Summary of Contents for Cembre B-TC650NA
- Page 1 BATTERY OPERATED HYDRAULIC CUTTING TOOL B-TC650A B-TC650NA ENGLISH OPERATION AND MAINTENANCE MANUAL...
- Page 2 FIG. 1a FIG. 2 Metabo battery Makita FIG. 1b Low battery battery Cu Al Steel FIG. 3a FIG. 3 FIG. 4...
- Page 3 FIG. 5 B-TC650A B-TC650NA LED WORKLIGHT UPPER BLADE LOWER BLADE LATCH OPERATING BUTTON PRESSURE RELEASE BUTTON BATTERY RELEASE BATTERY RING FOR SHOULDER STRAP BATTERY ADAPTER...
-
Page 4: Warning Symbols
WARNING SYMBOLS Tool – Before using the tool, carefully read the instructions in this manual. – Keep hands clear of cutting blades. – Do not cut Steel. – Always wear safety glasses and gloves when operating this tool. – User information applies in member states of the European Union (Directives 2011/65/EU and 2012/19/EU), see page 9. -
Page 5: General Characteristics
1. GENERAL CHARACTERISTICS B-TC650A B-TC650NA Application range suitable for cutting Copper, Aluminium or telephone cables Max. cutting diameter mm (inches) 65 (2-9/16") Operating pressure bar (psi) 700 (10,000) 429 x 415 x 83 429 x 435 x 83 Dimensions (Fig. 9 and fi g. - Page 6 B-TC650A: in the fi g. 1a press the release button (7) and slide the battery out unlocking it. B-TC650NA: in the fi g. 1b press the release buttons (7) and slide the battery out unlocking it. Insert a charged battery by sliding it into the guides until it locks.
- Page 7 2.2) Setting Insert the conductor between the blades, up to the desired cutting point (Ref. to Fig. 3). For a running conductor, release the latch (4) and open the tool head (Ref. to Fig. 3a). Fully retract the lower blade (3) before attempting to open the tool head (Ref. to § 2.6). With the conductor on the lower blade (3), close the tool head and fully secure the latch (4).
-
Page 8: Maintenance
The tool will continue to work however 15 sec. after use an alarm comprising 3 beeps com- bined with illumination of the worklights will signal that its return to Cembre for service is recommended (see § 6). -
Page 9: Connection To Computer
5. CONNECTION TO COMPUTER The memory card integrated in the tool records operating data for transfer via the USB cable supplied. To view and manage this data, go to www.cembre.com and register in the dedicated area, then download the free Cembre software CEM_SWBT01. - Page 10 429 (16.9) 83 (3.3) B-TC650A FIG. 9 mm (inch) 429 (16.9) 83 (3.3) B-TC650NA FIG. 10 mm (inch)
-
Page 12: Return To Cembre For Overhaul
Centre; if possible, attach a copy of the Test Certifi cate supplied by Cembre together with the tool or fi ll in and attach the form available in the “ASSISTANCE” section of the Cembre website.
