User Manual
AIMB-586
Intel® Xeon® E3/Core™ i7/i5/i3
LGA1151 MicroATX with HDMI / 2
DP / eDP(LVDS), 6 COM, Quad
LAN, DDR4, PCIe x 16, PCIe x 8
and SATAIII, 4 x USB3.1(Gen2),
6 USB 2.0, 2USB3.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AIMB-586 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Advantech AIMB-586

Summary of Contents for Advantech AIMB-586

  • Page 1 User Manual AIMB-586 Intel® Xeon® E3/Core™ i7/i5/i3 LGA1151 MicroATX with HDMI / 2 DP / eDP(LVDS), 6 COM, Quad LAN, DDR4, PCIe x 16, PCIe x 8 and SATAIII, 4 x USB3.1(Gen2), 6 USB 2.0, 2USB3.0...
  • Page 2 The documentation and the software included with this product are copyrighted 2019 by Advantech Co., Ltd. All rights are reserved. Advantech Co., Ltd. reserves the right to make improvements in the products described in this manual at any time without notice.
  • Page 3 Whether your new Advantech equipment is destined for the labo- ratory or the factory floor, you can be assured that your product will provide the reliability and ease of operation for which the name Advantech has come to be known.
  • Page 4 Intel Pentium® Pro- 3.7G 14nm LGA1151 PASS WG2/QG2/L cessor G5400 Intel Pentium® Pro- 3.1G 14nm LGA1151 PASS WG2/QG2/L cessor G5400T Intel Celeron® 3.1G 14nm LGA1151 PASS QG2/WG2/L Processor G4900 Intel Celeron® 2.9G 14nm LGA1151 PASS QG2/WG2/L Processor G4900T AIMB-586 User Manual...
  • Page 5 Because of Advantech’s high quality-control standards and rigorous testing, most of our customers never need to use our repair service. If an Advantech product is defec- tive, it will be repaired or replaced at no charge during the warranty period. For out- of-warranty repairs, you will be billed according to the cost of replacement materials, service time and freight.
  • Page 6 It should be free of marks and scratches and in perfect working order upon receipt. As you unpack the AIMB-586, check it for signs of ship- ping damage. (For example, damaged box, scratches, dents, etc.) If it is damaged or it fails to meet the specifications, notify our service department or your local sales representative immediately.

  • Page 7: Table Of Contents

    Board layout: Jumper and Connector Locations ........5 Figure 1.1 Jumper and Connector Location ........ 5 Figure 1.2 I/O Connectors ............5 AIMB-586 Board Diagram ................. 6 Figure 1.3 AIMB-586 Block Diagram ........... 6 Safety Precautions ..................7 Jumper Settings ..................7 1.8.1 How to Set Jumpers..............
  • Page 8 Chipset Software Installation Utility Before You Begin..................74 Introduction ..................... 74 Windows 10 Driver Setup ............... 75 Chapter VGA Setup ......... 77 Introduction ..................... 78 Windows 10 VGA Driver Installation ............78 Chapter LAN Configuration ......79 AIMB-586 User Manual viii...
  • Page 9 COM3 ~ COM6 box header (COM3456)..........101 Table B.20:COM3 ~ COM6 box header (COM3456) ....101 B.21 SMBUS connector from PCH (SMBUS1)..........101 Table B.21:SMBUS connector from PCH (SMBUS1) ....101 B.22 USB 2.0 Connector (USB1112) ............102 AIMB-586 User Manual...
  • Page 10 Table B.47:Case Open selection pin header (JCASEOP_SW1) ..B.48 Case Open connector (JCASE1) ............116 Table B.48:Case Open connector (JCASE1) ......116 B.49 ATX 8 Pin main power connector (ATX12V2)........117 Table B.49:ATX 8 Pin main power connector (ATX12V2) ..117 AIMB-586 User Manual...
  • Page 11 COM1_RI# Pin RI# / 5V / 12V selection (JSETCOM1_V1) ....124 Table B.66:COM1_RI# Pin RI# / 5V / 12V selection (JSETCOM1_V1)............ 124 B.66 LVDS Panel Voltage Selection (JLVDS1) ..........125 Table B.67:LVDS Panel Voltage Selection (JLVDS1) ..... 125 AIMB-586 User Manual...
  • Page 12 AIMB-586 User Manual...

