connect Power THERE ARE TWO OPTIONS FOR CONNECTING POWER: OPTION A - TYPICAL WIRING 1. Plug in the garage door opener into a grounded outlet. 2. DO NOT run garage door opener at this time. TYPICAL WIRING To prevent possible SERIOUS INJURY or DEATH from electrocution or fire: Be sure power is NOT connected to the opener, and disconnect power to circuit BEFORE removing cover to establish permanent wiring connection.
Page 22 Power 2 Ensure the Safety Reversing Sensors are Aligned IF THE AMBER LED ON THE SENDING SENSOR IS NOT GLOWING: 1. Make sure there is power to the garage door opener. The door will not close if the sensors have not been installed and aligned correctly. 2.
Page 23: Adjustments
Adjustments Introduction PROGRAMMING BUTTONS The programming buttons are located on the left side panel of the garage door opener and are used to program the travel. While programming, the UP and DOWN buttons can be used to move the door as needed.
Page 24 Adjustments 1 Program the Travel PROGRAMMING BUTTONS UP Button Adjustment Without a properly installed safety reversal system, persons (particularly small children) could be Button SERIOUSLY INJURED or KILLED by a closing garage door. Incorrect adjustment of garage door travel limits will interfere with proper operation of safety DOWN Button reversal system.
Page 25 Adjustments ® 2 Test the Safety Reversal System 3 Test the Protector System Without a properly installed safety reversal system, persons (particularly small children) could be Without a properly installed safety reversing sensor, persons (particularly small children) could be SERIOUSLY INJURED or KILLED by a closing garage door. SERIOUSLY INJURED or KILLED by a closing garage door.
Page 26: Operation
Operation IMPORTANT SAFETY INSTRUCTIONS To reduce the risk of SEVERE INJURY or DEATH: 1. READ AND FOLLOW ALL WARNINGS AND INSTRUCTIONS. 10. Safety reversal system MUST be tested every month. Garage door MUST reverse on contact with 2. ALWAYS keep remote controls out of reach of children. NEVER permit children to operate or 1-1/2"...
Page 27 37. automatically after 4-1/2 minutes. Use an incandescent A19 light bulb (100 watt maximum). NOTE: Older Raynor remote controls, door controls, and third party products are not compatible. Light Feature The garage door opener is equipped with an added feature; the lights will turn on when someone ®...
Page 28 Operation Connect With Your Smartphone ® Learn The Wi-Fi Garage Door Opener is compatible with up to 16 MyQ enabled accessories. Up to 10 Button devices can be paired to the Wi-Fi garage door opener’s internal gateway. These devices can be controlled with the MyQ app.
Page 29 Operation Using the Door Control The following features are accessible by lifting up the push bar: LEARN A DEVICE SYNCHRONIZE THE DOOR CONTROL ® Any compatible remote controls, wireless keyless entry, Wi-Fi garage door openers, or MyQ To synchronize the door control to the garage door opener, press the push bar until the garage door accessories can be programmed to the garage door opener by pressing the LEARN button on the door opener activates (it may take up to 3 presses).
Page 30 Operation Control Panel Setup LIGHT FEATURE (Default is Active) LOCK Deactivate: Press and hold the LIGHT button until the garage Your remote controls will NOT work when LOCK Command LED Command LED door opener lights turn on, then off again.* mode is active however your keyless entry will still Activate: allow access to your garage.
Page 31 1. Press and release the LEARN Button on the garage door opener. Older Raynor remote controls are NOT compatible, see page 37 for compatible accessories. 2. Press and hold the button on the remote control that you wish to use. Release the button when Programming can be done through the door control or the learn button the garage door opener.
Page 32 Operation To Erase the Memory To Open the Door Manually ERASE ALL REMOTE CONTROLS AND KEYLESS ENTRIES 1. Press and hold the LEARN button on garage door opener until the learn LED goes out (approximately 6 seconds). All remote control and keyless entry codes are now erased. To prevent possible SERIOUS INJURY or DEATH from a falling garage door: Reprogram any accessory you wish to use.
Page 33: Maintenance
Maintenance Maintenance Schedule NOTICE: Thisdevice complieswith Part 15 of the FCC rulesand IndustryCanada’slicense-exempt RSSs. Operation issubject to the following two conditions: (1) thisdevice maynot cause harmfulinterference, and (2) thisdevice must accept anyinterference received, EVERY MONTH including interference that maycause undesired operation. Manually operate door.
Page 34 Maintenance The Remote Control Battery To prevent possible SERIOUS INJURY or DEATH: NEVER allow small children near batteries. If battery is swallowed, immediately notify doctor. To reduce risk of fire, explosion or chemical burn: Replace ONLY with 3V CR2032 coin batteries. DO NOT recharge, disassemble, heat above 212°F (100°C) or incinerate.
Page 35: Troubleshooting
Troubleshooting Diagnostic Chart Your garage door opener is programmed with self-diagnostic capabilities. The UP and DOWN arrows on the garage door opener flash the diagnostic codes. DIAGNOSTIC CODE SYMPTOM SOLUTION Up Arrow Flash(es) Down Arrow Flash(es) The garage door opener will not close and the light Safety reversing sensors are not installed, connected, or wires may be cut.
Page 36 Troubleshooting DIAGNOSTIC CODE SYMPTOM SOLUTION Up Arrow Flash(es) Down Arrow Flash(es) Door is moving stops or reverses. Manually open and close the door. Check for binding or obstructions, such as a broken spring or door lock, correct as needed. If the door is binding or sticking contact a trained door systems technician. If door is not binding or sticking attempt to reprogram travel (refer to page 24).
Page 37: Accessories
Monitor open/closed status MAX Remote Control: Displays temperature, time lights using your garage door for up to 4 MyQ ® compatible Compatible with Raynor ® and system diagnostics; opener, a Security+ 2.0 ® garage door openers or gate garage door openers...
Page 38: Warranty
Warranty ® RAYNOR LIMITED WARRANTY ® Raynor (“Seller”) warrants to the first retail purchaser of this product, for the residence in which this product is originally installed, that it is free from defects in materials and/or workmanship for a specific period of time as defined below (the “Warranty Period”).
Page 39: Automatic Garage Door Opener Safety & Maintenance Guide
Automatic Garage Door Opener Safety & Maintenance Guide Garage Door Opener Safety – An Automatic Decision A garage door is the largest moving object in the home. An improperly adjusted garage door and opener can exert deadly force when the door closes – which could lead to entrapment of children or adults and subsequent injury or death.
Page 40 Routine Maintenance Can Prevent Tragedies Make monthly inspection and testing of your garage door and opener system a part of your regular routine. Review your owner’s manual for both the door and door opener. If you don’t have the owner’s manuals, contact the manufacturer(s) and request a copy for your speciﬁ c model(s). Look for the opener model number on the back of the power unit. WARNING –...
Page 41: Repair Parts
Repair Parts Rail Assembly Parts Installation Parts Description Part Number Description Part Number Master link kit 4A1008 3V CR2032 Lithium battery 10A20 Chain pulley bracket 41A4813 Remote control visor clip 29B137 Complete trolley assembly 41A3489 Emergency release rope and 41A2828 handle assembly One-piece rail - 7' (2.1 m) 1707LM...
Page 42 041D9069 Transformer 041A7635-1 Contact Information Address repair parts order to: For installation and service information call: Raynor Garage Doors 1-800-472-9667 1101 E. River Rd. Or visit us online at: Dixon, Illinois 61021 www.raynor.com Before calling, please have the model number of the garage door opener. If you are calling about a Troubleshooting issue, it is recommended that you have access to your garage door opener while calling.
