7 oPEratIoN

Make sure that specific warnings and cautions in Chapter 2 "Precautions" are carefully read, understood and applied!
A
B
Fig. 7.a Temperature probes
A Intake air from outiside
Exhaust air to outside
B
Supply air to inside
C
Extract air from inside
D
Fig. 7.b CTRL-DSP
E DATE: shows the current date
F
MODE: shows the operation mode
G
SPEED: shows the selected speed
H TIME: shows the time
FILTER ALARM: shows that filters need to be maintained/replaced
I
BOOST: shows that BOOST speed is activated
J
K
BOOST KEY: to manually activate the BOOST speed
L FILTER RESET KEY: to reset the Filter Alarm
ESC key: to exit and go back to the previous menu
M
OK key: to enter the selected menu
N
to go DOWN with the menu selection
O
T21
INTAKE
T12
EXHAUST
E
R
S
Q
P
WARNING
F
G
H
T U V W X
O
N L
M
to go UP with the menu selection
P
Q
to power off the ventilation unit
R shows ERROR ALARM - see point 7.3 to check the type of error
S
this symbol shows if the "bypass" or "free cooling" function is active
this symbol shows that ANTI-FROST is active
T
this symbol shows that the IAQ input is activated, i.e.CO2
U
this symbol shows that the HY input is activated.
V
this symbol shows that NIGHT MODE is activated
W
X this symbol shows that Heating output is activated
T11
D
EXTRACT
T22
C
SUPPLY
I
J
K
