Pandora Mini v3 User Manual
  1. Manuals
  2. Brands
  3. Pandora Manuals
  4. Security System
  5. Mini v3
  6. User manual

Pandora Mini v3 User Manual

Car service-security system, built for cars with onboard voltage of 12v
Hide thumbs Also See for Mini v3:
Table of Contents

Advertisement

Quick Links

Pandora Mini v3 is a car service-security system, built for cars with on-
board voltage of 12V.
It is a complex engineering product, which includes unique and modern
software and hardware solutions. When building the Pandora Mini v3 we were
using the most up-to-date electronics from world's best manufacturers. The
device is built using high-precision mounting and control machinery, thus we
guarantee highest possible quality, reliability and stable technical characteris-
tics for the whole operation period.
Elegant and advanced technical design and unique ergonomic interaction
algorithms that are used in the Pandora Mini v3 allow enhancing your car with
fantastic set of intuitive and useful functions.
WARNING! I
stAllING the system
the
s
stAllAtIoN
fAIls to pRoduce expected Result
INstAllAtIoN
This device has limited external factors resistance. It should not be subjected to water beyond occasional splatter, or operated in
temperatures outside -40° to +80° C range.
www.pandorainfo.com
Our web site:
Customer support:
Product is in conformity with Electromagnetic Compatibility
Directive EMC 2004/108/EC and R&TTE Directive 1999/5/EC
Pandora would like to thank you for choosing our
t Is stRoNGly AdvIsed to hAve pRofessIoNAl cAR mechANIc IN
. A
p
m
3
ANdoRA
INI v
. m
tudIo softWARe
. o
uR systems ARe thoRouGhly tested foR quAlIty
.
support@pandorainfo.com
Ny cAR electRoNIcs INstAlleR should be Able to INstAll
usING INstAllAtIoN scheme IN thIs mANuAl ANd
ost feAtuRes ARe hIGhly depeNdeNt oN competeNt IN
,
most lIkely the pRoblem Is IN ImpRopeR
service-security system
,
so If A feAtuRe
-
A
lARm
-

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Mini v3 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Pandora Mini v3

Summary of Contents for Pandora Mini v3

  • Page 1 Elegant and advanced technical design and unique ergonomic interaction algorithms that are used in the Pandora Mini v3 allow enhancing your car with fantastic set of intuitive and useful functions. WARNING! I...

  • Page 2: Table Of Contents

    System module layout Control over the system Warranty obligations Arming Installation certificate Disarming Acceptance certificate Warranty card Service (VALET) mode Control over the system in case of emergency Emergency disabling immobilizer radio tags PANDORA MINI V3 CAR SERVICE-SECURITY SYSTEM USER MANUAL...

  • Page 3: System Set

    Built-in sensors – These sensors are integrated in the base unit. The sensors perform control and protection of the vehicle. Additional connections are not required Additional sensor (*optional) – External additional sensors are connected to the base unit. PANDORA MINI V3 CAR SERVICE-SECURITY SYSTEM USER MANUAL...

  • Page 4: Arming Mode

    1 to 9. • The system will confirm the correct input by a sound signal of the beeper • • Closing windows and a programmed function will be performed. • •* Engine pre-heaters PANDORA MINI V3 CAR SERVICE-SECURITY SYSTEM USER MANUAL...

  • Page 5: Immobilizer Mode

    Is dIsAbled by defAult se the ANdoRA ANdoRA lARm • Built-in accelerometer tudIo to eNAble dIsAble thIs mode • Battery CR 2032 • 2.4 GHz radio frequency (dialog encryption AES-128) • Bluetooth-protocol PANDORA MINI V3 CAR SERVICE-SECURITY SYSTEM USER MANUAL...

  • Page 6: Functions Of The Button

    - hold for 10 seconds Firmware update Updating firmware of the tag • Run the mobile app Pandora BT. Light indication of SEND LED SEND • Press and hold the button on the radio tag until the 10th flash of the indicator, then release the button.

  • Page 7: Mobile Applications

    MOBILE APPLICATIONS III. PAIR A MOBILE DEVICE Switch on the Bluetooth on your phone. . Run the Pandora BT app and go The mobile application Pandora BT for Android and iOS devices is a service to the “Devices -> Searching device” screen. The application will search for the application to control and manage the system state via the Bluetooth connec- system via a Bluetooth connection.
  • Page 8 Vehicle and system statuses: Doors Shock sensor Note! y “mAIN meNu – settINGs – ou cAN chANGe buttoN lAyout IN the coNtRol buttoNs”. Front hood Tilt sensor Trunk Motion sensor Ignition Additional sensor PANDORA MINI V3 CAR SERVICE-SECURITY SYSTEM USER MANUAL...

  • Page 9: Control Over The System

    (for cars with an intel- ligent access system). Note! A ddItIoNAl settINGs ARe RequIRed foR usING the ANds Ree mode WIth Note! A A mobIle phoNe ddItIoNAl settINGs oR coNNectIoNs ARe RequIRed foR thIs mode PANDORA MINI V3 CAR SERVICE-SECURITY SYSTEM USER MANUAL...

