Model 40/40M
Multi IR Hydrocarbon and Hydrogen
Flame Detector
User Guide
FM, CSA Approved
ATEX, IECEx Approved
Class I Div. 1 Groups B, C, D
Ex II 2G D
Class II/III Div. 1 Groups E, F, G
Ex db eb op is IIC T4 Gb
Ex tb op is IIIC T96°C Db
Document ref: TM 40/40M, (14) February 2017
8200 Market Blvd, Chanhassen, MN 55317, USA
Phone: +1 (973) 239 8398
Fax: +1 (973) 239 7614
Website: www.spectrex.net; Email:
spectrex@spectrex.net

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SharpEye 40 and is the answer not in the manual?

Questions and answers

Related Manuals for Spectrex SharpEye 40

Summary of Contents for Spectrex SharpEye 40

  • Page 1 Ex db eb op is IIC T4 Gb Ex tb op is IIIC T96°C Db Document ref: TM 40/40M, (14) February 2017 8200 Market Blvd, Chanhassen, MN 55317, USA Phone: +1 (973) 239 8398 Fax: +1 (973) 239 7614 Website: www.spectrex.net; Email: spectrex@spectrex.net...

  • Page 3: Legal Notice

    Legal Notice The SPECTREX SharpEye Optical Flame Detector described in this document is the property of Rosemount. No part of the hardware, software or documentation may be reproduced, transmitted, transcribed, stored in a retrieval system or translated into any language or computer language, in any form or by any means, without prior written permission of Rosemount.

  • Page 4: Release History

    Multi IR Hydrocarbon and Hydrogen Flame Detector User Guide Release History Date Revision History Prepared by Approved by July 2008 First Release Ian Buchanan Eric Zinn September 2008 Second Release Ian Buchanan Eric Zinn July 2010 Third Release Ian Buchanan Eric Zinn August 2010 Fourth Release...

  • Page 5: Table Of Contents

    Table of Contents Model 40/40M Multi IR Hydrocarbon and Hydrogen Flame Detector ....i Legal Notice ....................iii Warranty ......................iii Release History ....................iv About this Guide .................... 10 Abbreviations and Acronyms ................11 Introduction .................... 13 Overview ..................... 13 Model and Types ...................
  • Page 6 Multi IR Hydrocarbon and Hydrogen Flame Detector User Guide 2.4.1 Special Instructions for Safe Use ............37 2.4.2 General Instructions ................ 38 Installation Cables ................39 2.5.1 Conduit Installation ................. 39 Installing the Tilt Mount ................. 40 2.6.1 Tilt Mount Assembly ................ 41 Connecting the Detector ................
  • Page 7 TM 40/40M, Rev (14) February 2017 Environmental Specifications ..............64 Wiring Instructions.................. 67 General Instructions for Electrical Wiring ..........67 Typical Wiring Configurations ..............69 RS-485 Communication Network ............. 73 RS-485 Overview .................. 73 Accessories ....................75 Flame Simulator FS-1400 ............... 75 D.1.1 Ordering Information ...............
  • Page 8 Multi IR Hydrocarbon and Hydrogen Flame Detector User Guide List of Figures Figure 1: Vertical and Horizontal Field of View for Gasoline ........23 Figure 2: Horizontal Fields of View for Hydrogen ........... 24 Figure 3: Vertical Field of View for Hydrogen ............25 Figure 4: Indicator LED ..................
  • Page 9 TM 40/40M, Rev (14) February 2017 List of Tables Table 1: Wiring Options ..................15 Table 2: Sensitivity Range Levels ................ 21 Table 3: Fuel Sensitivity Ranges ................22 Table 4: Immunity to False Alarm Sources ............26 Table 5: Welding Immunity Distance ..............27 Table 6: LED Indications ..................

  • Page 10: About This Guide

    About this Guide This guide describes the SharpEye Model 40/40M Multi IR Flame Detector and its features and provides instructions on how to install, operate, and maintain the detector. This guide includes the following chapters and appendices:  Chapter 1, Introduction, provides a general overview of the product, principles of operation, and performance considerations.

