MANUAL FOR
LC7TT novo
EN

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LC7TT novo and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Monark LC7TT novo

Summary of Contents for Monark LC7TT novo

  • Page 1 MANUAL FOR LC7TT novo...

  • Page 3: Table Of Contents

    Pulse settings �������������������������������������������������������������������������������������� 22 Settings general ���������������������������������������������������������������������������������� 23 Connect Bluetooth SMART heart rate monitor ������������������������������������ 24 Calibration  ��������������������������������������������������������������������������������������������������� 26 Testing with LC7TT novo  ���������������������������������������������������������������������������� 28 Troubleshooting guide  ������������������������������������������������������������������������������� 30 Service  ��������������������������������������������������������������������������������������������������������� 32 Warranty ���������������������������������������������������������������������������������������������� 32 Service check and Maintenance ��������������������������������������������������������� 32 Batteries ����������������������������������������������������������������������������������������������...
  • Page 4 Since the early 1900s, Monark bikes have been living proof of precision, reliability, strength and service. Those are the reasons why we now are the world leader in ergometer bikes and the market leader in Scandinavia in transport bikes.
  • Page 5 LC7TT novo is also prepared for additional equipment, channels behind the covers make it easy to install different equipment for different needs. LC7TT novo is a great bike as it is, with additional equipment, it can be even better.

  • Page 6: Product Information

    If you replace the original power adaptor, the Width 640 mm replacement must be CE marked or equivalent. It Height LC7TT novo 1265 mm (max at display) must also have the correct polarity and voltage, and Height 1240 mm (max at saddle) have a capacity of at least 90 W.

  • Page 7: Settings

    100 mm in the frame. This is marked with Initial operation “MAX” on the stem. Each LC7TT novo is calibrated at the factory. The user can always verify this by performing the mechanical NOTE! calibration of the pendulum. See section "Calibration You have to get off the bike when you adjust the pendulum".

  • Page 8: Overview

    2) Scale for vertical adjustment of saddle 3) Knob for horizontal adjustment of handlebar and display 4) Scale for vertical adjustment of handlebar 5) Monark novo display unit 6) Power switch with LED 7) Screw for adjustment scale 8) Scale...

  • Page 9: Operating Instruction

    ANT+ or Bluetooth SMART technology. Monark's unique construction. More information is available in section "Monark New on LC7TT novo is that you can control the bike novo display unit". from the shifters on the handlebar and the display...

  • Page 10: Validation

    Checking the pulse function On LC7TT novo the heart rate is displayed in Monark novo display unit. The heart rate can also be displayed in other external device. While the patient rests, with the chest belt on, compare...

  • Page 11: Validation Of Force

    Validation of force Start Monark Test Software (it is available for free download from our web site: www.monarkexercise. se) and select a test programme from the menu "Test". In the dialogue box that opens is a box showing the braking force in Newton, see Fig: Force and HR display.

  • Page 12: Shifters On The Handlebar

    The basic principle is that you change in large steps on the left side and in small steps on the right side. How big stages is set in Monark Test Software (MTS). In MTS, you can also change if you prefer to adjust the workload with large steps on the right side or small steps on the left side instead.

  • Page 13: Monark Novo Contol Unit

    No tests can be performed at Monark novo display unit, then you must connect your bike to a PC, via the Monark novo control unit, and use a special test software. A suitable one is available to download from our website: www.monarkexercise.se.

  • Page 14: Communication Protocol (Command Type)

    Command type "0" is default for both of the free ports. As default the baud is 4800, but can be changed by external control. The protocol is used by Monark Exercises softwares and some external controllers that are prepared to fully benefit from the advanced capabilities of the bike.

  • Page 15: Set Commando Type For The Rs232 Port

    Set commando type for the RS232 port Monark test software When power is turned on to the bike gives an Monark test software is available for free download indication of what command type the RS232 port is from our website: www.monarkexercise.se. If you set to.

  • Page 16: Monark Novo Display Unit

    Via the display, you can perform manual training with full precision and performance! With Monark novo display unit, you can control the bike via the touch screen. The display shows the current rpm, time, power and pulse (if any heart rate monitor is used).

  • Page 17: Stop / Pause Training

    Average workload Average speed Average heart rate Average rpm Max. workload Max. rpm Max. heart rate Max. power Max. speed Min. power Min. speed Min. workload Min. rpm Min. heart rate End heart rate Calories Total time Total distance LC7TT novo...

  • Page 18: Workload Control

    Calculation l / min: If you press "Locked mode" in the view "Set unit" Monark novo display unit uses a formula to calculate you lock the display to show only the current rpm at different workloads.

