- Page 1 Installation Manual Model 600A1 & 600UHD1 Moisture Sensor Kit for Large Square Balers Forage Harvester 600A1 & 600UHD1-19-INST 5/19...
- Page 2 DECLARATION OF APPLICATION OF ESSENTIAL REQUIREMENTS OF THE DIRECTIVE 2006/42/ EC OF THE EUROPEAN PARLIAMENT AND OF THE COUNCIL OF 17, MAY, 2006 AND OTHER RELEVANT EU DIRECTIVES: The Harvest Tec Hay Moisture Sensor Kit conforms with the Directive and other relevant EU directives.
-
Page 3: Table Of Contents
Installation Manual Table of Contents PAGE Introduction System Requirements Tools Needed Safety Safety Signs Installing the 600A1 & 600UHD1 Moisture Sensor Kit Mount the Dual Channel Processor (DCP) Installing Star Wheels – 600A1 Installing Star Wheels – 600UHD1 Wiring Installation – 600A1 Wiring Installation –... -
Page 4: System Requirements
System Requirements The Baler Processor must have Version 3.3 or higher. Tools Needed: - Standard wrench set - Side cutter - Standard socket set - Electric drill and bits - Standard nut driver set - Hammer & Center Punch Safety Carefully read all safety signs in this manual and on the moisture sensor kit before use. -
Page 5: Installing The 600A1 & 600Uhd1 Moisture Sensor Kit
Installing the 600A1 & 600UHD1 Moisture Sensor Kit Mounting the Dual Channel Processor (DCP) Locate the Dual Channel Processor (006-6671LS), four 5/16” x 1” hex bolts, flats, locks and nuts. Mark, and drill four 3/8” (9.525 mm) holes following the template shown below. The whip wire extension on the DCP should be facing down when attached to the baler. -
Page 6: Installing Star Wheels - 600A1
Installing Star Wheels – 600A1 The star wheel block has a plug on one side and a wire grommet on the other side. If there is interference or problems with the star wheel wires on one side of the block, exchange the wire grommet with the plug so the wire can exit the block on the opposite side. -
Page 7: Installing Star Wheels - 600Uhd1
Star Wheel Mounting – 600UHD1 The star wheels are to be mounted on top of the baler, just behind the knotters and under the walkway on both sides. The holes for the star wheel are precut. Remove the plate on top of the catwalk covering the triangle shaped access cutout. -
Page 8: Wiring Installation - 600A1
Terminator at this location see further instructions below. If your baler has the White Terminating Resistor you will need to attach the Pre 2012 AGCO Integration Harness (006-6650VAX) to the end of the Baler Interface harness (006-6650VC). Please contact Harvest Tec for this harness. -
Page 9: Wiring Installation - 600Uhd1
Wiring Installation – 600UHD1 Connecting to the Baler Harness Locate the communication harness (006-6650VAU) and the connection point shown (Left) on baler. Under the chamber locate the Active Terminator from the end of the baler harness. Labeled (LHR-C72 ISOBUS Term) It is located at the right rear corner of the baler frame. -
Page 10: Connecting The Star Wheels To Dcp
Connecting the Star Wheels to the DCP Locate the moisture harness (006-4640E2). Remove the four pan head screws on each star wheel and loosen the grommet. Insert the eye loop of the wire into the star wheel block and install on the end of the swivel. Leave a loop in the wire to allow the star wheel cover space to be reinstalled. -
Page 11: Connecting The Harnesses To The Dcp - 600Uhd1
Connecting the Harnesses to the DCP – 600UHD1 Star wheels Moisture harness 030-4641U 006-4640E2 006-6671LS Terminating resistor 006-5650Z 6 Pin Deutsch Baler Black Terminating Resistor 006-6650AU Power Harness 4 Pin Deutsch Power 6 Pin Delphi (LHR-C73) Baler Connection (LHR-C72 ISOBUS Term) Comm. -
Page 12: Parts Breakdown
600A1 Controls and Harnesses Ref # Description Part # Ref # Description 5/16” nuts Star wheel spacer 001-6707E 5/16” lock washers Star wheels 030-4641 5/16” flat washer Moisture harness 006-4640E2 10/24 x 5/8” PHS DCP cover 001-5650X Dual Channel Processor 006-6671LS 10/24 lock washers 5/16”... -
Page 13: Controls And Harnesses - 600Uhd1
600UHD1 Controls and Harnesses Ref # Description Part # Ref # Description Jiffy Clips 008-9018 Left Twine Diverter 001-4645 Moisture Harness 006-4640E2 Resistor (Green) 006-5650Z DCP Cover 001-5650X Processor (DCP) 006-6671LS UHD Integration Harness 006-6650VAU UHD Pwr Harness 006-6650AU UHD Baler Starwheel 030-4641U Terminator (Red) 006-6650Z... -
Page 14: Star Wheel Sensors - 600A1
006-4641B Star wheel block 006-4641A Electronic swivel 006-4642A Star wheel sensor 030-4641C Swivel insert w/ Ref # 10 Twine guard-left for Agco 001-4645H Snap ring (per side) 006-4641K Twine guard-Right for Agco 001-4644H Washer (per side) w/006-4641K 1-10 Star wheel assembly... -
Page 15: Warranty Statement
Harvest Tec Inc. Warranty and Liability Agreement Harvest Tec, Inc. will repair or replace components that are found to be defective within 12 months from the date of manufacture. Under no circumstances does this warranty cover any components which in the opinion of Harvest Tec, Inc. - Page 16 HARVEST TEC, INC. P.O. BOX 63 2821 HARVEY STREET HUDSON, WI 54016 PHONE: 715-386-9100 1-800-635-7468 FAX: 715-381-1792 Email: info@harvesttec.com...
