OPERATING INSTRUCTION MANUAL
Request for the Customers
•
Read and understand this operating manual before using the detector.
•
Use the detector in accordance with the operating manual.
•
Regardless of warranty period, we shall not make any compensation for accidents and damage
caused by using this product.
The compensation shall be made only under the warranty policy of products or parts
replacement.
•
Because this is a safety unit, a regular maintenance for every six months and daily maintenance
must be performed.
•
If any abnormality was found in the detector, notify them to Riken Keiki or local representative
immediately.
MULTI-UNIT CASE
590-04W/590-04R
590-06W/590-06R
590-09W/590-09R
590-12W/590-12R
FOR
PT1E-0912
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Riken Keiki 590-04W
Summary of Contents for Riken Keiki 590-04W
- Page 1 • Because this is a safety unit, a regular maintenance for every six months and daily maintenance must be performed. • If any abnormality was found in the detector, notify them to Riken Keiki or local representative immediately. ...
- Page 2 INDEX １．PRODUCT OUTLINE １−１．In the beginning・・・・・・・・・・・・・・・・・・・・・・・ 2 １−２．Application for use・・・・・・・・・・・・・・・・・・・・・・・ 2 １−３．Identification of each cautional marks・・・・・・・・・・・・・ 2 ２．IMPORTANT INSTRUCTION FOR THE SAFETY ２−１．Danger items・・・・・・・・・・・・・・・・・・・・・・・・・ 3 ２−２．Warning items・・・・・・・・・・・・・・・・・・・・・ ・・・ 3 ２−３．Caution items・・・・・・・・・・・・・・・・・・・・・・・・ 4 ３．PRODUCT FUNCTION ３−１．External drawing ３−１−１．Wall mounting type・・・・・・・・・・・・・・・・・・・ 5 ３−１−２．Panel mounting type・・・・・・・・・・・・・・・・・・ 6 ３−２．Name of each part and function・・・・・・・・・・・・・・・・・・ 7 ...
-
Page 3: Product Outline
1. PRODUCT OUTLINE １−１．In the beginning First of all, we wish to express our heartful thanks for your purchase of our multi-unit case 「590-*□□W(R)」 for RM-590 series. *: Number of monitoring capacity is put into □□.”W” and “R” mean wall mounting type and panel(rack) mounting type respectively. This manual describes specifications and instructions for use for RM-590 series multi-unit case. Your kind reading of this manual is requested not only for the first user but for already experienced staff. １−２．Application for use This is an exclusive multi-unit case to house indicator/alarm units and buzzer unit for RM-590 series. It can be used only by connecting power source and detector head as power unit is built in it. Any indicator/alarm unit for RM-590 series can be arranged in this multi-unit case. Basic composition ・Power unit（PSU-590）･･････････････････････････････････ 1 pce ・Coupling unit for buzzer unit（RM-590-MCASE）･･･････････ １ pce ・Coupling unit for indicator/alarm unit（RM-590-MCASE） ･･････････ Depends on mounting points（Max.12 pcs.） Coupling unit for indicator/alarm unit is for 4,6,9 and 12 points each as standard version. It is also available for other points (2-12 points). In such case, optional mounting angle is required. １−３．Identification of each cautional marks DANGER Indicates an imminently hazardous situation which, if not avoided, will result in death or serious injury. This signal word is to be limited to the most extreme situation. WARNING Indicates a potentially hazardous situation which, if not avoided, could result in death or serious injury. CAUTION Indicates a potentially hazardous situation which, it not avoided, may result in minor or moderate injury. It may also be used to alert against unsafe practices. ＊NOTE This means “ADVICE” at operation. ... - Page 4 2. IMPORTANT INSTRUCTION FOR THE SAFETY ２−１．Danger items DANGER This is not a explosion proof unit. Do not use it at places where combustible/explosive gases or vapours may exist. It is very danger to operate under such environment. ２−２．Warning items WARNING ・ Buzzer unit, indicator/alarm unit Do not connect other buzzer unit and indicator/alarm unit than that of for RM-590 series. If connected, this multi-unit case or other connected unit may be broken. ・ Power source Before supplying the power, confirm that the power source is a designated voltage. ・ Maximum monitoring capacity The maximum monitoring capacity is 12 points due to the capacity of power unit. ・ Necessity of protective grounding Do not cut inside or outside wire for earth, nor disconnect the wire from earth terminal. ...