  • Page 10: Service (Valet) Mode

    Switch on/ HandsFree mode off the service mode using a phone and the Pandora BT application Move toward the vehicle with a remote tag (or a paired mobile phone) •...

  • Page 11: Control Over The System In Case Of Emergency

    1 second and, red LED indicator flash and a short sound signal of the beeper confirms the input of the first digit. Then you can enter the next digit. PANDORA MINI V3 CAR SERVICE-SECURITY SYSTEM USER MANUAL...
  • Page 12 LED will produce the series of red and green flashes and the system will return to the programming menu. Enter the ‘Secret PIN-code’ that is written on the owner’s plastic card. The PANDORA MINI V3 CAR SERVICE-SECURITY SYSTEM USER MANUAL...
  • Page 13 Mini WIRING DIAGRAM External button DXL 0110L v3 VALET «LED/VALET» White Base unit (view from the top side) «LED/VALET» Blue Antenna 2.4 GHz Red/Black 200 mA (-) INP6/CH6 – OUT «Beeper» Orange/White CAN1-H «+12V» 200 mA (-) Yellow/White CAN1-L Gray 200 mA (-) CH1/INP1 –...

  • Page 14: System Installation

    This wire connects to appropriate wire that becomes grounded when the front hood opens. Wire №11 (Orange-black) CAN1-L — wire of digital bus CAN1-Low. It con- PANDORA MINI V3 CAR SERVICE-SECURITY SYSTEM USER MANUAL...

  • Page 15: System Configuration And Programming

    Low. It connects to an appropriate CAN2-High wire of a car. This channel can be Alarm Studio or Pandora Specialist application. Some functions can be con- assigned as an output, it will not work as a digital bus in this case.

  • Page 16: Pandora Alarm Studio

    1 second. The system will confirm correct input with red LED flashes and short sound signals of the siren/beeper and proceed • Install the Pandora Alarm Studio to a PC with Windows XP/Vista/7/8/10; • Start the Pandora Alarm Studio;...

  • Page 17: Programming Levels Table

    p №10.6 – Pairing an engine compartment P module RHM-03BT/PS-331BT/PS-332BT №10.7 – Pairing an additional device DI-04 P or BT-01 №10.8 – Pairing a telemetry module Pandora P Eye Pro / NAV-X PANDORA MINI V3 CAR SERVICE-SECURITY SYSTEM USER MANUAL...
  • Page 18 • Enter the first digit of the code using the VALET button. Press the button a number of times, equals to the first digit. Pauses between presses should not exceed 1 second, every pressing will confirm with an orange LED indica- PANDORA MINI V3 CAR SERVICE-SECURITY SYSTEM USER MANUAL...
  • Page 19 The system will enter the programming level №0. light red after entering. Press and hold (H) the VALET button for 6 seconds. Open the Pandora Specialist, go to “Search device” screen and select the device and then select one of the update option: An example of pairing door sensor DMS-100 BT: •...
  • Page 20 - Incorrect confirmation is indicated with a long red flash of the LED indica- tor, the system will cancel the input and return to the programming mode. PANDORA MINI V3 CAR SERVICE-SECURITY SYSTEM USER MANUAL...

  • Page 21: Beeper Sound Signals

    1 sec. interval. The number of the signals equals to the number of recorded radio tags. After a pause of 2 Blocking warning Fast sound signals seconds the system signal will indicate registered mobile device. PANDORA MINI V3 CAR SERVICE-SECURITY SYSTEM USER MANUAL...

  • Page 22: Additional Devices

    The sensor can be installed on wagon, trailer doors. It has The power supply and circuit to be blocked are connected to its own power source. the relay. The system control the relay via a radio channel. PANDORA MINI V3 CAR SERVICE-SECURITY SYSTEM USER MANUAL...

  • Page 23: System Module Layout

    • GSM, phone calls • pandora-on.com - online service • Pandora Pro (iOS), Pandora Online (Android) – special mobile applications for smartphones, tabs and smartwatches Apple Watch, Android Wear, Samsung Gear S2/S3...

  • Page 24: Warranty Obligations

    Maintenances and repairs of the system with expired warranty period are car- Date “____“___________________20___y ried out at the expense of the user on a separate contract between the user and the installer/service center. PANDORA MINI V3 CAR SERVICE-SECURITY SYSTEM USER MANUAL...

  • Page 25: Acceptance Certificate

    Directive EMC 2004/108/EC and R&TTE Directive 1999/5/EC. Serial number Date of production Responsible person’s signature (stamp) Packager Signature (personal stamp) Warranty card Model Pandora Pandora Mini v3 Serial number Date of purchase «____» ______________________ 20____year Seller’s (installer’s) stamp Seller’s signature PANDORA MINI V3 CAR SERVICE-SECURITY SYSTEM...
