  • Page 1 Battery Powered Smoke Alarms EIB650i Series Read and retain carefully for as long as the product is being used. It contains vital information on the operation and installation of your Smoke Alarm. The leaflet should be regarded as part of the product.
  • Page 3 Table 1 Intelligent Alarms Model Hardwired Interconnect Capability EIB650iC EIB650iW 1. See table 3 for intelligent features and operation 2. Certain Alarms may be supplied (on request) with the appropriate RF module fitted...

  • Page 4: Table Of Contents

    CONTENTS Page QUICK START GUIDE LOCATION & POSITIONING INSTALLATION INTERCONNECTION - HARD WIRED TESTING, MAINTENANCE & POWER SUPPLY MONITORING FIRE SAFETY ADVICE SMOKE ALARM LIMITATIONS RADIOLINK MODULES GETTING YOUR ALARM SERVICED FIVE YEAR GUARANTEE TROUBLESHOOTING ALARM INDICATORS COMPATIBLE EQUIPMENT CONTACT US...

  • Page 5: Quick Start Guide

    1. Quick Start Guide LOCATE CORRECT SITING POINT FIX BASEPLATE TO CEILING ALARM SHOULD BE CEILING MOUNTED AT LEAST 300MM FROM WALLS & OBSTRUCTIONS, IDEALLY CENTRALLY IN ROOM/AREA PLACE ALARM & TWIST ON TO BASE TWISTING THE UNIT ON TO THE BASE AUTOMATICALLY CONNECTS THE BATTERY Quick Start Guide...
  • Page 6 Quick Start Guide TEST ALARM PRESS THE TEST BUTTON TEST ALARM AT LEAST WEEKLY...

  • Page 7: Location & Positioning

    2. Location & Positioning Introduction Congratulations on purchasing an EIB650i Series Alarm. You can easily install these Smoke Alarms throughout the property on escape routes, on each storey, in corridors & in closed rooms to give warning of fire. The EIB650iC can be interconnected with hard wiring (or RadioLINK + plug-in modules) to give the loudest alarm sound level throughout the house.For wireless...
  • Page 8 Your first Smoke Alarm should be located between the sleeping area and the most likely sources of fire (living room for example), but it should not be more than 7.5 metres from the door to any room where a fire may start and block your escape from the house.
  • Page 9 Recommended Protection The Building Code of Australian, state and territory building regulation and AS1670.1 give the guidance on: - how many Alarms to install - what type of Alarm to use - where to position Alarms The above points will depend on the type of dwelling and class of building to be protected and the level of fire risk.
  • Page 10 Figure 1 For minimum protection - Smoke Alarm on each storey - every 7.5 metres of hallways and Kitchen Bedroom escape routes Bathroom Living Room - within 3 metres of all bedroom doors - all Alarms interconnected Dining Room For recommended protection Bedroom (in addition to the above): - Smoke Alarms in every room (except...
  • Page 11 We do not recommend wall mounting of Smoke Alarms. On a Sloping Ceiling With a sloping or peaked ceiling install a Smoke Alarm within 600mm of the peak (measured vertically). If this height is less than 600mm it is regarded as being flat (see Figure 4).
  • Page 12 Locations to avoid DON’T place Smoke Alarms in any of the following areas: • Bathrooms, kitchens, shower rooms, garages or other rooms where the smoke alarm may be triggered by steam, condensation, normal smoke or fumes. Keep at least 6 metres away from sources of normal smoke/fumes. •...

  • Page 13: Installation

    • Locate alarm at least 1.5m and route any interconnectedwiring at least 1m away from fluorescent light fittings as electrical “noise” and/or flickering may affect the Alarm. 3. Installation Installation Procedure 1. Select a location complying with the advice in Section 2. 2.
  • Page 14 picking a part of the building, say the front wall of the building and then installing all mounting plates in the same orientation with respect to this (see figure 6). 6. Carefully line up the Alarm on the base, gentle press home & twist on. Front Wall Front Wall Mounting Plate...
  • Page 15 Install all the other Smoke Alarms similarly. Tamperproofing the Smoke Alarms The Alarm can be made tamperproof to prevent unauthorised removal. Break off the small pillar on the base as shown in figure 8a. To remove the Alarm from the ceiling it is now necessary to use a small screwdriver.
  • Page 16 If necessary, it is possible to further secure the Alarm by using a No.2 or No.4 (2 to 3 mm diameter - not supplied) self tapping screw 6 to 8mm long (see figure 8d), to firmly lock the Alarm and its mounting plate together (see figure 8c). First, attach the Alarm to the mounting plate.