  • Page 13: Chapter 1 General Information

    Chapter General Information...

  • Page 14: Introduction

    (Gen 3) BOM option to 2 x PCIe x8 slot (Gen 3), 1 x PCIe x4 slot (Gen 3), 1 x PCIe x1 slot (Gen 3), 6 USB 2.0 ports and 6 USB 3.1 ports.  Standard Micro ATX form factor with industrial features: The AIMB-586 is a full featured Micro ATX motherboard with balanced expandability and perfor- mance.

  • Page 15: Input/Output

    Note! 6 USB 3.1 4 ports in rear support to USB 3.1 (gen2); 2 ports on board support to USB 3.1 (gen1)  GPIO: AIMB-586 supports 16-bit GPIO from super I/O for general purpose con- trol application. 1.3.4 Graphics ...

  • Page 16: Jumpers And Connectors

    Board weight: 0.365 kg Jumpers and Connectors Connectors on the AIMB-586 motherboard link it to devices such as hard disk drives and a keyboard. In addition, the board has a number of jumpers used to configure your system for your application.

  • Page 17: Board Layout: Jumper And Connector Locations

    Digital Audio connector 4 x 1 header pitch = 2.54 mm LPC1 Low pin count interface (2 x 7 pin header) Board layout: Jumper and Connector Locations Figure 1.1 Jumper and Connector Location Figure 1.2 I/O Connectors AIMB-586 User Manual...

  • Page 18: Aimb-586 Board Diagram

    AIMB-586 Board Diagram Figure 1.3 AIMB-586 Block Diagram AIMB-586 User Manual...

  • Page 19: Safety Precautions

    1, 2, and 3. In this case you connect either pins 1 and 2, or 2 and 3. A pair of needle-nose pliers may be useful when set- ting jumpers. AIMB-586 User Manual...

  • Page 20: Cmos Clear (Cmos1)

    1.8.2 CMOS Clear (CMOS1) The AIMB-586 motherboard contains a jumper that can erase CMOS data and reset the system BIOS information. Normally this jumper should be set with pins 1-2 closed. If you want to reset the CMOS data, set CMOS1 to 2-3 closed for just a few seconds, and then move the jumper back to 1-2 closed.

  • Page 21: Jusbpwr1-2 (Usb Power Selection Connector)

    Table 1.7: JIR1+JOB1+JWD1: Watchdog Timer Output and OBS Alarm Connector Pin Name Watch dog reset# output IRRX System reset input# SIO Warning Beep output IRTX SP1 Buzzer Beep input Note: Watch dog time-out reset# (4-6 short) / SIO Warning Beep enable (8-10 short) AIMB-586 User Manual...

  • Page 22: Jsetcom2: Com2 Rs232, Rs422, Rs485 Selection

    (3-4) (9-11) (10-12) (15-17) (16-18) RS-485 Mode (1-2) (9-11) (10-12) (15-17) (16-18) 1.8.8 JCASE1: Case Open Sensor The AIMB-586 motherboard contains a jumper that provides a chassis open sensor. The buzzer on the motherboard beeps when the case is opened. AIMB-586 User Manual...

  • Page 23: Jcaseop_Sw1: Case Open Selection Pin Header

    Jumper position for +12V System Memory AIMB-586 has four 288-pin memory sockets for 2666/2400 MHz memory modules with maximum capacity of 64 GB (Maximum 16 GB for each DIMM). AIMB-586QG2/ L supports only non-ECC DDR4 memory modules and do not support registered DIMMs (RDIMMs).

  • Page 24: Cache Memory

    1.11 Cache Memory The AIMB-586 supports a CPU with one of the following built-in full speed L3 caches: 12MB for Intel Xeon E-2176G 8MB for Intel Xeon E-2124G 12MB for Intel Core i7 8700 12MB for Intel Core i7 8700T...

  • Page 25: Chapter 2 Connecting Peripherals

    Chapter Connecting Peripherals...

