CONNECTING TO MONITORS*
Use the diagram below to connect to a Monitor or CRT Monitor properly.
12VDC
Monitor
Power Connection - 12VDC Voltage.
All cameras are equipped with a second video output for on-site configuration.
10
Second Video Output
CCTV Monitor
