Pandora Smart Moto / Smart Moto Plus is a service-security system built for motorcycles and
quads with on-board voltage of 12V.
It is a complex engineering device, which includes unique and modern technological software and
hardware solutions. While developing we were using the most up-to-date electronics from world's
best manufacturers. The device is built using high-precision mounting and control machinery; thus,
we guarantee highest possible quality, reliability and stable technical characteristics for the whole
operation period.
The system is built for your convenience: it's ergonomic, reliable, has the highest security and service
characteristics, 3 years unconditional warranty and free service and support. We are happy to provide
any support we can – feel free to use our online support.
!
WARNING! I
t Is stRoNGly RecommeNded to hAve A pRofessIoNAl cAR mechANIc to INstAll the system
cAR electRoNIcs INstAlleR should be Able to INstAll the system usING INstAllAtIoN scheme IN thIs mANuAl
A
s
ANd the
lARm
tudIo oR
. o
INstAllAtIoN
uR systems ARe thoRouGhly tested foR quAlIty
most lIkely the pRoblem Is IN ImpRopeR INstAllAtIoN
This device has limited external factors resistance. It should not be subjected to water beyond occasional splatter.
The base unit is designed to operate at temperatures from -40°C to +85°, the degree of protection is IP54.
The control units (remotes, tags, etc.) are designed to operate at temperatures from -10°C to +40°C, the degree of protection is IP40.
See wiring diagram to find information about additional devices and options.
Our web-site: pandorainfo.com
Customer support: support@pandorainfo.com
for motorcycles Pandora Smart Moto/Smart Moto Plus
p
s
ANdoRA
pecIAlIst softWARe
Pandora would like to thank you
for choosing our service-security system
. m
ost feAtuRes ARe hIGhly depeNdeNt oN competeNt
,
so If A feAtuRe fAIls to pRoduce expected Result
.
Product is in conformity with Electromagnetic Compatibility
Directive EMC 2004/108/EC and R&TTE Directive 1999/5/EC
. A
Ny
,

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Smart Moto and is the answer not in the manual?

Questions and answers

Related Manuals for Pandora Smart Moto

Summary of Contents for Pandora Smart Moto

  • Page 1 Pandora Smart Moto/Smart Moto Plus Pandora Smart Moto / Smart Moto Plus is a service-security system built for motorcycles and quads with on-board voltage of 12V. It is a complex engineering device, which includes unique and modern technological software and hardware solutions.

  • Page 2: Table Of Contents

    Emergency control of the anti-theft functions Prompt entry/change of the main owner phone number Programming the system Updating firmware of the tag Pandora Specialist Application Wrist bracelet PANDORA BAND Pandora Alarm Studio Switching on/off the Band Updating firmware Charging the Band Programming table Button’s functions...

  • Page 3: General Information

    GENERAL INFORMATION Read before using System set Pandora Smart Moto and Pandora Smart Moto Plus Carefully read this manual before starting installation and using the security-service system. Pay attention to the text marked with 1. User and installation manual 2. Owner’s personal card 3.

  • Page 4: Pin-Codes Of The System

    PIN-codes of the system Owner’s personal card The «Secret PIN-code» rasE ThE prOTEcTivE layEr carEfully O NOT usE aNy sharp ObjEcTs CANNOT BE CHANGED (is written on the «Owner’s personal card») TO avOid damagiNg Of a hiddEN iNfOrmaTiON uNdEr ThE prOTEcTivE layEr The «Service PIN-code»...

  • Page 5: Base Unit

    Built-in LTE module (4G LTE/3G/2G | GPS/GLONASS) – provides a connection with our online- SOUND / LIGHT SIGNALIZATION service pandora-on.com and mobile applications), allows to control the system by a phone using DTMF- SIGNALS commands, voice and SMS notifications, LBS-coordinates (only by DTMF–command), automatic date DESCRIPTION (sound / light) and time detection, precise GPS location (with Tracking function).