  • Page 19: Menu

    1, when you press the arrow down decreases the value from 9. At the same time, the value that appears above "home" is changed to show the value you set. Press, increase value (1, 2, 3...) Press, decrease value (9, 8, 7...) LC7TT novo...
  • Page 20 The time in the display will count down to zero. "Target bar" appears in the display. Home Press, increase value (1, 2, 3...) Press, decrease value (9, 8, 7...) 10 hours 1 hours 10 min 1 min Home Start Step back LC7TT novo...
  • Page 21 Average workload Average speed Average heart rate Average rpm Max. workload Max. rpm Max. heart rate Max. power Max. speed Min. power Min. workload Min. speed Min. rpm Min. heart rate End heart rate Calories Total time Total distance LC7TT novo...

  • Page 22: Pulse Settings

    Fig: Moistening the electrodes If you have connected to an ANT+ heart rate monitor it says "connected" at "ANT+ status:" and the current heart rate is displayed at "Pulse". The images above are used with permission of Polar Sweden. LC7TT novo...

  • Page 23: Settings General

    0 = indicator inactivated 1 = maintenance service Home completed 3 = maintenance service recommended Commandtype USB: Command type USB port Commandtype RS232: Command type RS232 port Baudrate USB: Data transfer rate USB port Baudrate RS232: Data transfer rate RS232 port LC7TT novo...

  • Page 24: Connect Bluetooth Smart Heart Rate Monitor

    This can be done in Monark novo display unit (further only one heart rate monitor or there may be several information in section "Monark novo display unit") within the range of the receiver (10-15 m).
  • Page 25 Monark Exercise AB has tested several belts, both example Polar belts. There are many free applications of famous brands and so-called "no-name". As long...

  • Page 26: Calibration

    New calibration automatically replaces the old. Calibration pendulum All LC7TT NOVO are calibrated in the factory, but a calibration of the pendulum can still be done to verify this. If so, please do the following. Open the front cover. Check that the brake belt (3) is loose.
  • Page 27 This is done by pressing down the pointer into the groove on the scale at each kp value. It is also important to keep left the pendulum at each point until the beep stops before moving to the next position. Fig: 0 kp. LC7TT novo...

  • Page 28: Testing With Lc7Tt Novo

    Testing with LC7TT novo Test person enforcement The versatility of the LC7TT novo enables it to be The bike performs automated tests virtually by itself, utilized in a variety of testing environments. The requiring minimal intervention by the test operator.
  • Page 29 Interpretation should therefore be made more carefully with an understanding of the possibility of errors in the methodology. LC7TT novo...

  • Page 30: Troubleshooting Guide

    Check that the pedal speed is higher than 30 RPM. No workload is put on if the actual pedal speed is lower than 30 RPM. See in Monark test software: - ’Monark Ergomedic’ - ’Service program...’ - ’Service Setup...’ - ’Pedal measurement’. The default setting is 30 RPM but can be adjusted to the desired value.
  • Page 31 There’s a click noise and a squeak • Loosen the chain. noise when pedalling Problems with the computer software • Describe the problem in an email (write in English) and send it to the software developer HUR Labs support, support@hurlabs.com. LC7TT novo...

  • Page 32: Service

    EC Directive 1999/44/EC. In short, pedalling (check this 4 times per year). the directive states that your Monark dealer will be • Check that the pedal crank is secure to the crank liable for any defects, which existed at the time of axle (4 times per year).

  • Page 33: Batteries

    If a problem and carefully pedalling the cycle. arises, please contact your Monark dealer. Irregularities on the brake belt contact surface are removed by means of a fine sand paper or an abrasive Crank bearing cloth.

  • Page 34: Chain 1/2" X 1/8

    At assembly the flywheel has to be parallel with the centerline of the frame. Otherwise the chain and sprockets make a lot of noise and wear out rapidly. Then assemble the removed parts as above but in reverse order. LC7TT novo...

  • Page 35: Freewheel Sprocket

    The sprocket should be lubricated with a few drops of oil once a year. Tilt the cycle to make it easier for the oil to reach the bearing. See Fig: Lubrication. Fig: Lubrication Fig: Hub assembly LC7TT novo...

  • Page 36: Spare Parts List

    Spare parts list LC7TT novo...
  • Page 37 Side cover rear, left guard) 9310-13 Scale 7 kp, complete 9000-103 -Pole screw M5x12, white 9310-152 -Scale 9312-5-7 Monark novo Display Unit 9000-103 -Pole screw M5x12, white 9312-12 -Knurled screws 8243-7 Holder for cable 9310-12 Display holder, Monark novo 9301-4...
  • Page 38 Potentiometer with cable 9300-24 -Flywheel suspension, complete 9310-45 Pendulum 7 kp, complete 9311-84 Sensor with bracket, complete 9310-43 -Pointer 9311-903 Monark novo Control Unit LC7 9326-88 -Spring 9100-26 Tension cylinder 9300-475 Crank set, 52T, 172,5 mm, Q 146 mm 9300-99 Stop 9300-480...
  • Page 39 Notes ................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................LC7TT novo...
  • Page 40 Version 1710 Art. nr: 7950-409 KROONS VÄG 1, SE-780 50 VANSBRO, SWEDEN | MONARKEXERCISE.SE | TEL: +46(0)281 59 49 40 | FAX: +46(0)281 719 81...