  • Page 11: Abbreviations And Acronyms

    TM 40/40M, Rev (14) February 2017 Abbreviations and Acronyms Abbreviation Meaning ATEX Atmosphere Explosives American Wire Gauge Built In Test Electromagnetic Compatibility End of Line Field of View HART Highway Addressable Remote Transducer- communication protocol Immune at Any Distance IECEx International Electrotechnical Commission Explosion Isopropyl Alcohol Infrared...

  • Page 13: Introduction

    Ex tb op is IIIC T106°C Db (–55°C ≤ Ta ≤ +85°C) The SharpEye 40/40 detector is designed to operate as a stand-alone unit directly connected to an alarm system or an automatic fire extinguishing system. The detector can also be a part of a more complex system, where many detectors and other devices are integrated through a common control unit.

  • Page 14: Model And Types

    Multi IR Hydrocarbon and Hydrogen Flame Detector User Guide Model and Types The 40/40M Flame Detector is provided in various configurations depending  Wiring options  Temperature ranges  Type of cable entries  Housing material type  Required approval The configuration detail is included in the product part number on the product label and takes the form: 40/40M-XXXXX, where XXXXX defines the model according to the above requirements.

  • Page 15: Table 1: Wiring Options

    TM 40/40M, Rev (14) February 2017 Table 1 describes the wiring options in detail. Table 1: Wiring Options Wiring Connections Provided Option Fault Alarm Manual 0–20mA Power Relay Relay RS-485 HART Sink N.C. N.O. Alarm Fault Manual Relay 0–20mA Power Relay RS-485 HART N.O.,...

  • Page 16: Features And Benefits

    Multi IR Hydrocarbon and Hydrogen Flame Detector User Guide Features and Benefits  Detects Hydrocarbons and Hydrogen Flames.  Detection Range: Up to 215ft/65m for a 1ft /0.1m n-heptane fire.  Ultra High Immunity to False Alarms: See Table 4 on page 26. ...

  • Page 17: Fire Detection Principle

    TM 40/40M, Rev (14) February 2017 1.4.1 Fire Detection Principle The SharpEye 40/40M Detector is designed to detect hydrocarbon flames that produce CO in their combustion process and non-hydrocarbon flames that produce mainly water vapor (H O) from inorganic fuels, for example, hydrogen, ammonia, hydrofluoric acid, hydrochloric acid and so on.

  • Page 18: Rs-485 Modbus

    Multi IR Hydrocarbon and Hydrogen Flame Detector User Guide Through the HART connection, you are able to perform:  Detector setup  Detector troubleshooting  Detector health and status For more details, refer to the HART Manual TM 777030. 1.4.4 RS-485 Modbus For more advanced communications, the 40/40M detector has an RS 485 Modbus-compatible output that provides data communication from a...
  • Page 19 TM 40/40M, Rev (14) February 2017 FM, CSA 1.4.6.1 The 40/40M Flame Detector is certified for FM and CSA Explosion Proof and Functionality per FM3260:  Class I, Division 1, Groups B, C, and D.  Dust Ignition Proof – Class II/III Division 1, Groups E, F, and G. ...

  • Page 20: Performance Considerations

    Multi IR Hydrocarbon and Hydrogen Flame Detector User Guide TR CU/EAC 1.4.6.5 The 40/40M Flame Detector is in compliance with the standard TR CU 012/2011 per: 1Ex d e IIC T5 Gb X Ex tb IIIC T96°C Db X –55°C ≤ Ta ≤ +75°C 1Ex d e IIC T4 Gb X Ex tb IIIC T106°C Db X –55°C ≤...

  • Page 21: Table 2: Sensitivity Range Levels

    TM 40/40M, Rev (14) February 2017 Alarm response times for a standard fire at a specified range are shown Table 2. Table 2: Sensitivity Range Levels Sensitivity Range ft/m Level Response Time (sec) (for 1ft /0.1m n-heptane pan fire) 50/15 2 (default) 100/30 150/45...

  • Page 22: Table 3: Fuel Sensitivity Ranges

    Multi IR Hydrocarbon and Hydrogen Flame Detector User Guide Table 3: Fuel Sensitivity Ranges Percent of Max. Distance Max. Distance Type of Fuel at Each Sensitivity Range (ft/m) Gasoline 100% 215/65 N-Heptane 100% 215/65 150/45 Kerosene 150/45 Diesel Fuel 150/45 Ethanol 95% 135/40 135/40...