  • Page 6: System Functions And Modes

    SYSTEM FUNCTIONS AND MODES EXTERNAL BUTTON LED INDICATOR SIGNALS SIGNALS DESCRIPTION Security mode THE SYSTEM IS ARMED The system confirms arming with 1х sound 1х light signals. When the system is armed, the system monitors security zones with separated warning and alarm level of triggering: Short red flashes System is armed •...

  • Page 7: Security Zones

    Security zones Immobiliser mode This mode is used to recognize an owner using authorization devices when the system is disarmed. • Outside temperature (status) When turning on the ignition, the base unit performs a search for authorization devices in the radio •...

  • Page 8: Checking The Number Of Paired Devices

    IMMOBILISER RADIO TAG Checking the number of paired devices The number of paired radio tags/mobile devices can be checked by the number of flashes of the LED A radio tag is a device used to control a vehicle/system on a distance of a Bluetooth connection. The indicator.

  • Page 9: Indication Of The Send Led

    Updating firmware of the tag Installation/replacing a battery of the tag CR2032 • Download the Pandora BT application (Android / iOS) or Pandora Specialist (Android) on the devices To install or replace the battery (CR2032), carefully follow these steps: equipped with a Bluetooth 4.0 Low Energy or higher module.

  • Page 10: Switching On/Off The Band

    Press and hold the button for 3 sec to switch ON, 8 sec to switch OFF. Charge the battery if it will not Install Pandora BT (Android/iOS) or Pandora Specialist Apps on a smartphone or a tablet, equipped with switch on.

  • Page 11: Information Icons

    CONTROL THE SYSTEM BY A PHONE Information icons Connection state Tilt sensor Or ThE cOrrEcT OpEraTiON Of ThE fuNcTiONs aN OwNEr shOuld mONiTOr ThE sTaTus balaNcE Of ThE card (alarm level) , gsm iNsTallEd iN ThE sysTEm f ThE card is blOckEd Or dEfEcTivE fuNcTiONs Of ThE sysTEm will bE uNavailablE Security system status Motion sensor...

  • Page 12: Changing Settings Via A Phone

    Changing settings via a phone 2. Dial 500*. 3. The system will confirm: «Current coordinates are sent via text message» and will send text message with coordinates and a web link to a map to your phone. Owner number -> # Changing guest PIN-code To end the session, hang up the phone.

  • Page 13: System Installation

    SYSTEM INSTALLATION An example of changing the owner main number: 1. Enter the setting menu via a phone according to the instruction above; General installation requirements 2. Dial DTMF command 1*(phone number settings) and 1*(owner main number); 3. Enter new owner number in the format *XXXXXXXXXXX # (the system recognizes «*» as «+»); 4.
  • Page 14 • Wire №9 | Orange | 6A (+12V) | CH7 — default logic is «Turn indicators». Connect this wire to (+) This connector is used to configure and update the system with Pandora Alarm Studio or Pandora control wire of the left or right turn indicators. The wire is equipped with a 7.5A fuse.

  • Page 15: Wiring Diagram

    Pandora SMART MOTO BASE UNIT WIRING DIAGRAM PLACEMENT WARNING! Update rmware of the WARNING! Fixate the protective cap WARNING! The system is a IT IS FORBIDDEN to install the system IS FORBIDDEN to change or bypass original base unit before installation. If the using clamps when the installation is maintenance-free device.

  • Page 16: Online Service And Mobile Application

    (enter information from the «Owner’s personal card»). state through the online-service. Web-service: https://pandora-on.com. The Pandora Connect mobile app is available for downloading from the corresponding app store: App Store for iOS devices; Google Play for Android devices. hE maNufacTurEr rEsErvEs ThE righT TO makE chaNgEs Of ThE...

  • Page 17: Writing A Mobile Device To The System Memory

    When approaching the vehicle or when Internet connection is missing a mobile phone with the mobile application Pandora Connect installed can work with the system via a Bluetooth connection. External temperature This type of connection allows you to control the system, receive status information and use your mobile phone as an authorization device.

