Fig. 4:
Mounting with
mounting plate
SETLA M5 and
spacer plates/
rebate gap
Mounting
a b
A
A
B
SELTA M5
(optional)
A -A
c
1 SETLA M5
2 Spacer plates
3 Escape door locking system 352M
4 Lock counterpart
B - B
B
3 4
min. 2
16
d e
1 2
max. 4,5
6
1