  • Page 23: Cone Of Vision

    TM 40/40M, Rev (14) February 2017 1.5.2 Cone of Vision Gasoline 1.5.2.1  Horizontal: 80°  Vertical: 80° Figure 1: Vertical and Horizontal Field of View for Gasoline Performance Considerations...

  • Page 24: Figure 2: Horizontal Fields Of View For Hydrogen

    Multi IR Hydrocarbon and Hydrogen Flame Detector User Guide Hydrogen 1.5.2.2  Horizontal: 70°  Vertical: 80° Figure 2: Horizontal Fields of View for Hydrogen Performance Considerations...

  • Page 25: Figure 3: Vertical Field Of View For Hydrogen

    TM 40/40M, Rev (14) February 2017 Figure 3: Vertical Field of View for Hydrogen Performance Considerations...

  • Page 26: False Alarm Prevention

    Multi IR Hydrocarbon and Hydrogen Flame Detector User Guide 1.5.3 False Alarm Prevention To prevent false alarms, the detector will not alarm or react to the radiation sources specified in Table 4. Table 4: Immunity to False Alarm Sources Immunity Radiation Source Distance ft/ m Indirect or reflected sunlight...

  • Page 27: Visual Indicators

    TM 40/40M, Rev (14) February 2017 Table 5: Welding Immunity Distance Detection Range Immunity Distance Sensitivity Setting (ft/m) (ft/m) 50/15 >6/2 100/30 >12/4 150/45 >17/6 215/65 >25/7.5 1.5.4 Visual Indicators One 3-color LED indicator is located inside the detector window, as shown in Figure 4.

  • Page 28: Output Signals

    Multi IR Hydrocarbon and Hydrogen Flame Detector User Guide 1.5.5 Output Signals Outputs are available according to the default configuration or the wiring options selected for the 40/40M detector. Determine the outputs for your model according to Table 7. The detector incorporates several types of output suitable to different control systems: ...

  • Page 29: Detector Status

    TM 40/40M, Rev (14) February 2017 1.5.6 Detector Status The possible detector function statuses are listed in Table 8. A more detailed fault analysis can be seen via HART or RS-485. Table 8: Detector Status Status Description Normal Normal operation. Built-In-Test being performed.

  • Page 30: Auxiliary Relay As End-Of-Line

    Multi IR Hydrocarbon and Hydrogen Flame Detector User Guide The detector will remain in BIT Fault state until it has passed a successful BIT. The auxiliary relay can be activated at the warning level or alarm level, depending on programmed function. The outputs depend on the wiring options.

  • Page 31: Built-In-Test (Bit)

    TM 40/40M, Rev (14) February 2017  Relays and heater operation  Processor watchdog  Software  Memory  Oscillator frequency Response to Fault Indication If a failure is found, the detector indicates by:  Fault relay:  Opens in wiring options 1, 2, and 4 ...

  • Page 32: Table 10: Results Of A Successful Bit

    Multi IR Hydrocarbon and Hydrogen Flame Detector User Guide Automatic BIT 1.6.2.2 The detector automatically performs a BIT every 15 minutes. A successful BIT sequence does not activate any indicator. All outputs of BIT results function as described in Table 10 and Table 11, and the BIT is automatically executed every 1 minute.

  • Page 33: Table 12: Results Of A Successful Manual Bit

    TM 40/40M, Rev (14) February 2017 Manual BIT 1.6.2.3 The BIT is manually initiated by momentarily connecting Terminal 3 with Terminal 2 (or a switch across these terminals in the safe area). The results of a successful and unsuccessful Manual BIT are listed in Table 12 and Table 13.

  • Page 35: Installing The Detector

    Installing the Detector ➣ In this chapter… General Guidelines page 35 Unpacking the Product page 36 Required Tools page 37 Certification Instructions page 37 Installation Cables page 39 Installing the Tilt Mount page 40 Connecting the Detector page 42 Configuring Your Detector page 45 This chapter provides basic guidelines for installing the detector.

  • Page 36: Unpacking The Product

    Multi IR Hydrocarbon and Hydrogen Flame Detector User Guide  Environment:  Dust, snow, or rain can reduce the detector’s sensitivity and require more maintenance activities.  The presence of high intensity flickering IR sources may affect sensitivity.  Aiming the Detector: ...

