Summary of Contents for Security Tronix ST-D540IRVP49-S
- Page 1 INSTALLATION MANUAL ST-D540IRVP49-S 4.5” Vandalproof Infrared Dome Color Camera...
- Page 2 65 feet. The camera’s varifocal lens allows focal length adjustment from 4mm to 9mm allowing an optimal field of view. The ST-D540IRVP49-S’ size and packaging allow it to be easily and discretely installed. Its rich color, high definition, stability and resistance to jamming make it attractive for CCTV security applications.
- Page 3 INSTALLATION AND OPERATION This symbol is intended to alert the user to the presence of important operating and maintenance (servicing) instructions. This symbol is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electrical shock.
- Page 4 4. WIRING CONNECTIONS a. Connect the power supply’s DC plug to the camera’s power outlet. b. Connect the camera to the monitor with a 75Ω coaxial video cable. c. Connect power supply’s AC plug to a suitable AC power outlet. d.
