Industrial Electronic Devices
CHARACTERISTICS:
The HD67D01-B2 is a LoRaWAN / Modbus Master Converter.
It allows the following characteristics:
Electrical isolation between Modbus and Power Supply;
Mountable on 35mm Rail DIN;
Wide power supply input range: 12...35V DC and 8...24V AC;
Wide temperature range: -40°C / 85°C [-40°F / +185°F].
CONFIGURATION:
You need Compositor SW67D01 software on your PC in order to perform the following:
Define the parameter of Modbus line;
Define the parameter of LoRaWAN line;
Define the list of LoRaWAN messages in uplink and downlink to the LoRaWAN gateway;
Define the Modbus registers to read and write from/to the Modbus Slaves;
Update the device.
ADFweb.com S.r.l.
User Manual LoRaWAN / Modbus Master
Document code: MN67D01_ENG
Revision 1.000
Page 7 of 31