- Page 5 ２−３．Cautional items CAUTION ・ Do not use walky-talky near this unit. When this unit receives the electric waves by walky-talky etc near from the cable, this will effect the reading. When use the walky-talky, operate it at the place where there is no influence of electric wave ejection. ・ When make power on again, make it after an interval of over 5 seconds. When make power on within 5 seconds, there may be no normal operation. ・ When operate it not to follow this manual, repair it by other rating parts or modify it on his own, the safety and quality of products can not be secured. Then, when an accident take place by it, we cannot assure our responsibility on them. Take enough consideration for instrumentation to keep safety even if disconnection of power and signal lines, defect of operation or trouble would be happen due to unexpected reason. This is an electrical applied instrument. Be care it may be effected by power noise, electrostatic and electromagnetic noise. When use under such conditions, make protective treatment for use. ...
- Page 9 Arrangement of connection terminal ３−３． Power unit ＣＮ２ ＴＡＮ２ Input/output for (Terminal plate for pump power) ...
-
Page 10: How To Use
４．HOW TO USE ４ − １ ． Before operation Be sure to keep cautional items of use not only for first user but for already experienced staff. If not keep these cautional items, the unit may be defective and correct gas detection may not be performed. ４ − ２ ． Mounting/dismounting procedures When mounting/dismounting indicator/alarm unit and buzzer unit for RM-590 series, make following procedures. （１）Mounting method ・Open the front cover of indicator/alarm unit and buzzer unit. ・Confirm that the power switch is at OFF ・With the disengagement lever at down position, mount into the case. （Confirm that the edge connector is put in firmly） ... - Page 11 ４ − ３ ． Installation place CAUTION Do not install at places where direct sun drought or where the temperature is drastically changed. Keep away the system from direct sun drought or where the temperature of the system is drastically changed. Do not install it where vibration or shocks may take place. The system consists of fine electronics parts. Install them where to be stable not to crush or fall down. Keep the system from the equipment which may generate the noise (Unit & cable). Keep the system from the equipment which may give a high frequency in the surroundings and install it. ・Do not put the system jointly each. ・Do not wire the cable in parallel nor take access. Do not install it where the detection gas is deposited around. Do not install and make gas detection at the place where the sample gas is deposited. Do not install at the place where it is danger for maintenance service such as high voltage cable, etc. This unit is required to make maintenance regularly. Then, do not install at the place where there is danger at maintenance time. Do not install it where it is unable to make maintenance. When required to stop the system at maintenance time, unable to maintain if not remove a part of system ...
- Page 12 ４ − ４ ． Caution in the system engineering CAUTION Unstable power and noise may cause error of performance and alarm. For the system to use this unit, it is required to make design based on this manual descriptions. （１）Stable power used While the system gets stable at power failure, the external output and alarm contact may be on and the care for it must be taken. In such case, use the standby battery or take an appropriate action in the receiver side. Supply the following power to this unit . Power voltage 100〜240VAC, 50/60 Hz Approx 50msec. Power failure （For power failure of 50msec, it re-starts） ...
- Page 13 （４）Alarm contact ・Alarm contacts shall be used only for external buzzer and alarm light, and do not use it for the controlling use (such as solenoid valve control etc). When control the external load, the bad influence may be given to the system according to the load characteristics. In such case, the following countermeasure shall be taken to stabilize the action and protect the contents. ・Relayed by the low voltage relay and operate by connecting CR circuit (Spark Killer: SK) (Diode etc for DC) suited for relay coil directly to relay. ・Add CR circuit to the load side of relay on the request. CAUTION （FOR USE OF NORMALLY-CLOSED CONTACT） Normally-closed contact (Break contact) at non-existing condition may change to open contact in a moment due to physical shock. Whenever alarm signals from gas detectors are used with normally-closed contact, please put delayed-circuit (for about one second) to receiver side of normally-closed contact to avoid such phenomenon. ...
