Raynor Ultra II 8587RGD User Manual

Premium series chain drive garage door opener

Advertisement

PREMIUM Series
Chain Drive Garage
Door Opener
Model 8587RGD - 3/4 hp
FOR RESIDENTIAL USE ONLY
■ Please read this manual and the enclosed safety materials carefully!
■ Fasten the manual near the garage door after installation.
■ The door WILL NOT CLOSE unless the Protector System
aligned.
■ Periodic checks of the garage door opener are required to ensure safe operation.
■ The model number label is located on the front panel of your garage door opener.
■ This garage door opener is ONLY compatible with MyQ
accessories.
■ ONLY enable the Timer-to-Close* or MyQ
the garage door opener is installed on a sectional door. (*Not available on all
models)
NOTE: If you are installing the garage door opener on a one-piece door, visit
www.raynor.com for installation instructions.
.
®
is connected and properly
®
and Security+ 2.0™
®
remote operation feature* when
Write down the following information for
future reference:
Serial Number:
Date of Purchase:
CONTENTS
Preparation . . . . . . . . . . . . . . . .2-3
Assembly . . . . . . . . . . . . . . . . .4-5
Installation . . . . . . . . . . . . . . . 6-13
Install the Door Control . . . . . . 14-16
®
. . 17-20
Power. . . . . . . . . . . . . . . . . . 21-22
Adjustments . . . . . . . . . . . . . 23-25
Operation . . . . . . . . . . . . . . . . . 26
Features . . . . . . . . . . . . . . . . . . 27
Door Control . . . . . . . . . . . . . 28-29
Remote Control . . . . . . . . . . . 30-31
To Erase the Memory . . . . . . . . . 31
Maintenance . . . . . . . . . . . . . . . 32
Troubleshooting. . . . . . . . . . . 33-34
Accessories. . . . . . . . . . . . . . . . 35
Warranty. . . . . . . . . . . . . . . . . . 36
Repair Parts . . . . . . . . . . . . . 37-38
Notes . . . . . . . . . . . . . . . . . . . . 39
Raynor Garage Doors
1101 E. River Rd.
Dixon, Illinois 61021
www.raynor.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Ultra II 8587RGD and is the answer not in the manual?

Questions and answers

Summary of Contents for Raynor Ultra II 8587RGD

  • Page 1: Table Of Contents

    (*Not available on all models) NOTE: If you are installing the garage door opener on a one-piece door, visit www.raynor.com for installation instructions. Write down the following information for future reference:...
  • Page 2: Preparation

    Preparation Safety Symbol and Signal Tools Needed Check the Door Word Review 1. Disable locks and remove any ropes This garage door opener has been designed and To prevent possible SERIOUS INJURY or connected to the garage door. tested to offer safe service provided it is installed, DEATH: 2.
  • Page 3: Preparation

    Preparation Overview/Carton Inventory ® AND SECURITY✚ 2.0 ACCESSORIES NOTE: Accessories will vary depending on the garage door opener model purchased. Depending on your specific model, other accessories 041A7305-3 893RGX Smart Control Remote may be included with your garage door opener. The instructions for these accessories will be attached to the accessory and are not included Panel ®...
  • Page 4: Assembly

    Assembly Attach the rail to the garage door opener NOTE: ONLY use the bolts removed from the Hex Screws 8-32x1" garage door opener. Place the garage door Washered Bolt opener on the packing material to prevent 5/16"-18x1/2" Washers scratching. To avoid SERIOUS damage to garage door Lock Remove bolt and lock nut from the top opener, use ONLY those bolts/fasteners...
  • Page 5: Screw #8-32X3/8

    Assembly 2 Attach the Chassis Support Bracket Hex Bolt Lock 1/4"-20x5/8" Washer Screw #8-32x3/8" To avoid possible SERIOUS INJURY to finger from moving garage door opener: Washerd Bolt • ALWAYS keep hand clear of sprocket while operating opener. 5/16"-18x1/2" • Securely attach sprocket cover BEFORE operating.
  • Page 6 8. NEVER wear watches, rings or loose clothing while installing or servicing opener. They could garage doors. To be enabled ONLY when operating a sectional door. be caught in garage door or opener mechanisms. NOTE: If you are installing the garage door opener on a one-piece door, visit www raynor.com for installation instructions.
  • Page 7: Determine The Header Bracket Location

    Installation Determine the header bracket location NOTE: If you are installing the garage door opener on a one-piece door, visit www.raynor.com for OPTIONAL Unfinished installation instructions. CEILING Ceiling Close the door and mark the inside vertical centerline of the garage door.
  • Page 8: Install The Header Bracket

    Installation 2 Install the Header Bracket You can attach the header bracket either to the OPTION A WALL INSTALLATION (Header Wall) wall above the garage door, or to the ceiling. Vertical 2.1A Centerline of Center the bracket on the vertical Follow the instructions which will work best for Wall Mount Garage Door...
  • Page 9: Attach The Rail To The Header Bracket