  • Page 18: Control The System

    Pandora Band (Smart Moto Plus kit) – the device must be in the Bluetooth coverage area. Shortly Radio tag – A radio tag must be in the Bluetooth coverage area. Shortly press the control button press the control button on the Band.

  • Page 19: Panic Mode

    Mobile app Pandora Connect – When the system is online (only Bluetooth connection), press and Mobile app Pandora Connect – When the system is online (there is an Internet or Bluetooth hold the button on the control panel until the scale is fully loaded.

  • Page 20: Control Over The System In Case Of Emergency

    Call the system phone number and enter the command after the answer: – Disarming Pandora Band (Smart Moto Plus kit) – to activate/deactivate service mode, press and hold the – Deactivate authorization devices, where хххх is the «Secret PIN- code» written on 998*xxxх...

  • Page 21: Emergency Disarming

    Emergency disarming Owner’s personal card External VALET button valET Not paying attention to the siren signals, make sure that the ignition is off and enter the «Secret PIN- EmOvE ThE prOTEcTivE layEr carEfully O NOT hE ExTErNal buTTON is placEd iN ThE iNTEriOr «s ») code»...

  • Page 22: Programming The System

    (without pauses). 15 times (without pauses). System settings and parameters can be configured using the Pandora Alarm Studio and Pandora Specialist application. Some functions can be configured only by the programming menu of the system. 3. Тo deactivate the function – The LED indicator will be green after entering the programming It is required to put the system to programming mode to get access to the settings.

  • Page 23: Pandora Specialist Application

    • Connect the system to the PC via a USB cable; • Put the system to the programming mode; • The Pandora Alarm Studio will automatically connect to the system and you will be able to configure settings and update firmware.

  • Page 24: Programming Table

    Pauses between presses should not exceed 1 second, every pressing will confirm with an orange LED indicator flash. Pause for more than 1 second and a red LED indicator flash with a 10.8 – Pairing a telemetry module Pandora Eye Pro / NAV-X H1P8 sound from the Siren confirm the input of the first digit.
  • Page 25 The LED will light red after entering. Press and hold the VALET button for 5 programming level №0. seconds until 6 orange flashes of LED indicator or 5 sound signals of the Siren. Open the Pandora Specialist or Pandora BT app, go to «Search device» screen and select the device and then select one...

  • Page 26: Additional Devices

    ADDITIONAL DEVICES Level №11 – Programming and configuring an «Immobiliser PIN-code» The level is divided into 3 sublevels Selecting buttons Remote control D-035 – is a two-way short-distance communication The system will automatically enter the sublevel 11.0 (Selecting buttons) after entering the level device designed to control a security system and receive information 11.

  • Page 27: Warranty Obligations

    WARRANTY OBLIGATIONS Manufacturer guarantees correct operation of the service-security system if exploitation, installation, storage and transportation conditions described in this manual were met. The system should only be used according to installation scheme and user manuals. The system is meant to be installed by the professional car electronics installers. The installer should fill in installation certificate that is included in this manual.

  • Page 28: Installation Certificate

    Car specifications: Car model Type Id number (VIN) Registration number Security system specification: Model Pandora Smart Moto / Pandora Smart Moto Plus Serial number Service center name, full address and installer’s stamp Signature_____________________/___________________________________/ Signatory Work accepted________________/___________________________________/ Signatory Date «____»___________________20____y.

  • Page 29: Acceptance Certificate

    Acceptance certificate Pandora Smart Moto / Pandora Smart Moto Plus Model is in conformity with Electromagnetic Compatibility Directive EMC 2004/108/EC and R&TTE Directive 1999/5/EC. Serial number ______________________________ Date of production__________________________ Responsible person’s signature (stamp) Packager_____________________________________________________________________________ Signature (personal stamp) Warranty card...
