ADDITIONAL BACKUP NOTES
Once the selections have been entered as listed above; click Add. Data applicable to the selections
will now appear in the main screen.
Clicking start will commence the backup operation and replace the capacity requirement with
information on the estimated time to complete the process.

Main Menu Layout

Main Menu Sub Menu
Record Config
Playback
Backup
Alarm Motion
Video blind
Video loss
Alarm input
Alarm output
System General Config
Configuration
Encode Config
Network Config
Net Service
GUI display
PTZ Config.
Serial port Config
Tour
Management Hard disk
tools management
User management
Online user
TV adjust
Auto maintenance
Restore
System info Hard disk info
Code stream stats
Log info
Edition info
Shut down
Function
Set the recording configuration, recording type, recording time section
Set recording look-up, recording play, video file storage
Detect or format backup devices, backup selected files
Set motion detect alarm channel, sensitivity, area, defending
time detection section, alarm output, screen hint, recording, PTZ, patrol
Set camera mask alarm channel, sensitivity, defending time, section, alarm
output, screen hint, recording, PTZ, patrol
Set video loss alarm channel, defending time, section, alarm output, screen hint,
recording, PTZ, patrol
Set alarm input channel, equipment type, defending time section, alarm output,
screen hint, recording, PTZ, patrol
Set alarm mode: configuration, manual, shut down
Set system time, data format, language, hard configuration disk full time
operation, machine number, video format, output mode, summertime, stay time
Set main (assistant) coding parameter: code mode, resolving ability, frame rate,
code stream control, image quality type, code stream value, frame between
value, video/audio enable
Set basic network parameters, DHCP and DNS parameters, network high speed
download
PPPOE, NTP, Email, IP purview, DDNS parameter
Set channel name, preview hint icon state, transparency, cover area, time title,
channel time fold
Set channel, PTZ protocol, address, baud rate, date bit, stop bit, check
Set serial port function, baud rate, date bit, stop (RS232) bit, check
Set patrol mode and interval time
Set appointed hard disk as read-write disc, read-only disc or redundant
disc, clear data, resume date and so on
Modify user, team or password. Add user or team. Delete user or team.
Break the connection with the already login user. Lock the account after, break
until booting up again.
Adjust TV upside, downside, nearside, starboard distance
Set automatic reboot system and automatic deleting files
Resume setup state: common setup, code setup, recording setup, alarm setup,
network setup, network service, preview playback, serial port, setup, user
management
Display hard disk capability and recording time
Display code stream information
Clear all log information according to the log video and time
Display edition information
Logout, shut down or reboot
