- Page 1 866.332.2403 (TOLL FREE); 7am – 7pm Pacific Time, Monday-Saturday ASSEMBLY INSTRUCTIONS FOR THE ATTACHED ARCHED PERGOLA KITS WITH WALL MOUNTED ANCHORS...
- Page 2 P| 1 ATTACHED ARCHED PERGOLA KITS WITH WALL MOUNTED ANCHORS. www.ForeverRedwood.com...
- Page 3 P| 2 ATTACHED ARCHED PERGOLA KITS WITH WALL MOUNTED ANCHORS. www.ForeverRedwood.com...
- Page 4 P| 3 ATTACHED ARCHED PERGOLA KITS WITH WALL MOUNTED ANCHORS. www.ForeverRedwood.com...
- Page 5 5/16´´ X 3´´ Lag Bolts Step 2: Attach the wall mounted anchors (10) to the wall with ½´´ X 4´´ anchor bolts (H) (for concrete wall) or lag bolts (for wood wall). P| 4 ATTACHED ARCHED PERGOLA KITS WITH WALL MOUNTED ANCHORS. www.ForeverRedwood.com...
- Page 6 Step 4: Place the supports with in-between blocking (3), into the post notches as shown and attach to the posts with the single support bolts (C). Each part has a series of numbers that indicate where to attach the part with the corresponding number. P| 5 ATTACHED ARCHED PERGOLA KITS WITH WALL MOUNTED ANCHORS. www.ForeverRedwood.com...
- Page 7 3/8´´ X 6 ½´´ Bolts Step 6: Use 5/16´´ x 3 ½´´ lag bolts (H) to attach the wall mounted anchors (10) to the supports. 5/16´´ X 3 ½´´ Lag Bolts P| 6 ATTACHED ARCHED PERGOLA KITS WITH WALL MOUNTED ANCHORS. www.ForeverRedwood.com...
- Page 8 Step 8: Attach the secondary knee braces (6) to the posts with 3/8´´ x 9´´ bolts (F) and to the arched rafters with 5/16´´ x 5´´ bolts (E). Each part has a series of numbers that indicate where to attach the part with the corresponding number. 5/16´´ X 5´´ Bolt 3/8´´ X 9´´ Bolt P| 7 ATTACHED ARCHED PERGOLA KITS WITH WALL MOUNTED ANCHORS. www.ForeverRedwood.com...
- Page 9 Step 10: Use 8´´ x 3´´ deck screws (G) to attach the other arched rafters (4) to the supports. Each part has a series of numbers that indicate where to attach the part with the corresponding number. 8´´ X 3´Deck Screws P| 8 ATTACHED ARCHED PERGOLA KITS WITH WALL MOUNTED ANCHORS. www.ForeverRedwood.com...
- Page 10 Step 11: Use 8´´ x 3´´ deck screws (G) to attach the slats (7) to the arched rafters. Each part has a series of numbers that indicate where to attach the part with the corresponding number. 8´´ X 3´Deck Screws P| 9 ATTACHED ARCHED PERGOLA KITS WITH WALL MOUNTED ANCHORS. www.ForeverRedwood.com...
- Page 11 Step 13.1: Attach a row of lattice panels (8) with 8´´ x 3´´ deck screw (G). 8´´ X 3´Deck Screws P| 10 ATTACHED ARCHED PERGOLA KITS WITH WALL MOUNTED ANCHORS. www.ForeverRedwood.com...
- Page 12 8´´ X 3´Deck Screws Repeat the operation until the installation is complete. 14: Finally, attach the boots (9) to the posts with 8´´ x 3´´ deck screws (G). 8´´ X 3´Deck Screws P| 11 ATTACHED ARCHED PERGOLA KITS WITH WALL MOUNTED ANCHORS. www.ForeverRedwood.com...
- Page 13 This completes the Pergola assembly. Hope you enjoy your set for many decades. If you ever have a problem or a question, don't hesitate to call us (866 332 2403) or email us. We are here to support you. P| 12 ATTACHED ARCHED PERGOLA KITS WITH WALL MOUNTED ANCHORS. www.ForeverRedwood.com...
- Page 14 Step 1: First remove the deck screws to remove the boots of the post. Don´t add the lag bolt over the trim piece initially. Step 2: Loosen the nut on the bolt support. P| 13 ATTACHED ARCHED PERGOLA KITS WITH WALL MOUNTED ANCHORS. www.ForeverRedwood.com...
- Page 15 Step 3: The bolt of the post and the brace must be flush with the post. Bolt. Step 4: Swing the brace aside. After that, remove the trim. Note: The dimensions of the trim are standard, adjust if necessary. P| 13 ATTACHED ARCHED PERGOLA KITS WITH WALL MOUNTED ANCHORS. www.ForeverRedwood.com...