  • Page 37: Required Tools

    TM 40/40M, Rev (14) February 2017 Required Tools The detector can be installed using general-purpose common tools and equipment. Table 14 lists the specific tools required to install the detector. Table 14: Tools Tool Function Comments Hex Key ” Open and close detector Part of the kit cover (for wiring) Hex Key...

  • Page 38: General Instructions

    Multi IR Hydrocarbon and Hydrogen Flame Detector User Guide  Units may be painted or fitted with optional accessories, some of which are made of a non-metallic material or have a non-metallic coating which could potentially generate an ignition-capable level of electrostatic charge under certain extreme conditions.

  • Page 39: Installation Cables

    TM 40/40M, Rev (14) February 2017  If the equipment is likely to come into contact with aggressive substances, then it is the responsibility of the user to take suitable precautions that prevent it from being adversely affected, thus ensuring that the type of protection provided by the equipment is not compromised: ...

  • Page 40: Installing The Tilt Mount

    Multi IR Hydrocarbon and Hydrogen Flame Detector User Guide Installing the Tilt Mount The tilt mount (P/N 40/40-001) enables the detector to be rotated up to 60º in all directions. Figure 5 shows the detector mounted on the tilt mount. Figure 5: Detector with Tilt Mount Installing the Tilt Mount...

  • Page 41: Tilt Mount Assembly

    TM 40/40M, Rev (14) February 2017 2.6.1 Tilt Mount Assembly Figure 6 shows the tilt mount assembly with dimensions in both millimeters and inches. Tilt Holding Plate Tilt Mount Horizontal Locking Screw Vertical Locking Screw Detector Holding Plate Figure 6: Tilt Mount Assembly Figure 7 shows the tilt mount assembly with dimension in both millimeters and inches.

  • Page 42: Connecting The Detector

    Multi IR Hydrocarbon and Hydrogen Flame Detector User Guide ➣ To install the tilt mount and detector: Place the tilt mount in its designated location and secure it with 4 fasteners through 4 holes 7mm in diameter. Use the 4 screws and spring washers according to the kit.

  • Page 43: Figure 8: Detector With Cover Removed

    TM 40/40M, Rev (14) February 2017 Terminal Chamber Terminals Internal Earth Terminal Earth Terminal Detector Holding Screw Conduit/Cable Inlet Figure 8: Detector with Cover Removed Connect the wires to the required terminals on the Terminal Board according to the wiring diagram (Figure 8) and Table 15. Connect the grounding (earth) wire to the ground (earth) screw outside the detector (earth terminal).

  • Page 44: Verifying The Detector Wiring

    Multi IR Hydrocarbon and Hydrogen Flame Detector User Guide 2.7.1 Verifying the Detector Wiring The detector has 5 output wiring options within the Exde integral terminal section of the enclosure. There are 12 terminals labeled 1–12. Table 15 describes the function of each terminal for all the wiring options. Table 15: Model 40/40M Wiring Options Wire Option 1...

  • Page 45: Configuring Your Detector

    HART protocol as follows:  Mini Laptop Kit (P/N 777820): The mini laptop, pre-loaded with the SPECTREX host software, enables you to re-configure settings or perform diagnostics on all 40/40 series flame detectors. Refer to manual TM777070 for programming instructions when using the Mini Laptop Kit.

  • Page 46: Sensitivity

    Multi IR Hydrocarbon and Hydrogen Flame Detector User Guide  Heated Optics – Auto  Temperature – 41°F/5°C 2.8.1 Sensitivity The detector offers 4 sensitivity settings. The settings refer to an n-heptane or gasoline fire of 1ft²/0.1m², from low sensitivity of 50ft/15m to 215ft/65m.

  • Page 47: Function Setup

    TM 40/40M, Rev (14) February 2017 2.8.4 Function Setup You can select the desired functions as detailed in Table 17. Table 17: Functions Function Setting Alarm Latch Yes: Enable alarm latching.  No: Disable alarm latching (default).  Auxiliary Relay* Yes: Activate auxiliary relay at warning level.