  • Page 26: Introduction

    USB Ports (LAN1_USB12/LAN2_USB34/LAN3/ LAN4/USB5678/USB910/USB1112/USB1314 The AIMB-586 provides up to 14 USB ports. The USB interface complies with USB Specification Rev 2.0 supporting transmission rates up to 480 Mbps and Rev 3.0 sup- porting transmission rate up to 5 Gbps, Rev 3.1 Gen2 supporting transmission rate up to 10 Gbps and is fuse protected.

  • Page 27: Usb Power Switch (Jusbpwr1/Jusbpwr2)

    USB Power Switch (JUSBPWR1/JUSBPWR2) AIMB-586 allows users to set USB power between +5 VSB and +5 V. When the jumper is set as +5 V (default 2-3 pin), the board doesn't support wake from S3 via keyboard or mouse. If you need to set it to +5 Vsb, you need to modify the jumper (1- 2 pin) .

  • Page 28: Com1/Hdmi/Dp1/Dp2 Connector

    COM1/HDMI/DP1/DP2 Connector AIMB-586 includes COM1 and HDMI, DP interfaces that can drive conventional COM1 and HDMI, DP displays. COM1 is a standard 9-pin connector support RS-232. Pin assignments for COM1 and HDMI, DP connectors are detailed in Appendix B. DP max resolution support to 4096 x 2304 @ 60 Hz HDMI default is support to HDMI 1.2.

  • Page 29: Serial Ports (Com1~Com6)

    Serial Ports (COM1~COM6) AIMB-586 supports six serial ports. COM1, COM2, COM4-6 supports RS-232. COM2 supports RS-232/422/485 (with 5V/12V power). JSETCOM2 is used to select the RS- 232/422/485 mode for COM2. These ports can connect to serial devices, such as a mouse or a printer, or to a com- munications network.

  • Page 30: Ps/2 Keyboard And Mouse Connector

    6-pin mini-DIN connectors (KBMS1, 2.54pitch) is for supporting the PS/2 keyboard and PS/2 mouse by a cable P/N 1700018699. CPU Fan Connector (CPU_FAN1) If a fan is used, this connector supports cooling fans of 1500 mA (18 W) or less. AIMB-586 User Manual...

  • Page 31: System Fan Connector (Sysfan1/2/3/4)

    BOM optional. Please notice that, system fan 3 and system fan 4 can't be read rota- tional speed in BIOS. And system fan 3 will be controlled with system fan 1, system fan 4 will be controlled with system fan 2. AIMB-586 User Manual...

  • Page 32: Front Panel Connectors (Jfp1/Jfp2)

    External speaker (JFP1/SPEAKER) JFP2/SPEAKER is a 4-pin connector for an external speaker. If there is no external speaker, the AIMB-586 provides an onboard buzzer as an alternative. To enable the buzzer, set pins 7 & 10 as closed. AIMB-586 User Manual...

  • Page 33: Power Led And Keyboard Lock Connector

    Off ( Windows 7) System Off Slow Flashes (Window 8) Fast flashes Slow flashes 2.10 Line Out, Mic In Connector (AUDIO1) Note! Note: default audio support 2 ports. But can BOM option to support 3 ports.(line-in/line out/ Mic in) AIMB-586 User Manual...

  • Page 34: Digital Audio Connector (Spdif_Out1)

    This connector is for the S/PDIF audio module to allow digital output sound. Connect one end of the S/PDIF audio cable to this connector and the other end to the S/PDIF module. Note! The S/PDIF module should be purchased separately by end user. AIMB-586 User Manual...

  • Page 35: Serial Ata Interface (Sata1 ~ Sata8)

    2.12 Serial ATA Interface (SATA1 ~ SATA8) AIMB-586 features a high performance Serial ATA III interface (up to 600 MB/s) which eases hard drive cabling with thin, space-saving cables.In QG2,WG2 sku, SATA1 colay with M.2 E-key SATA interface. If M.2 E-key with PCIe interface, SATA1 can be used normally.

  • Page 36: 8-Pin Alarm Board Connector (Volt1)

    2.14 PCI Express x16 Slot / PCI Express x 8 AIMB-586 provides a PCIe x16 slot ,which can BOM option to 2 PCIex8 for users to install add-on cards when their applications require higher graphic performance than the CPU embedded graphics controller can provide.

