Nola
Installation Guide
For Model:
NOL52
E192641
net weight of fan: 20.83 lb (9.45 kg)

Table of Contents:

pgs. 9 - 10
Warranty. pg. 12
page 1
READ THESE INSTRUCTIONS AND
SAVE THEM FOR FUTURE USE
PRINTED IN CHINA