  • Page 49: Operating The Detector

    Operating the Detector ➣ In this chapter… Powering Up page 49 Safety Precautions page 50 Testing Procedures page 51 This chapter describes how to power up and test the detector. It also includes some very important safety checks that you should complete before operating the detector.

  • Page 50: Safety Precautions

    Multi IR Hydrocarbon and Hydrogen Flame Detector User Guide Safety Precautions After powering up, the detector requires almost no attention in order to function properly, but the following should be noted:  Follow the instructions in this guide and refer to the drawings and specifications.

  • Page 51: Testing Procedures

    This section describes the proof testing procedure for proper operation of the detector. The detector can be tested using the Manual BIT or the SPECTREX Flame Simulator FS-1400. The detector performs internal tests continuously and automatic BIT tests every 15 minutes. For more details refer to Built-In-Test (BIT) on page 31.

  • Page 52: Table 19: Results Of Successful Flame Simulator Test

    Power up the system and wait up to 60 seconds for the detector to turn to a normal state. The Power LED turns on. Aim the SPECTREX Flame Simulator Model FS-1400 at the target point of the detector such that the radiation emitted by it is facing directly towards the detector.

  • Page 53: Maintenance And Troubleshooting

    This chapter deals with preventive maintenance, describes possible faults in detector operation and indicates corrective measures. Ignoring these instructions may cause problems with the detector and may invalidate the warranty. Whenever a unit requires service, please contact SPECTREX or its authorized distributor for assistance. Maintenance...

  • Page 54: Periodic Procedures

    Serial and tag number  Entries for every maintenance operation performed, including a description of the operation, date, and personnel ID If a unit is sent to SPECTREX or a distributor for service, a copy of the maintenance records should accompany it. Maintenance...

  • Page 55: Troubleshooting

    TM 40/40M, Rev (14) February 2017 Troubleshooting This section is a guide to correct problems which may happen during normal operation. Table 20: Troubleshooting Table Problem Cause Corrective Action LEDs Off No power to the Check that the correct power ...

  • Page 57: Appendix

    Appendix Appendix...

  • Page 59: A Specifications

    Specifications ➣ In this appendix… Technical Specifications page 59 Electrical Specifications page 60 page 61 Outputs Approvals page 63 Mechanical Specifications page 63 Environmental Specifications page 64 Technical Specifications Spectral Response Multi IR Bands Detection Range Fuel ft/m Fuel ft/m (at highest Sensitivity n-Heptane 215/65...

  • Page 60: Electrical Specifications

    Multi IR Hydrocarbon and Hydrogen Flame Detector User Guide Electrical Specifications Operating Voltage: 18–32VDC Power Consumption: Table 21 Table 21: Electrical Specifications Operating Status Without Voltage Outputs 0–20mA Power Normal 1.61W 1.56W Consumption Normal when Heater On 2.28W 2.16W (Max. 24VDC) Alarm 2.64W 2.28W...

  • Page 61: Outputs

    TM 40/40M, Rev (14) February 2017 Outputs Electrical There are 5 output wiring options. These options are Interface defined at the factory per the customer order and cannot be changed at the customer facility. See General Instructions for Electrical Wiring on page 67 for the wiring/terminal diagram for each option.

  • Page 62: Table 23: 20Ma Current Output

    Multi IR Hydrocarbon and Hydrogen Flame Detector User Guide Table 23: 20mA Current Output State Output Fault 0+1mA BIT Fault 2mA±10% Normal 4mA±10% Warning 16mA±5% Alarm 20mA±5% HART Protocol  The HART protocol is a digital communication signal at a low level on top of the 0–20mA. This bi-directional field communication protocol is used to communicate between intelligent field instruments and the host system.

  • Page 63: Approvals

    TM 40/40M, Rev (14) February 2017 Approvals FM, CSA Hazardous Area  Approvals Class I Div. 1 Groups B, C, and D; Class II/III Div. 1 Groups E, F, and G ATEX, IECEx  Ex II 2G D Ex db eb op is IIC T4 Gb Ex tb op is IIIC T96°C Db (–55°C ≤...

  • Page 64: Environmental Specifications

    Multi IR Hydrocarbon and Hydrogen Flame Detector User Guide Environmental Specifications The SharpEye 40/40M is designed to withstand harsh environmental conditions. Designed to meet MIL-STD-810C, method High Temperature  501.1 procedure II Operating temperature: +167°F/+75 °C  Storage temperature: +185 °F/+85 °C ...