  • Page 37: Front Panel Audio Connector (Fpaud1)

    I/O module cable. Note! For motherboards with the optional HD Audio feature, we recommend that you connect a high-definition front panel audio module to this con- nector to take advantage of the motherboard’s high definition audio capability. AIMB-586 User Manual...

  • Page 38: Atx Power Connector (Eatxpwr1, Atx12V1)

    For a fully configured system, we recommend that you use a power supply unit (PSU) that complies with ATX 12 V Specification 2.0 (or later version) and provides a minimum power of 180 W. AIMB-586 can support 12V DC-in @ ATX12V3 by HW BOM option. AIMB-586 User Manual...

  • Page 39: General Purpose I/O Connector (Gpio1)

    2.17 General purpose I/O Connector (GPIO1) 2.18 eDP/LVDS Connector (eDP1) AIMB-586 User Manual...

  • Page 40: Edp Backlight Inverter(Inv1)

    2.20 M.2 (E-key)/ M.2 (M-key)  M.2 M-key : 2280, support SATA or PCIex4 interface, and can support NVMe devices.  M.2 E-key: 2230, support USB, PCIex1 interface, can support wifi module devices and Intel CNVi module. AIMB-586 User Manual...

  • Page 41: Bios Operation

    Chapter BIOS Operation...

  • Page 42: Introduction

    AIMB-586 setup screens. BIOS Setup The AIMB-586 Series system has AMI BIOS built in, with a SETUP utility that allows users to configure required settings or to activate certain system features. The SETUP saves the configuration in the FLASH of the motherboard. When the power is turned off, the battery on the board supplies the necessary power to pre- serve the FLASH.

  • Page 43: Main Menu

    System Date using the <Arrow> keys. Enter new values through the keyboard. Press the <Tab> key or the <Arrow> keys to move between fields. The date must be entered in MM/DD/YY format. The time must be entered in HH:MM:SS format. AIMB-586 User Manual...

