2.2.2 Interior View

1
2
3
4
5
13
14
15
8
6 7
18
16 17
9
10
1.
Ribbon rewind spindle
2.
Z axis mechanism adjustment knob
11
3.
Print head pressure adjustment knobs
4.
Ribbon guide bar
5.
Print head release lever
6.
Ribbon release button
12
7.
Rear label guide
8.
Media guide bar
9.
Rear label guide
10.
Label supply spindle
11.
Ribbon supply spindle
12.
Media damper
13.
Print head
14.
Gap sensor
15.
Planten roller.
16.
Black mark sensor
17.
Front label guide
18.
Ribbon sensor