- Page 14 Reference:By the condition of load, CR circuit may be better to install in the contact side but it is required to put in by checking the action of load. ＳＫ : Surge absorption filter SK SK Ｖ Ｖ Alarm contact Power supply Power supply Relay (Low pressure relay) −How to think alarm contacts against inductive load− When use the inductive load for alarm contacts, the very high reverse electromotive voltage may be generated and the following trouble tends to be produced.) ・Contact part of relay is melted adhesively and the contacts can no work. ・High voltage is put inside of indicator/alarm unit and then, electrical parts may be damaged. ・As it is big noise, the trouble action may be taken by the reckless drive of CPU. ...
- Page 15 Grounding ４−５． Make grounding with terminal WARNING Be sure to make grounding before putting power ON. Terminal Be sure to make grounding for safety purpose and to keep stable operation of this unit. Do not connect earth wire with gas pipe. Make grounding corresponding to D-class grounding (Grounding resistance : below 100 ohms). ...
- Page 16 ５. CONNECTIONS OF EACH UNIT ５−１．Connection of power cable The power requirement of this multi-unit case is 100V 〜 240VAC ±10%, 50/60Hz. Apply power source within this specified range. Before connecting power cable, FG terminals shall be grounded.. Grounding resistance shall be according to D-class grounding(Resistance: below 100Ω). After grounding and it becomes in safety condition, make wirings for power source and others. ５−２. Connections of detector heads. Terminal numbers ③,④,⑤ and ⑥ are the connection of detector head. ５−３．Connections of relay outputs RM-590 series provides relay outputs for 1st alarm, 2nd alarm and trouble alarm in each unit. Also, buzzer unit provides relay outputs for total 1st alarm, total 2nd alarm and total trouble alarm. Rating of relay contact is 0.5A at 100VAC,1.5A at 30VDC(Resistive load). When connecting the load above rating, use auxiliary relay circuit. Power source for auxiliary relay Power source for utility Multi-unit case Terminal plate Auxiliary relay RY Alarm contact Load When the inductive load is used for alarm contact, connect an appropriate spark killer to the load side. ５−４．Connection of 4-2mA output The RM-590 series provides 4-20mADC output from each unit. The load to be connected is up to 300Ω(Max.). Use a shielded cable equivalent to CVVS for connection. ...
- Page 17 ５−５．Connection diagram for each detector head ・ＧＰ−５９１／ＮＣ−５９１／ＮＣ−５９１Ｗ for catalytic combustion gas detector heads. Terminal plate for pump in power unit Terminal plate of indicator/alarm unit in multi-unit case ７...
- Page 18 ・ＯＸ−５９１（Direct transmission）/ OX-592(4-20mA transmission) for galvanic cell type detector heads Terminal plate for pump in power unit Terminal plate of indicator/alarm unit in multi-unit case ７ １ ＋ 1st gas alarm contact 4-20mA ８ output ２ − ９ ３ 2nd gas alarm contact 10 Short-circuit ４ 11 Trouble alarm contact ５ 12 ６ 13 FG CVV−2C 1.25 or 2.0mm2 Applicable detector heads CVVS−2C ...
- Page 19 ・ＲＭ−５９２ for 2-wire, 4〜20mA general measuring signal or detector heads. Terminal plate of indicator/alarm unit in multi-unit case ７ １ ＋ 1st alarm contact ８ 4-20mA output ２ − ９...
-
Page 20: Product Specifications
: 250V 5A T(For power source) 250V 2A T(For pump) External terminal : Screw type(3mm) Outer dimensions & weight : Panel/Rack mounting design 590-04R : Approx 261(W)×260(H)×153(D)mm Approx 5.7kg 590-06R : Approx 334(W)×260(H)×153(D)mm Approx 7.1kg 590-09R : Approx 443(W)×260(H)×153(D)mm Approx 9.2kg 590-12R : Approx 552(W)×260(H)×153(D)mm Approx11.3kg Wall mounting design 590-04W : Approx 261(W)×260(H)×156(D)mm Approx 5.7kg 590-06W : Approx 334(W)×260(H)×156(D)mm Approx 7.1kg 590-09W : Approx 443(W)×260(H)×156(D)mm Approx 9.2kg 590-12W : Approx 552(W)×260(H)×156(D)mm Approx11.3kg ...