  • Page 65: Table 24: Electromagnetic Compatibility (Emc)

    TM 40/40M, Rev (14) February 2017 Electromagnetic Compatibility (EMC) Table 24: Electromagnetic Compatibility (EMC) Test Standard Level Per Electrostatic Discharge ESD IEC 61000-4-2 IEC 61326-3 Radiated EM Field IEC 61000-4-3 IEC 61326-3 Electrical Fast Transients IEC 61000-4-4 IEC 61326-3 Surge IEC 61000-4-5 IEC 61326-3 Conducted Disturbances...

  • Page 67: B Wiring Instructions

    Wiring Instructions ➣ In this appendix… General Instructions for Electrical Wiring page 67 Typical Wiring Configurations page 69 General Instructions for Electrical Wiring Follow the instructions detailed in this section for determining the correct wire gauge to be used for the installation. Use Table 25 to determine the required wire gauge/size for general wiring, such as relay wiring.

  • Page 68: Table 26: Wiring Length In Feet/Meters

    Multi IR Hydrocarbon and Hydrogen Flame Detector User Guide Table 26: Wiring Length in Feet/Meters Power Number Supply Recommended Wire Diameter (AWG) Range Detectors (VDC) 22–32 22–32 22–32 20–32 20–32 4 and less 20–32 ft/m 164/ 50 328/ 492/ 150 656/ 820/240 Max.

  • Page 69: Typical Wiring Configurations

    TM 40/40M, Rev (14) February 2017 Typical Wiring Configurations This section describes examples of typical wiring configurations. Figure 9: Wiring Terminals Typical Wiring Configurations...

  • Page 70: Figure 10: Typical Wiring For 4 Wire Controllers (Using Option 1 Or 2 Wiring)

    Multi IR Hydrocarbon and Hydrogen Flame Detector User Guide Table 27: Wiring Connections Wiring Detector Terminals Option Model 40/40M- Fault Relay 0–20mA 0–20mA 1XXXX (N.C.) (Sink) (Sink) 40/40M- Fault Relay Alarm Relay 0–20mA 2XXXX (N.C.) (N.C.) (Source) 40/40M- Fault Relay Alarm Relay 0–20mA 3XXXX...

  • Page 71: Figure 11: 0-20Ma Wiring Option 1 (Sink 4-Wire) - Default

    TM 40/40M, Rev (14) February 2017 Figure 11: 0–20mA Wiring Option 1 (Sink 4-Wire) - Default Figure 12: 0–20mA Wiring Option 1 (Converted to Source 3-Wire) Typical Wiring Configurations...

  • Page 72: Figure 13: 0-20Ma Wiring Option 1 (Non-Isolated Sink 3-Wire)

    Multi IR Hydrocarbon and Hydrogen Flame Detector User Guide Figure 13: 0–20mA Wiring Option 1 (Non-isolated Sink 3-Wire) Figure 14: 0-20mA Wiring Option 2 and 3 (Source 3-Wire available with the HART Protocol) Note: There are no 0–20mA outputs in wiring options 4 and 5. Typical Wiring Configurations...

  • Page 73: Crs-485 Communication Network

    (32 detectors for each repeater) up to 247 on the same 4 wires. When using the RS-485 network, it is possible to read each detector status (FAULT, WARNING, and ALARM) and to initiate a BIT for each detector individually. For more details, contact SPECTREX. Figure 15: RS-485 Networking RS-485 Overview...

  • Page 75: Accessories

    Accessories ➣ In this appendix… Flame Simulator FS-1400 page 75 Tilt Mount page 80 Duct Mount page 81 Weather Cover page 82 Cone Viewer page 83 Air Shield page 84 This appendix describes the accessories that can help you maximize fire detection with the SharpEye Multi IR Flame Detector: Flame Simulator FS-1400 The Flame Simulator FS-1400 is designed specifically for use with SharpEye...

  • Page 76: Ordering Information

    Multi IR Hydrocarbon and Hydrogen Flame Detector User Guide D.1.1 Ordering Information The P/N of the Flame Simulator Kit is 380114-4. The kit is supplied in a carry case that includes:  Flame Simulator FS-1400  Charger  Tool Kit ...

