INSTALLATION AND OPERATING INSTRUCTIONS
PATRIOT-AT
PART NUMBER: F-12PPL-HD-AT1
450 LB. [204 kg] MAXIMUM CAPACITY (PRO POOL LIFT)
MANDATORY – LEAVE THIS MANUAL WITH LIFT OWNER
9889 GARRYMORE LANE
MISSOULA, MT 59808
1-888-687-3552
FAX: 406-549-2602
1.
READ AND FOLLOW ALL INSTRUCTIONS. LIFT SAFETY CAN ONLY BE ENSURED IF THE
LIFT IS INSTALLED AND OPERATED PROPERLY – AS PER INSTRUCTIONS.
2.
WARNING- TO REDUCE RISK OF INJURY, DO NOT PERMIT CHILDREN TO USE THIS
PRODUCT UNLESS THEY ARE CLOSELY SUPERVISED AT ALL TIMES.
3.
WARNING- DO NOT PERMIT CHILDREN TO PLAY ON THIS PRODUCT.
4.
WARNING- NEVER APPLY DIRECT WATER PRESSURE TO ELECTRONIC COMPONENTS.
5.
WARNING – DO NOT OPERATE THIS LIFT IF THE DECK-TO-WATER DISTANCE IS OVER 12".
6.
WARNING – DO NOT OPERATE THIS LIFT UNDER LOAD IN A DRY POOL (NO WATER).
7.
WARNING – DO NOT OPERATE THIS LIFT WITHOUT THE 10 WEIGHT-PLATES INSTALLED.
8.
WARNING – FOR SAFETY REASONS YOU SHOULD NEVER SWIM ALONE!
9.
SAVE A COPY OF THESE INSTRUCTIONS.
©AQUA CREEK PRODUCTS, 2012
TM
PORTABLE LIFT
U.S. PATENT NUMBER: 5,790,995
WARNING
IMPORTANT SAFETY INSTRUCTIONS
JUNE 2012

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PATRIOT-AT F-12PPL-HD-AT1 and is the answer not in the manual?

Questions and answers

Related Manuals for Aqua Creek Products PATRIOT-AT F-12PPL-HD-AT1

Summary of Contents for Aqua Creek Products PATRIOT-AT F-12PPL-HD-AT1

  • Page 1 WARNING – DO NOT OPERATE THIS LIFT UNDER LOAD IN A DRY POOL (NO WATER). WARNING – DO NOT OPERATE THIS LIFT WITHOUT THE 10 WEIGHT-PLATES INSTALLED. WARNING – FOR SAFETY REASONS YOU SHOULD NEVER SWIM ALONE! SAVE A COPY OF THESE INSTRUCTIONS. ©AQUA CREEK PRODUCTS, 2012 JUNE 2012...
  • Page 2 PATRIOT-AT PORTABLE LIFT TABLE OF CONTENTS PAGE DESCRIPTION ADA INSTALLATION GUIDELINES PATRIOT-AT PORTABLE PACKING LIST PATRIOT-AT PORTABLE ASSEMBLY INSTRUCTIONS FIXING-ANCHOR INSTALLATION INSTRUCTIONS INSTALLING THE FIXING BOLT TRANSPORTING & USING THE PATRIOT-AT PORTABLE 24V BATTERY OP & INSTALL INSTRUCTIONS BATTERY MAINTENANCE PRO POOL-AT LIFT OPERATING INSTRUCTIONS CARE OF YOUR LIFT...
  • Page 3 INSTALLATION: ADA GUIDELINES ADA REQUIREMENTS: The PATRIOT-AT portable lift is designed and manufactured to be 100% ADA compliant. But for the installed lift to be 100% compliant the installation must meet the requirement for CLEAR DECK SPACE as shown in the diagram to the left. To be compliant, install the lift at 16 inches [406mm] minimum from the pool edge to the centerline of the seat, and make sure the deck has the required CLEAR DECK SPACE as shown.
  • Page 4 THE PATRIOT-AT PORTABLE LIFT WARNING 1. NEVER OPERATE THIS LIFT IF THE POOL DECK TO WATER LEVEL EXCEEDS 9” 2. BEFORE OPERATING THE LIFT THE BALLAST TANK MUST BE FILLED AS PER THESE INSTRUCTIONS. (SEE PAGE 5). 3. THE 24V BATTERY WILL ARRIVE UNCHARGED FOR SAFETY. CHARGE THE BATTERY FOR 24 HOURS BEFORE INITIAL USE.
  • Page 5 PATRIOT-AT PORTABLE - ASSEMBLY INSTRUCTIONS 1. The BALLAST TANK needs to be filled with sand to make the lift stable during usage. This will require twelve (12) 50lb bags of all-purpose sand, or equivalently 600lbs [272kg] of medium-grain sand to fill to the required weight. 2.

  • Page 6: Fixing-Anchor Installation Instructions

    FIXING-ANCHOR INSTALLATION INSTRUCTIONS: TOOLS REQUIRED: CORE-DRILLING RIG TAPE MEASURE 1-1/4” DIAMETER CORE-DRILL MARKING PEN STEP 1] Use the diagram below to determine the location of the FIXING ANCHOR. Make sure to allow for the clear deck space as shown. STEP 2] Mark the location for the 1-1/4” x 4” deep anchor hole. Drill a ½” diameter, 4” deep hole at the marked location.

  • Page 7: Installing The Fixing Bolt

    INSTALLING THE FIXING BOLT: When the FIXING-BOLT is utilized to ensure proper placement of the portable lift the following procedure should be used when placing the unit in position on the deck. STEP 1: Roll the portable cart over the installed anchor. Look straight down through the DOCKING BAR to align the anchor with the DOCKING BAR.

