Digital Watchdog MEGApix DWC-MV75Wi28TW User Manual page 16

Setup - Video & Audio Setup
Video Configuration
1
2
3
4
5
Live Video Channel Setup - The video can be configured to various settings with a combination of codec and
1
resolution. The camera performance should be considered when setting multiple channels, as the performance
of the camera will be affected.
H.265 (HEVC) codec with higher bitrate may cause unstable live streaming or reload the webpage.
Codec - Choose the video codec. Depending on the selected codec, the subcategories may be changed
2
accordingly.
Description - Input the additional description of the selected channel. Max. 30 alpha-numeric characters may
3
be used, including spaces.
Resolution - Select video resolution.
4
Available Frame Rate may differ even if the same codecs are in use.
<Resolution of Video Format>
2.1MP/
5MP
4MP
(QSXGA)
1080p
2592x1944 2560x1440 1920x1080
Frame Rate - Select the maximum Frame Rate.
5
Available Frame Rate can be different although the same codecs were set up.
768x432
720p/i SVGA
(0.3M)
1280x720 800x600 768x432
16
4CIF D1 VGA
704x576 704x480 640x480
640x360
CIF SIF / 240P
(0.2M)
640x360 352x288 352x240
