® registered trademarks of HDMI licensing Administrator, Inc.
Page 3
DISCLAIMERS The information in this manual has been carefully checked and is believed to be accurate. Cypress Technology assumes no responsibility for any infringements of patents or other rights of third parties which may result from its use. Cypress Technology assumes no responsibility for any inaccuracies that may be contained in this document.
Page 4
SAFETY PRECAUTIONS Please read all instructions before attempting to unpack, install or operate this equipment and before connecting the power supply. Please keep the following in mind as you unpack and install this equipment: • Always follow basic safety precautions to reduce the risk of fire, electrical shock and injury to persons.
1. INTRODUCTION This UHD HDMI/VGA Table Box scaler is an HDMI/VGA switch with audio embedding and HDBaseT output. The table box is designed to be placed on a table, or mounted to any typical table edge using a clamp. This unit can send high definition uncompressed audio/video along with Ethernet over a single cable up to a distance of 100 meters at 1080p@60Hz.
2. APPLICATIONS • Household entertainment sharing and control • Lecture room display and control • Showroom display and control • Meeting room presentation and control • Classroom display and control 3. PACKAGE CONTENTS • 1× UHD HDMI/VGA over HDBaseT Table Box Scaler Transmitter •...
6. OPERATION CONTROLS AND FUNCTIONS 6.1 Front Panel HDMI IN LINK VGA IN AUTO VGA IN ADJUST L/R IN PWR LED: This LED will illuminate to indicate the unit is on and receiving power. LINK LED: This LED will illuminate solidly when a live connection with a compatible receiver is active.
6.2 Rear Panel CAT5e/6/7 OUT CAT5e/6/7 OUT Port: Connect to a compatible HDBaseT receiver with a single Cat.5e/6/7 cable for transmission of all data signals. Power via PoH will also be supplied to this unit when connected to a compatible PSE receiver.
6.4 Serial Commands COMMAND Description and Parameters help Show the full command list. ? Show the full command list. get fw ver Show the unit’s firmware version. get model name Show the unit’s model name. set out A route N1 Route the specified input to the HDBaseT output.
Page 12
COMMAND Description and Parameters get in N1 timing Show the current resolution detected on the specified input. Available values for N1: [HDMI] [VGA] Note: Timing information can only be displayed for the currently se- lected input. get in type list List the port type of all inputs on the unit.
Page 13
COMMAND Description and Parameters [1920×1200@60RB] [2048×1080@50] [2048×1080@60] [2560×1440@60RB] [2560×1600@60RB] [720×480p@60] [720×576p@60] [1280×720p@50] [1280×720p@60] [1920×1080p@24] [1920×1080p@25] [1920×1080p@30] [1920×1080p@50] [1920×1080p@60] [2560×1080p@50] [2560×1080p@60] [3840×2160p@24] [3840×2160p@25] [3840×2160p@30] [4096×2160p@24] [4096×2160p@25] [4096×2160p@30] get out A timing Show the current resolution used by the HDBaseT output. get out A sync status Show the current sync state of the HDBaseT output.
Page 14
COMMAND Description and Parameters set out A brightness N1 Set the brightness level of the HDBaseT output. N1 = 0~60 [Brightness] get out A brightness Show the current brightness level. set out A saturation N1 Set the saturation level of the HDBaseT output. N1 = 0~60 [Saturation] get out A saturation...
Page 15
COMMAND Description and Parameters get out A nr Show the current amount of noise reduction applied to the HDBaseT output’s source. set out A aspect ratio N1 Set the aspect ratio of the video shown on the HDBaseT output. Available values for N1: [Overscan] [Full] [Best fit]...
Page 16
COMMAND Description and Parameters get out A r gain Show the current red gain level. set out A g gain N1 Set the HDBaseT output’s green gain level. N1 = 0~1023 [Green gain] get out A g gain Show the current green gain level. set out A b gain N1...
Page 17
COMMAND Description and Parameters set in 2 phase N1 Set the PC phase value for the VGA input. N1 = 0~255 [PC phase] get in 2 phase Show the current PC phase value for the VGA input. set in 2 clock N1 Set the PC clock value for the VGA input.
Page 18
COMMAND Description and Parameters set audio out A route N1 Set the audio routing behavior for the HDBaseT output. Available values for N1: [Follow video] [Analog audio] get audio out A route Show the currently selected audio routing behavior. get audio in type list List all available audio input sources.
Page 19
COMMAND Description and Parameters set out A osd timeout N1 Set the OSD’s timeout value. Available values for N1: [Off] [5 seconds] [10 seconds] [15 seconds] [20 seconds] [25 seconds] [30 seconds] [35 seconds] [40 seconds] [45 seconds] [50 seconds] [55 seconds] [60 seconds] get out A osd timeout...
Page 20
COMMAND Description and Parameters set out A osd hposition N1 Set the horizontal position of the OSD. N1 = 0~60 [H position] get out A osd hposition Show the current horizontal position of the OSD. set out A osd transparency N1 Set the transparency level of the OSD.
Page 21
COMMAND Description and Parameters get uart 1 baudrate Show the current RS-232 baud rate setting. set uart 1 stop bits N1 Set the number of RS-232 stop bits. Available values for N1: [1 bit] [2 bits] get uart 1 stop bits Show the current number of RS-232 stop bits.
Page 22
COMMAND Description and Parameters set in 1 edid N1 Set the EDID to use on the HDMI input. Available values for N1: [1080P, 2CH] [4K (3G), 2CH] [4K (6G), 2CH] [Output’s EDID] get in 1 edid Show the EDID currently being used on the HDMI input. get in edid list...
Page 23
COMMAND Description and Parameters get automation event N1 uart A Show the current state of the specified Automation Event’s RS-232 response. N1 = 1~3 [Automation Event number] set automation event N1 uart A delay N2 sce Set the delay time that the specified Automation Event must continue to be true before sending the defined RS-232 command.
7. CONNECTION DIAGRAM Media Player HDMI Input Stereo Input Input HDMI IN LINK VGA IN VGA IN AUTO ADJUST L/R IN Cat.5e/6/7 Cable Wireless Router Power Supply BLASTER HDMI OUT DC 48V EXTENDER RS-232 OUT POWER STD UPDATE LINK HDMI RS-232 Output RS-232...
8.5 HDBaseT Features HDBaseT Feature Set Transmitter Video & Audio Extension Supported LAN Extension Supported Send power to Receiver Unsupported Accept power from Receiver Supported (PoH) IR Extension Unsupported RS-232 Extension Unsupported USB 2.0 Extension Unsupported...