  • Page 8: Modes Of Operation

    TRANSPORTING & USING THE PATRIOT-AT LIFT: The Patriot-AT Lift has been designed to make transporting and using the lift as simple as possible. The design makes the lift 100% ADA compliant by providing two separate operating modes; one for transporting the lift and one for using it. DO NOT ATTEMPT TO USE THE LIFT WHILE IN THE TRANSPORT MODE! MODES OF OPERATION: 1] TRANSPORT MODE: In this mode the lift is on top of the portable cart and the...
  • Page 9 RETURNING THE LIFT TO TRANSPORT MODE: To move the lift after use, reverse the steps above as follows: 1) Tilt the lift back and down until the lower wheels are at the cart level. 2) Roll the lift back and onto the cart. Roll all the way back to the end of the guide frames (see close-up detail).
  • Page 10 24V BATTERY SYSTEM OPERATING AND INSTALLATION INSTRUCTIONS WALL MOUNT CHARGER CONTROL BOX 24V SEALED BATTERY & HANDSET REMOTE The Pro Pool-AT Lift comes with a 24v sealed rechargeable battery, wall mount charging unit (with mounting bracket), control box, and a waterproof handheld controller. The control box is mounted to the Pro Pool-AT Lift has a plug-in socket for both...

  • Page 11: Battery Maintenance

    BATTERY MAINTENANCE 1. RECHARGE THE BATTERY AS OFTEN AS POSSIBLE. The battery power unit is a sealed lead acid battery pack. Frequent recharges will prolong the battery life and maintain a high cold amperage capacity. 2. Do NOT expose the battery to freezing temperatures. 3.
  • Page 12 PRO POOL LIFT OPERATING INSTRUCTIONS: NOTE: CHECK ALL NUTS & BOLTS FOR TIGHTNESS AND FOR WORN PARTS BEFORE EACH USE. NEVER OPERATE THE LIFT WITH THE ARMRESTS FLIPPED UP. WARNING! FOR SAFETY REASONS YOU SHOULD NEVER SWIM ALONE! The Pro Pool Lift should always be in the full up or deck position before a user attempts to transfer into the chair.
  • Page 13 BEFORE using the PATRIOT-AT LIFT. You can call our customer service at 1-888-687-3552 to order any parts. 2. Aqua Creek Products, LLC lifts shall be grounded per local codes. 3. At least ONCE A WEEK, the PATRIOT-AT LIFT must be cleaned with fresh water.
  • Page 14 If the lift is used MONTHLY follow the same steps as above. Also check the nuts and bolts to make sure they are securely fastened (this is always a good idea, no matter how often or infrequently the lift is used). Also make sure to store the battery on the charger and not on the lift.

  • Page 15: Troubleshooting Guide

    TROUBLESHOOTING GUIDE Before troubleshooting make sure the battery is fully charged. If the lift doesn’t move when the handset button is pressed: When you can’t get the lift to move check the following things: 1. Make sure the battery is fully charged: A.
  • Page 16 If the battery is fully charged and the lift is not moving then: 2. Check all cords: A. Check that the cords are properly plugged in. Start by unplugging the remote and the actuator cord from the control box. Once these cords are removed check the ends for corrosion or damage.
  • Page 17 If the lift stops moving over the water and is stuck: 4. Then try pushing the emergency button: A. If the lift gets stuck out over the water use a pen or pencil tip and stick it into the emergency button on the front of the control box to retract the lift.
  • Page 18 PATRIOT-AT INTEGRATED LIFT: PARTS LIST ITEM NO. QTY. PART NUMBER DESCRIPTION 1 RAT-200-00 REBAL-AT ROLL-BASE ASSY 1 PPF-200-10 RANGER-AT FRAME ASSY 1 A-2012ARM-PS PORTABLE CHAIR ARM ASSY 1 A-2012SRS PRO POOL SEAT SUPPORT 1 L-2014FBL-PAT-R1 RANGER-AT CONTROL ARM 1 WM-A-8980PPAF-AT PRO POOL-AT ACTUATOR FRAME 1 SA-0904CA 18"...

  • Page 19: Seat Assembly: Parts List

    SEAT ASSEMBLY: PARTS LIST ITEM NO. QTY PART NUMBER DESCRIPTION 1 P-900 18" ROTOMOLDED CHAIR, GREY 1 P-1208HSB HANDSET BRACKET, HDPE 2 P-2100ART ARMREST TUBE, 304 SS 2 RUBBER FINGER GRIPS RUBBER FINGER GRIP, BLACK 1 F-38SB 2" WIDE SEAT BELT, BLACK 1 SCREW#12X1PHSMS #12 X 1"...
  • Page 20 PATRIOT-AT PORTABLE CART: PARTS LIST ITEM NO. QTY. PART NUMBER DESCRIPTION 1 P-0138PBP-REVA2 PORTABLE CART BASEPLATE 1 RATWM-120-00 PATRIOT-AT CART WLDMT A 1 RATWM-130-10 PATRIOT-AT CART WLDMT B, 2-ANC 1 P-985B PATRIOT-AT BALLAST TANK/COVER 1 RAT-110-00 PATRIOT-AT CART TRAY 2 A-0138GFT-REVC GUIDE FRAME ASSY, REVISION C 2 P-0138PCPS-REVB PORTABLE CART PLASTIC SLIDE...
  • Page 21 Patriot-AT Portable Lift Aqua Creek Products lifts have a Limited Lifetime Warranty on the frames, not including the powder coat finish. Aqua Creek Products, LLC (a.k.a. Aqua Creek) also warrants to the original end user that all non-frame components manufactured by Aqua Creek, when properly installed in accordance with assembly and installation instructions, and...
