Pro Pool-XR Deep

Draft Lift

PART #: F-004XRDD-NA (without anchor)

US PATENT NUMBER: [D507,769 S] [7,249,386 B2]

350 LB. [159 kg] MAXIMUM WEIGHT CAPACITY

MANDATORY – LEAVE THIS MANUAL WITH LIFT OWNER

Read & follow all instructions

Lift safety can only be ensured if the lift is installed

and operated according to these instructions

NEVER permit children to play on or around the lift

Do not allow children to use the lift without adult supervision

NEVER apply direct water pressure to the electronics

NEVER use the lift with a dry pool

For safety reasons, NEVER swim alone

9889 Garrymore Ln

Missoula, MT 59808

SAVE a copy of these instructions

888-687-3552 | +1-406-549-0769

aquacreek.com

Revised 12/3/15

Table of Contents

Need help?

Do you have a question about the Pro Pool-XR Deep Draft and is the answer not in the manual?

Questions and answers

Summary of Contents for Aqua Creek Products Pro Pool-XR Deep Draft

Page 1 NEVER use the lift with a dry pool For safety reasons, NEVER swim alone 9889 Garrymore Ln Missoula, MT 59808 SAVE a copy of these instructions 888-687-3552 | +1-406-549-0769 aquacreek.com Copyright © 2015 Aqua Creek Products All Rights Reserved Revised 12/3/15...
Page 2: Table Of Contents
BATTERY MAINTENANCE CARE FOR YOUR LIFT 12-13 PRO POOL-XR DEEP DRAFT LIFT OPERATING INSTRUCTIONS 14-15 TROUBLESHOOTING GUIDE PRO POOL-XR DEEP DRAFT PARTS LIST SEAT & ACTUATOR ASSEMBLY PARTS LIST WARRANTY Copyright © 2015 Aqua Creek Products All Rights Reserved Revised 12/3/15...
Page 3 If any damage occurred in transit, Aqua Creek Products LLC must be notified within three days of receipt of unit. Proper installation cannot be overstressed, as an improper installation voids Aqua Creek’s warranty and may affect the safety of the user.
Page 4 Installation: ADA Requirements ADA REQUIREMENTS: The Pro Pool-XR Deep Draft Lift is completely ADA Compliant when installed correctly. The installation must meet the following requirements: • Clear Deck Space Dimensions (see FIGURE 1) • Lift anchors installed between 22 1/2” - 38” from the pool edge •...
Page 5: Anchor Installation: Core-Drill Retro-Fit
BOTTOM of the jig-plate (see diagram to left). IMPORTANT: Use the enclosed packet of anti-seize lube on the threads of the hardware to prevent the hardware from seizing in the anchor inserts. continued on page 6 Copyright © 2015 Aqua Creek Products All Rights Reserved Revised 12/3/15...
Page 6 The anchor TEST-FITTING AND TO HOLD ANCHORS IN PLACE AS EPOXY jig-plate can be recycled or used CURES for installing a second set of anchors in another location. FIGURE 4 Copyright © 2015 Aqua Creek Products All Rights Reserved Revised 12/3/15...
Page 7: Anchor Installation: Saw-Cut Retro-Fit
*SETBACK DIMENSIONS ARE FOR FLAT DECK APPLICATIONS. FOR SLOPED DECKS OR OTHER FEATURES, CONTACT AQUA CREEK BEFORE INSTALLATION. Be sure to use anti-seize on all hardware. FIGURE 6 Copyright © 2015 Aqua Creek Products All Rights Reserved Revised 12/3/15...
Page 8: Anchor Installation: New Construction
(Do not tie into the bond beam). The rest of the pool deck can be a typical 4” thick or thickened per local code requirements. Bond rebar or reinforcing mesh grid according to local requirements and also bond the anchor system to the rebar/mesh grid. Copyright © 2015 Aqua Creek Products All Rights Reserved Revised 12/3/15...
Page 9: Pro Pool-Xr Deep Draft Lift Assembly Instructions
Attach seat belt to the seat as shown in the figure to the right. FOR EASY ACCESS Install the Pro Pool-XR Deep Draft pool lift onto the three (3) anchors using the supplied 1/2 x 1-1/2” stainless steel hex bolts and 1/2” stainless steel flat washers. Apply anti-seize to all hardware to prevent lift from seizing in the anchor.
Page 10: Battery Maintenance
Scotch Bright pad and then apply dielectric grease (supplied with lift) as shown in the figure below. Clean with alcohol and a cotton swab and apply dielectric grease to terminals Copyright © 2015 Aqua Creek Products All Rights Reserved Revised 12/3/15...
Page 11 Use white epoxy paint to touch up. Apply wax to finish. For service and/or replacement parts contact Aqua Creek Direct at Toll free: (888) 687-3552 Copyright © 2015 Aqua Creek Products All Rights Reserved Revised 12/3/15...
Page 13 Pressure to the Down Arrow Return to Submerged Lift Raise Lift by Applying Seat & Secure Lapbelt Pressure to the Up Arrow Release Lapbelt, Raise Armrests, & Exit Lift Seat Copyright © 2015 Aqua Creek Products All Rights Reserved Revised 12/3/15...
Page 14: Troubleshooting Guide
Check the ends of the cords for corrosion or damage. The cord plugs should be recessed into the outlet. You should feel them pop into place when they are correctly inserted. Copyright © 2015 Aqua Creek Products All Rights Reserved Revised 12/3/15...
Page 15 Note: the lift will not retract if the battery is not fully charged or if the control box is not working. The emergency button only overrides the remote handset. Copyright © 2015 Aqua Creek Products All Rights Reserved Revised 12/3/15...
Page 16: Pro Pool-Xr Deep Draft Parts List
BOLT, 3/8 X 1 3/4 SHOULDER RER50X100MM CAP, PLASTIC, RECTANGLE, 2” X 4” SHOULDER, 5/16-18 THREAD FLAT WASHER, 3/8 SS WASHER, FLAT, 3/8, 316 SS F-45ACB-C COVER, ACTUATOR, WATER RESISTANT Copyright © 2015 Aqua Creek Products All Rights Reserved Revised 12/3/15...
Page 17 NUT, 316 SS, NYLOCK, 5/16”-18 HOSE CLAMP, 1 3/4 SS HOSE CLAMP, 1 3/4” SS FLAT WASHER, #10 WASHER, FLAT, #10 SAE, 316 SS SQR-1-10-14 CAP, PLASTIC, 1”X1” SQUARE Copyright © 2015 Aqua Creek Products All Rights Reserved Revised 12/3/15...
Page 18 (ITEM #’s F-004PLB-XR, F-004PLB-XRNA, F-004PLB-XRNA-R) Aqua Creek Products, LLC (a.k.a. Aqua Creek) also warrants to the original end user purchaser that products manufactured by Aqua Creek, when properly installed in accordance with assembly and installation instructions, and properly used and maintained, shall be free from defects in...
