OPERATOR INSTRUCTIONS
6.3.4

Pallet Grip

Pallet Grip locks the load to the pallet.
It includes a groove roller and a tilting roller.
As the FDS lowers, Pallet Grip engages and makes
a cable of film.
The cable attaches below the top boards of the
pallet to lock the load to the pallet.
Groove Roller
The Groove Roller rolls the film into a cable when
the FDS is at the bottom of the load.
Adjust the roller to increase, decrease the quantity
of film that makes the cable.
It sets the height of the cable on the pallet.
Tilting Roller
The Tilting Roller moves the cable of film down on
the pallet.
The actuator is adjustable to increase, decrease the
angle of the roller.