  • Page 17: Interconnection - Hard Wired

    4. Interconnection - Hard Wired A combined maximum of 12 Smoke Alarms and/or Heat Alarms may be wired together such that when one Alarm senses fire all other Alarms sound a warning - (see Table 1 for the Smoke Alarms with the hardwired interconnect option). This helps ensure the alarm will be heard throughout the property.
  • Page 18 making it insensitive. It is essential that all such ceiling openings be closed with silicone sealant or similar. 1. Run the two core cable to the Alarm locations. 2. Bring the cable through the opening in the mounting plate (before screwing it to the ceiling) see figure 9b.

  • Page 19: Testing, Maintenance & Power Supply Monitoring

    6. Twist the Alarm clockwise on to the mounting plate to lock in place. Install and connect all the other Alarms similarly. Now test the first Alarm by pressing and holding the Test button (this may take up to 5 seconds). The red indicator light will flash about once every 0.5 seconds and all Alarms should sound (note: when the test button is released the local Smoke Alarm will stop sounding but the interconnected Alarms will continue to sound for a further 3 seconds.
  • Page 20 - If they are interconnected using RadioLINK + modules, hold down the Test button until the blue light on the cover of the Alarm illuminates. Check that all other Alarms sound. - Release the Test button. The Alarm and all connected Alarms should stop sounding.
  • Page 21 If you installed Smoke Alarms with RadioLINK + modules and did not House Code them, you may be receiving alarm signals from a neighbouring system. This can be easy rectified by “House Coding” your Alarms - see the ‘RadioLINK + Module Booklet’.
  • Page 22 The latest design, materials and manufacturing techniques have been used in the construction of Ei Electronics Alarms to minimise the effects of contamination. However it is impossible to completely eliminate the effect of dust and insect...
  • Page 23 it is kept clean so that excess dust does not build up. Any insects or cobwebs in the vicinity of the Smoke Alarm should be promptly removed. In certain circumstances even with regular cleaning, contamination can build up in the smoke sensing chamber causing the Alarm to sound.

  • Page 24: Fire Safety Advice

    6. Fire Safety Advice When using household protective devices, basic safety precautions should always be followed, including those listed below • Please read all instructions. • Rehearse emergency escape plans so everyone at home knows what to do in case the alarm sounds. •...
  • Page 25 • This is not a portable product. It must be mounted following the instructions in this instruction leaflet. • Smoke Alarms are not a substitute for insurance. The supplier or manufacturer is not your insurer. Fire Safety Hints Store petrol and other flammable materials in proper containers. Discard oily or flammable rags.
  • Page 26 This device cannot protect all persons at all times. It may not protect against the three most common causes of fatal fires: 1. Smoking in bed. 2. Leaving children at home alone. 3. Cleaning with flammable liquids, such as petrol. Further information can be obtained from the Fire Brigade.

  • Page 27: Smoke Alarm Limitations

    4. Call the Fire Brigade from a neighbour’s house or mobile phone. Remember to give your name and address. 5. NEVER re-enter a burning house. NEVER 7. Alarm Limitations Limitations of Smoke Alarms Smoke Alarms have significantly helped to reduce the number of fire fatalities in countries where they are widely installed.

  • Page 28: Radiolink Modules

    recommended in this leaflet very significantly improve the probability of early detection. • The Smoke Alarm may not be heard. • RadioLINK + may not work due to interference or due to the signal being blocked by furniture, renovations etc. •...

  • Page 29: Getting Your Alarm Serviced

    9. Getting Your Alarm Serviced If your Alarm fails to work after you have read the sections on “Installation”, “Testing and Maintenance” and “Troubleshooting”, then contact Customer Assistance at the nearest address given at the end of this leaflet. If it needs to be returned for repair or replacement the Smoke Alarm must be removed from the mounting plate and put in a padded box.

