Fiilex P3 COLOR User Manual

Safety Instructions

• DO NOT look into the light source. Be cautious of the high-intensity beam.
• DO NOT disassemble P3 Color. This will void the warranty.
• DO NOT install P3 Color in damp or wet locations.
• DO NOT obstruct the fixture's air vents.
• Use safety cable (not included) when rigging P3 Color overhead.
• Only use Fiilex approved power supply and accessories. Failure to do so may damage the fixture.
• Shields, lenses or ultraviolet screens shall be changed if they have become visibly damaged to such an extent that their
effectiveness is impaired, for example by cracks or deep scratches.
• The lamp shall be changed if it has become damaged or thermally deformed.
• The luminaire is intended for professional use only.

Parts Diagram

6 5
7
8
1. 4 Leaf Barndoor
2. V-Mount
3. Barndoor Slot
4. Accessory Lock
5. Barndoor Holder
6. Side Air Vents
7. Yoke Knob
User Guide
4 3 2 1
8. DMX Cable
9. USB Type-C Port
(For updating firmware & 5V/1A)
10. Accessory Lock Release
11. Intensity Control Knob
12. OLED Display
13. Menu Knob
9 10 11 12
18
19
17
14. Light Control Output Jack
15. DC Power Input Jack
16. ON/OFF Button
17. Light Stand Adapter
18. Power Adapter
19. Yoke
13
14
15
16