  • Page 77: Range

    TM 40/40M, Rev (14) February 2017 D.1.4 Range Table 28: Sensitivity Ranges Sensitivity Detection Maximum Testing Sensitivity Setting Distance (ft/m) (ft/m) 1 (Low) 50/15 6.6/2 100/30 19.6/6 150/45 29.5/9 4 (High) 215/65 39.3/12 Notes:  The minimum distance from the detector is 30”/75cm. ...

  • Page 78: Battery Replacement

    Unscrew the locking disc clockwise (Item 3). Pull out the battery from the flame simulator. Insert the new battery pack in the simulator housing. Use only SPECTREX battery pack, P/N 380004. Screw on the locking disc (Item 3). Screw on the back cover (Item 4).

  • Page 79: Technical Specifications

    TM 40/40M, Rev (14) February 2017 D.1.7 Technical Specifications Temperature Range: –4°F to +122ºF / –20ºC to General  +50ºC Vibration Protection: 1g (10-50Hz) Power: 14.8V (4 X 3.7V rechargeable lithium-ion Electrical  battery) Max. Current: 4A  Battery Capacity: 2.2AH ...

  • Page 80: Tilt Mount

    Multi IR Hydrocarbon and Hydrogen Flame Detector User Guide Tilt Mount The tilt mount (P/N 40/40-001) provides accurate directional selection for optimum area coverage. Figure 18: Tilt Mount Tilt Mount...

  • Page 81: Duct Mount

    TM 40/40M, Rev (14) February 2017 Duct Mount The duct mount (P/N 777670) is suitable for use with the SharpEye 40/40 Series Optical Flame Detector 40/40M, for both the aluminum and st.st. enclosure. The duct mount allows flame detection in areas where high temperatures exist or where the detector cannot be installed inside the area.

  • Page 82: Weather Cover

    Multi IR Hydrocarbon and Hydrogen Flame Detector User Guide Weather Cover The weather cover (P/N 777163) protects the detector from different weather conditions, such as snow and rain. Figure 20: Weather Cover Weather Cover...

  • Page 83: Cone Viewer

    TM 40/40M, Rev (14) February 2017 Cone Viewer The cone viewer (P/N 777166) evaluates detector coverage onsite. The device is an add-on accessory that enables designers and installers to optimize detector location and assess the actual coverage of installed detectors. The device is universal and can be used with all 40/40 SharpEye Optical Flame Detectors.

  • Page 84: Air Shield

    Multi IR Hydrocarbon and Hydrogen Flame Detector User Guide Air Shield The air shield (P/N 777650) is suitable for use with the SharpEye 40/40 Series Optical Flame Detector 40/40M, for both the aluminum and st.st. enclosures. Optical flame detectors are often used in highly polluted or dirty areas that force maintenance personnel to access the detector frequently in order to clean its optical window.

  • Page 85: Esil-2 Features

    SIL-2 Features ➣ In this appendix… 40/40M Flame Detector page 85 40/40M Flame Detector This appendix details the special conditions for compliance with the requirements of EN 61508 for SIL 2. The 40/40M Flame Detector can only be used in low or high demand mode applications.
  • Page 86 Multi IR Hydrocarbon and Hydrogen Flame Detector User Guide E.1.2.1 Conditions for Safe Operating  The flame detector must consist only of the approved hardware and software modules.  The 24V power supply must fulfill the requirements for PELV/SELV of EN 60950.
  • Page 87 TM 40/40M, Rev (14) February 2017 Other E.1.2.4  The complete function of the flame detector (flame detection, function of the 0–20mA interface, and the relays) must be examined at least every 6 or 12 months (see Safety Relevant Parameters on page 85), or whenever the flame detector must be switched off and on.

  • Page 90: Technical Support

    Phone: +1 (973) 239 8398 Fax: +1 (973) 239 7614 Email: spectrex@spectrex.net Website: www.spectrex.net Your Local SPECTREX Office: Texas (USA) Mr. Jay Cooley, Regional Sales Manager 16203 Park Row, Suite 150 Houston, Texas 77084 Phone: +1 (832) 321 5229 Email: jay.cooley@emerson.com...
