Clicker 4 for STM32 is a compact development board
designed as a complete solution, you can use it to quickly
build your own gadgets with unique functionalities.
Featuring a STM32F767BI MCU, four mikroBUS
Click boards connectivity, power managment, and more, it
™
represents a perfect solution for the rapid development of
many different types of applications.
At its core, there is a STM32F767BI MCU, a powerful
microcontroller by STMicroelectronics, based on the high-
performance Arm® Cortex®-M7 32-bit RISC core operating
at up to 216 MHz frequency.
It provides sufficient processing power for the most
demanding tasks, allowing Clicker 4 to adapt to any specific
application requirements.
Besides two 1x23 pin headers, four improved mikroBUS
sockets represent the most distinctive connectivity feature,
allowing access to a huge base of Click boards
a daily basis.
sockets for
™
Each section of Clicker 4 is clearly marked, offering an
intuitive and clean interface. This makes working with the
development board much simpler and thus, faster.
The usability of Clicker 4 doesn't end with its ability to
accelerate the prototyping and application development
stages: it is designed as a complete solution which can be
implemented directly into any project, with no additional
hardware modifications required. Four mounting holes
[3.2mm/0.126"] at all four corners allow simple installation
by using mounting screws. For most applications, a nice
stylish casing is all that is needed to turn the Clicker 4
development board into a fully functional, custom design.
™
, growing on
™