    Installation Attach the rail to the header bracket HARDWARE Align the rail with the header bracket. Ring Insert the clevis pin through the holes in Fastener the header bracket and rail. Secure with the ring fastener. Clevis Pin NOTE: Use the packing material as a 5/16"...
  • Page 10: Installation

    Installation Hang the garage door opener Hanging your garage door opener will vary FIGURE 2 FIGURE 1 depending on your garage. Two representative Unfinished Ceiling Finished Ceiling installations are shown. Yours may be different. To avoid possible SERIOUS INJURY from a Hanging brackets should be angled (Figure 1) to Not Provided falling garage door opener, fasten it SECURELY...
  • Page 11: Attach The Emergency Release Rope And Handle

    Installation Install the light bulbs Pull on the top center of the light lens and rotate the light lens down. Insert an A19 incandescent (100W maximum) or To prevent possible OVERHEATING of the end panel or light socket: compact fluorescent (26W, 100W equivalent) light •...
  • Page 12: Installation

    Installation FIGURE 1 Install the door bracket A horizontal and vertical reinforcement is needed for lightweight garage doors (fi berglass, aluminum, steel, doors with glass panel, etc.) (not provided). A horizontal reinforcement brace should be long enough to be secured to two or three vertical supports.
  • Page 13: Clevis Pin 5/16" X 2-3/4

    Installation 9 Connect the door arm to the trolley IMPORTANT: The groove on the straight door arm MUST face away from the curved door arm. Attach the straight door arm to the outer Close the door. Disconnect the trolley by Attach the curved door arm to the door CORRECT trolley using the clevis pin.
  • Page 14: Install The Door Control

    Panels or 4 of any other Security+ 2.0™ door Drywall • Connect ONLY to 12 VOLT low voltage wires. controls. NOTE: Older Raynor door controls and Anchors Screw third party products are not compatible. To prevent possible SERIOUS INJURY or DEATH from a closing garage door: 6-32x1"...
  • Page 15 Install the Door Control Position the bottom hole of the door Lift the push bar up and mark the top hole. Remove the door control from the wall Position the bottom hole of the control over the screw and slide and drill a 5/32 inch (4 mm) hole for door control over the screw and down into place.
  • Page 16 Install the Door Control Attach the warning labels Attach the entrapment warning label on the wall near the door control with tacks or staples. Attach the manual release/safety reverse test label in a visible location on the inside of the garage door.
  • Page 17: Install The Protector System

    ® Install the Protector System Introduction IMPORTANT INFORMATION ABOUT THE SAFETY REVERSING SENSORS The safety reversing sensors must be connected and aligned correctly before the garage door opener will move in the down direction. The sending sensor (with an amber LED) transmits an invisible light beam to the receiving sensor (with a green LED). If an obstruction breaks the light beam while the door is closing, the door will stop and reverse to the full open position, and the garage door opener lights will flash 10 times.
  • Page 18: Carriage Bolt 1/4"-20 X 1/2

    ® Install the Protector System Install the Safety Reversing Sensors The safety reversing sensors can be attached to the door track, the wall, or the floor. If the door track will not support the sensor bracket a wall installation is recommended. Choose one of the following installations. OPTION A DOOR TRACK INSTALLATION HARDWARE...
  • Page 19 ® Install the Protector System 1 Install the Safety Reversing Sensors OPTION C FLOOR INSTALLATION Use an extension bracket or wood block to raise the sensor bracket if needed. 1.1C Carefully measure the position of both 1.3C 1.4C Slide the carriage bolt into the slot on Insert the bolt through the hole in the sensor 1.2C Attach the sensor brackets to the floor...
  • Page 20 ® Install the Protector System OPTION B PRE-WIRED INSTALLATION 2.1B 2.2B 2.3B Cut the end of the safety Separate the safety reversing sensor wires and strip 7/16 inch (11 mm) of Connect the pre-installed wires to the sensor wires with wire nuts reversing sensor wire, making insulation from each end.
  • Page 21: Power

    Power To avoid installation difficulties, do not activate the garage door opener at this time. 1 Connect Power To reduce the risk of electric shock, your garage door opener has a grounding type plug with a third grounding pin. This plug will only fit into a grounding type outlet. If the plug doesn’t fit into your outlet, contact a qualified electrician to install the proper outlet.
  • Page 22 Power Ensure the Safety Reversing Sensors are aligned The door will not close if the sensors Check to make sure the LEDs in both sensors are glowing steadily. The LEDs in both sensors will glow steadily if they have not been installed and aligned are aligned and wired correctly.
  • Page 23: Adjustments

    Adjustments INTRODUCTION Your garage door opener is designed with electronic controls to make setup and adjustments easy. The adjustments allow you Without a properly installed safety reversal to program where the door will stop in the system, persons (particularly small children) open (UP) and close (DOWN) position.
  • Page 24: Program The Travel

    Adjustments Program the Travel Without a properly installed safety reversal system, persons (particularly small children) could be SERIOUSLY INJURED or KILLED by a closing garage door. • Incorrect adjustment of garage door travel limits will interfere with proper operation of safety reversal system. •...
  • Page 25: Test The Safety Reversal System

