EVERPURE
QL2-OW200L WATER FILTER
®
The Everpure QL2-OW200L Water Filter reduces chlorine tastes and odors in drinking water and beverages made with water.
The OW200L also filters out dirt and rust, and reduces the formation of limescale which builds-up in water-using appliances
that heat or freeze water. Perhaps most important, the OW200L reduces both lead and trihalomethanes (THMs) to below
Federal limits.
PARTS LIST
Key Letter
Description
A
QL2 Head Assembly
B
OW200L Cartridge
C
Mounting Screw (2 req'd)
D
Star Washer (2 req'd)
E
Flow Control/Quick Disconnect
F
Mounting Bracket
G
Bracket Screw (3 req'd)
SPECIFICATIONS
Rated Service Flow:
Maximum Working Temperature:
Min/Max Operating Pressure:
Capacity:
Flow Rate:
For cold water use only.
Not for use with water preheated over 100 °F (38 °C).
This drinking water system must be maintained in accordance with the manufacturer's instructions, including the timely
replacement of filter cartridges.
FILTRATION & PROCESSING SOLUTIONS
Part Number
EV3063-32
EV9619-01
EV3061-96
EV3062-04
EV3081-32
EV3055-34
EV3062-03
0.5 gpm / 1.9 Lpm
35-100°F (2-38°C)
10 psi (0.7 bar) / 125 psi (8.6 bar)
480 gallons (1816 L)
0.5 gpm (1.9 Lpm)
QL2-OW200L FILTER INSTALLATION AND OPERATION GUIDE
INCOMING FITTING FROM COLD WATER
SUPPLY PROVIDED BY INSTALLER
F
E
TO DISPENSER
G
WATER INLET
D
C
A
B
