SET COMMUNICATION:

By Pressing the "Set Communication" button from the main window for SW67D01 (Fig. 2)
the window "Set Communication" appears (Fig. 3).
The means of the fields for the "LoRaWAN" section are:
In the field "RF Band" the wireless band used for LoRaWAN communication is
defined;
In the field "Network Type" the type of LoRaWAN network is defined;
If the field "Adaptive Data Rate" is checked, the converter will enable the ADR
functionalities to select the best data rate to be used in relation to the environmental
conditions;
In the field "Data Rate" the data rate for LoRaWAN communication is defined;
In the field "Transmission
In the field "Max Payload
messages is defined (fixed in relation to the data rate selected);
In the field "JoinEUI" the ID of the application server is defined;
In the field "Activation
is defined;
In the field "Device Address" the device identifier (DevEUI) is defined (only for ABP
method);
In the field "Network Session
LoRaWAN gateway (NwkSKey) is defined (only for ABP method);
In the field "Application Session
payload (AppSKey) is defined (only for ABP method);
If OTAA method is selected, in the field
dynamic activation of the converter in the LoRAWAN network is defined.
ADFweb.com S.r.l.
Type" the type of LoRaWAN communication is defined;
Size" the maximum dimension of the LoRaWAN
Method" the method used to join into a LoRaWAN network
Key" the key used for the communication with the
Key" the key for encryption and decryption of the
"Application
User Manual LoRaWAN / Modbus Master
Document code: MN67D01_ENG
Key" the secret key for the
Revision 1.000
Figure 3: "Set Communication" window