    Adjustments Test the Safety Reversal System With the door fully open, place a 1-1/2 Press the remote control push button to If the door stops and does not reverse on inch (3.8 cm) board (or a 2x4 laid flat) on close the door.
  • Page 26: Operation

    Operation IMPORTANT SAFETY  INSTRUCTIONS WARNING To reduce the risk of SEVERE INJURY or DEATH: 1. READ AND FOLLOW ALL WARNINGS AND INSTRUCTIONS. 10. Safety reversal system MUST be tested every month. Garage door MUST reverse on 2. ALWAYS keep remote controls out of reach of children. NEVER permit children to operate contact with 1-1/2"...
  • Page 27: Features

    Security+ 2.0™ accessories, see page 35. The garage door opener can be activated through a wall-mounted door control, remote control, NOTE: Older Raynor remote controls, door controls, and third party products are not compatible. ® wireless keyless entry or MyQ accessory.
  • Page 28: Door Control

    Door Control USING THE DOOR CONTROL The following features are accessible through the screen using the navigation buttons: LEARN A DEVICE SYNCHRONIZE THE DOOR CONTROL ® Any compatible remote controls, wireless keyless entry, or MyQ accessories can be programmed to To synchronize the door control to the garage door opener, press the push bar until the garage door the garage door opener by accessing the menu and using the navigation buttons.
  • Page 29: Door Control Hardware

    Door Control Smart Control Panel Setup The features on the door control can be programmed through a series of menus on the screen and the navigation buttons. Refer to the descriptions below. SCREEN FEATURES SETTINGS SERVICE Press the navigation button below "MENU" to view The main screen displays the time, Press the navigation button below the down arrow Press and hold the second navigation button, then...
  • Page 30: Remote Control

    Your remote control has been programmed at the factory to operate with your garage door opener. Older Raynor remote controls are NOT compatible, see page 35 for compatible accessories. Programming can be done through the door control or the learn button the garage door opener. To program ®...
  • Page 31: To Erase The Memory

    Remote Control To Erase the Memory ERASE ALL REMOTE CONTROLS AND KEYLESS ENTRIES Press and hold the learn button on garage door opener until the learn LED goes out (approximately 6 seconds). All remote control and keyless entry codes are now erased. Reprogram any accessory you wish to use.
  • Page 32: To Open The Door Manually

    To Open the Door Manually DISCONNECT THE TROLLEY The door should be fully closed if possible. Pull down on the emergency release handle. To prevent possible SERIOUS INJURY or DEATH from a falling garage door: RECONNECT THE TROLLEY • If possible, use emergency release handle to disengage trolley ONLY when garage door is The lockout feature prevents the trolley from reconnecting automatically.
  • Page 33: Troubleshooting

    Troubleshooting Diagnostic Chart Your garage door opener is programmed with self-diagnostic capabilities. The UP and DOWN arrows on the garage door opener flash the diagnostic codes. DIAGNOSTIC CODE SYMPTOM SOLUTION Up Arrow Down Arrow Flash(es) Flash(es) The garage door opener will not close and the light Safety sensors are not installed, connected or wires may be cut.
  • Page 34: Troubleshooting

    Troubleshooting DIAGNOSTIC CODE SYMPTOM SOLUTION Up Arrow Down Arrow Flash(es) Flash(es) Door is moving stops and or reverses. Manually open and close the door. Check for binding or obstructions, such as a broken spring or door lock, correct as needed. If the door is binding or sticking contact a trained door systems technician. If door is not binding or sticking attempt to reprogram travel (refer to page 24 ).
  • Page 35: Accessories

    Accessories MAX ACCESSORIES ® ACCESSORIES STANDARD ACCESSORIES Compatible with Raynor ® garage door openers manufactured since 1993. 41A7773-1 823LM Remote Light Switch: 829LM Garage and Gate Monitor: Security✚ 2.0™ Wireless Automatically control Monitor open/closed status Door Control: your lights using your for up to 4 MyQ ®...
  • Page 36: Warranty

    Warranty RAYNOR ® FIVE-YEAR LIMITED WARRANTY LIFETIME MOTOR LIMITED WARRANTY RAYNOR ® (“Seller”) warrants to the fi rst retail purchaser of this product, for the residence in which this product is originally installed, that it is free from defect in materials and/or workmanship for a period of fi...
  • Page 37: Repair Parts

    Repair Parts Rail Assembly Parts Installation Parts Description Part Number Description Part Number Chain - for 7 foot door 41D3484 Curved Door Arm 178B35 Chain - for 8 foot door 41D3483 Door Bracket with Clevis 41A5047 Pin and Fastener Chain - for 10 foot door 41D3485 Emergency Release Rope 41A2828...
  • Page 38 041A7619-9 Logic Board 045ACT Logic Board End Panel 041D0216 Contact Information Address repair parts order to: For installation and service information call: Raynor ® Garage Doors 1-800-472-9667 1101 East River Road Or visit us online at: Dixon, IL 61021-0048 www.Raynor.com Before calling, please have the model number of the garage door opener.
  • Page 39: Notes

    Notes...
  • Page 40 © 2015, The Chamberlain Group, Inc. 114A4621C All Rights Reserved...
