2. MCU programming

The host MCU can be programmed and debugged over the 2x5 pin header
(1), labeled as JTAG/SWD. This header allows an external programmer
(preferably CODEGRIP or mikroProg) to be used.
N O T E Before usage, please check if the programmer pinout and the 2x5
pin header pinout are compatible. Based on the used programmer/
debugger tool pinout, a coresponding addapter might be needed.
Programming the microcontroller can also be done by using the bootloader
which is preprogrammed into the device by default. All the informations
about the bootloader software can be found on the following page:
www.mikroe.com/mikrobootloader
1
CLICKER 4 for STM32 U S E R M A N U A L
Figure 2: Clicker 4 for STM32
with CODEGRIP connected
