Page 2
Contents 1 Outline of the Product ............................. 4 Preface................................4 Purpose of use..............................4 Checking gases to be detected ........................5 Definition of DANGER, WARNING, CAUTION and NOTE ................6 2 Important Notices on Safety ..........................7 2-1. Danger cases ............................7 2-2.
Page 3
10-2. List of accessories ..........................117 11 Appendix ..............................118 11-1. Calibration history/various trend/event history functions ..............118 11-2. Definition of terms ..........................120 11-3. List of gases for reading VOC ......................121 - 3 -...
Page 4
The gases to be detected varies by the sensors installed in the gas monitor. Check the gases to be detected before use and conduct gas detection properly in accordance with purposes. Check the gases to be detected by your GX-6000 in 'Checking gases to be detected' (P. 5). - 4 -...
Page 12
Three different types of detection principle are applied for Smart Sensors and up to two sensors can be installed into the GX-6000. Gas is sampled by a built-in micro pump.
Page 13
2 Important Notices on Safety 2-4. Safety information Certificate numbers •IECEx Certificate number : IECEx PRE 15.0011 •ATEX Certificate number : Presafe15 ATEX6171X List of standards •IEC 60079-0:2017 ・EN IEC 60079-0:2018 •IEC 60079-11:2011 ・EN60079-11:2012 Specific conditions of “X”-mark: Regarding ATEX specification, the measuring function according to Annex II paragraph 1. 5. 5 of the Directive is not covered by this EU-type examination.
Page 14
3-1. Main unit and standard accessories Unpack and check the main unit and accessories. If any part is missing, contact RIKEN KEIKI. Main unit See '3-2. Names and functions for each part' (P. 18) for names and functions of each part of the gas monitor and LCD display.
Page 15
3 Product Components 3-1. Main unit and standard accessories Standard accessories Lithium ion battery unit Charger* (BUL-6000)* 1 pc 1 pc Dry battery unit** AA alkaline (BUD-6000) battery** 1 pc 3 pcs Belt clip Protect cover 1 pc 1 pc (3 screws) Protect the gas The gas monitor...
Page 20
3 Product Components 3-2. Names and functions for each part Battery unit <Lithium Ion Battery Unit (BUL-6000)> <Dry Battery Unit (BUD-6000)> - 20 -...
Page 105
The vial of cleaning compound contains alumina (CAS Number 1344-28-1) as a very fine powder. Cleaning should be undertaken in a well-ventilated area. A full material safety data sheet MSDS is available on request from RIKEN KEIKI. Key safety issues are identified below: Hazard identification:...
Page 106
7 Maintenance 7-4. Parts replacement Re-fitting Electrode pellet and PID lamp Caution! Never refit a damaged lamp 1. Place the lamp inside the O-ring seal in the pellet as illustrated. Twisting the lamp slightly during insertion will help to ensure the lamp window is snug against the pellet’s front electrode. The lamp should be freely supported by the O-ring.
Page 108
The operation must be checked after replacement by a qualified service engineer. For the stable operation of the unit and safety, ask a qualified service engineer to take care of replacement of the part. Request it from RIKEN KEIKI. NOTE The above replacement intervals are recommendation only.
Page 119
11 Appendix 11-1. Calibration history/various trend/event history functions (4) Trouble event Records the trigger of fault alarm as an event. The event records the time when the trouble was triggered, the target gas of measurement, and the type of fault event. Up to 100 latest events are recorded.
Page 120
11 Appendix 11-2. Definition of terms 11-2. Definition of terms Gas concentration indicated in the unit of one-billionth of the volume Gas concentration indicated in the unit of one-millionth of the volume vol% Gas concentration indicated in the unit of one-hundredth of the volume The acronym of Lower Explosive Limit.