  • Page 30: Troubleshooting

    11. Troubleshooting Smoke Alarms sound for no apparent reason • Check for fumes, steam, etc. from the kitchen or bathroom. Paint and other fumes can cause nuisance alarms. • Check for any sign of contamination such as cobwebs or dust. Clean the Alarm as described in Section 5 if necessary.

  • Page 31: Alarm Indicators

    12. EIB650i Alarm Indicators Table 3 - EIB650i INDICATOR SUMMARY Normal Operation Action Red LED Yellow LED Sounder See 12.1 Replace Alarm Power up Twist on base 1 flash 1 flash 12.1.1 Standby 12.1.2 Weekly button test Press & hold button Rapid flashing (0.5 sec) Ramps to full sound 12.1.3...
  • Page 32 Table 3 - EIB650i INDICATOR SUMMARY (cont.) Diagnostics Modes Action Red LED Yellow LED Sounder See 12.3 Replace Alarm Predictive failures 12.3.1 Recommended Low battery Press & hold button Rapid flash (0.5 sec) Ramps to full sound Ramps to full sound See note Contaminated chamber Press &...
  • Page 33 Table 3 EIB650i Indicators explained 12.1. Normal Operation 12.1.1. Power Up Twist the Alarm onto the base to power up, the red LED will flash once followed by one flash of the yellow LED to indicate that the Alarm has been powered successfully and is now in standby mode.
  • Page 34 12.1.5. Silence False / Nuisance alarm Occasionally Smoke Alarms can be activated by phenomena other than fire, e.g. dust, insects, cooking fumes. Once you are sure it is a nuisance alarm press the large test button to silence the alarm for 10 minutes – the red LED will then flash every 8 seconds for 10 minutes.
  • Page 35 If it is not convenient to replace the Alarm immediately, then press the test button to silence the low battery beeps and stop the yellow LED flashing for 12 hours. This can be repeated as required. 12.2.2. Contaminated chamber If the Alarm sounds without any apparent smoke being present, press the test button to silence the Alarm for 10 minutes (as described in 12.1.5 above).
  • Page 36 12.2.3. Faulty smoke chamber In the unlikely event of the smoke sensing chamber becoming defective, the Alarm will give 2 short beeps with 2 yellow LED flashes every 32 seconds. The Alarm must then be replaced. If it is not convenient to replace it immediately, press the test button. The yellow LED will flash rapidly while the test button is held.
  • Page 37 Alarm should be replaced. 12.4. AudioLINK AudioLINK is an added feature available in the EIB650i series only. This feature allows an authorised person to download information from the Alarm through the use of a mobile App. For more information on using this feature,...

  • Page 38: Compatible Equipment

    13. Compatible Equipment 1. Hardwire Interconnection EIB600 series Smoke/Heat Alarms EIB605C, EIB605TYC, EIB603C and EIB605TYC BAALOC Brooks alarm locator 2. RadioLINK Interconnection EIB450 Smoke Alarm Controller EIB411RF Smoke alarm controller EIB605C & EIB603C fitted with RF module EIB605MRF EIB605TYC & EIB603TYC fitted with RF module EIB605MTYRF EIB650iC / EIB650iW &...
  • Page 39 Block E1 The crossed out wheelie bin symbol that is on your product indicates that this product should not be disposed of via the normal household waste stream. Proper disposal will prevent possible harm to the environment or to human health. When disposing of this product please separate it from other waste streams to ensure that it can be recycled in an environmentally sound manner.

  • Page 40: Contact Us

    14. Contact Us NSW - Head Office P.O. Box 7050 Silverwater NSW 1811 4 Pike Street Rydalmere NSW 2116 Ph: 02 9684 1466 Website: www.Brooks.com.au 9/71 Victoria Crescent, Abbotsford VIC 3067 Ph: 03 9879 5294 P.O. Box 101 Woodville SA 5011 729A Port Road, Woodville, SA 5011 Ph: 08 8347 0000 P.O.

This manual is also suitable for:
