6.1

Sequence of Operation

The sequence starts with a load on the turntable.
1. Move the Main Disconnect switch to the On position.
2. Reset the E-stop.
3. Push Reset.
4. Refer to Section 6.5.2 and make a new a profile.
5. Select a Profile.
6. Push Film Assist.
7. Pull the film and attach it to the load.
8. Push Start.
9. The turntable turns and the FDS moves up.
10. The film pre-stretches and is applied to the load.
11. The load height sensor senses the top of the load and the FDS stops to apply the set number of
layers.
12. The FDS lowers to wrap the bottom of the load.
13. Pallet Grip engages and makes a cable of film on the bottom edge of the film.
14. The tilting roller engages and applies the cable of film to the pallet.
15. On the last rotation of the turntable, the FDS raises and disengages the Pallet Grip.
16. The Auto Film Cut-off engages and the pre-stretch motor stops to break the film.