  • Page 44: Advanced Bios Features

    3.2.2 Advanced BIOS Features Select the Advanced tab from the AIMB-586 setup screen to enter the Advanced BIOS Setup screen. You can select any of the items in the left frame of the screen, such as CPU Configuration, to go to the sub menu for that item. You can display an Advanced BIOS Setup option by highlighting it using the <Arrow>...
  • Page 45  Security Device Support [ Disable ] Note! TCG EFI Protocol and INT1A interface won't be available. AIMB-586 User Manual...
  • Page 46 Select ACPI sleep state the system will enter when the SUSPEND button is pressed.  Lock Legacy Resources [ Disabled ] Enables or Disables Lock of Legacy Resources.  S3 Video Repost [ Disabled ] Enable or Disable S3 Video Repost. AIMB-586 User Manual...
  • Page 47 3.2.2.3 PCH FW Configuration  MEDS BIOS Status Code [ Disable ]  Firmware update Configuration – ME FW Image Re-Flash [ Disabled ] AIMB-586 User Manual...
  • Page 48 MEBx Debug Message Output [ Disabled ] Enable MEBx debug message output. – Un-Configure ME [ Disabled ] Sets this item to [Disabled] to unconfigure AMT/ME without using a password or set it as [Enabled] to use a password. AIMB-586 User Manual...
  • Page 49 3.2.2.5 NCT6776 Super IO Configuration  Super IO Chip [ NCT6776 ]  Serial Port 1 Configuration AIMB-586 User Manual...
  • Page 50 To select an optimal setting for serial port 1.  Serial Port 2 Configuration – Serial Port [ Enabled ] – Device Settings: IO=2F8h; IRQ =3 – Change Setting [ Auto ] To select an optimal setting for serial port 2. AIMB-586 User Manual...
  • Page 51 NCT5114DSEC Super IO Configuration – Serial Port [ Enabled ] To “enable or disable” Serial Port 3. – Device Settings: IO=240H; IRQ=5 – Change Settings [ Auto ] To select an optimal setting for serial port 3. AIMB-586 User Manual...
  • Page 52  Serial Port 4 Configuration – Serial Port [Enabled] To "enable or disable" serial port 4. – Device Settings: IO=248H; IRQ=5 – Change Settings [ Auto ] To select an optimal setting for serial port 4. AIMB-586 User Manual...
  • Page 53  Serial Port 5 Configuration – Serial Port [Enabled] To “enable or disable” serial port 5. – Device Settings: IO=250H; IRQ=5 – Change Settings [ Auto ] To select an optimal setting for serial port 5. AIMB-586 User Manual...
  • Page 54 Serial Port 6 Configuration – Serial Port [ Enabled ] To “enable or disable” serial port 6. – Device Settings: IO=258H; IRQ=5 – Change Setting [ Auto ] To select an optimal setting for serial port 6. AIMB-586 User Manual...
  • Page 55 ACPI Shutdown Temperature [ Disabled ] Use this to set the ACPI shutdown temperature threshold. When the system reaches the shutdown temperature, it will be automatically shut down by ACPI OS to protect the system from overheating damage. AIMB-586 User Manual...
  • Page 56 CPU FAN Mode [ SMART FAN IV Mode ] The item shows you CPU temperature and fan speed (PWM) information.  SYSFAN Mode [ SMART FAN IV Mode ] The item shows you system temperature and fan speed (PWM) information. AIMB-586 User Manual...
  • Page 57  Digital I/O Configuration – Digital I/O Pin 1 - 16 [ Input ] AIMB-586 User Manual...
  • Page 58 3.2.2.8 S5RTC Wake Settings The item allow you enable or disable system wake up on alarm event.  Wake system with Fixed Time [ Disabled ] Note! When enabled, system will wake up on the specified time. AIMB-586 User Manual...
  • Page 59 3.2.2.9 Serial Port Console Redirection  Console Redirection [ Disabled ] Enable or disable the console redirection feature AIMB-586 User Manual...
  • Page 60 3.2.2.10 Network Stack Configuration[Disabled]  Enable/Disable UEFI Network Stack Note! When network stack [enable], item must enable: LANx PXE OpROM [enable] AIMB-586 User Manual...
  • Page 61 1. Re-install your OS as UEFI Mode 2. Change all of settings above as " Legacy" * Boot option filter-> Legacy Only * Network -> Legacy * Storage -> Legacy * Video -> Legacy * Other PCI devices -> Legacy AIMB-586 User Manual...
  • Page 62  USB Mass Storage Driver Support [ Enabled ]  USB hardware delays and time-outs USB Device transfer & reset time-out and delay setting.  Mass Storage Devices [ Auto ] Shows USB mass storage device information. AIMB-586 User Manual...

  • Page 63: Chipset Configuration Setting

    <Arrow> keys. All Chipset Setup options are described in this section. The Chipset Setup screens are shown below. The sub menus are described on the following pages. 3.3.1 System Agent (SA) Configuration AIMB-586 User Manual...
  • Page 64  VT-d [ Enabled ] Disable or enable VT-d function on MCH. AIMB-586 User Manual...
  • Page 65 The triple display can only working PASS under Windows 10, the 2nd and 3rd display can not work under DOS. Here is 2-3 displays combination table and all of these combinations are verified and tested properly already. AIMB-586 User Manual...
  • Page 66 PASS PASS PASS PASS HDMI PASS PASS PASS Dual Display DP1/DP2+HDMI PASS DP1+DP2 PASS DP1/DP2+EDP PASS eDP+HDMI PASS Triple Display DP1+HDMI+DP2 PASS DP1+HDMI+eDP PASS DP2+eDP+HDMI PASS 3.3.1.2 DMI Configuration  DMI MAx Link Speed [ Auto ] AIMB-586 User Manual...
  • Page 67 Root Port Preset Value Per lane for Gen3 Equalization.  PEG Gen3 Endpoint Preset Value each Lane Endpoint Preset Value Per lane for Gen3 Equalization.  PEG Gen3 Endpoint Hint Value each Lane Endpoint Hint Value Per lane for Gen3 Equalization. AIMB-586 User Manual...
  • Page 68  Max TOLUD [ Dynamic ] Maximum Value of TOLUD. Dynamic assignment would adjust TOLUD auto- matically based on largest MMIO length of installed graphic controller.  Fast Boot [Enabled] Enable or disable Fast Boot support. AIMB-586 User Manual...

  • Page 69: Pch-Io Configuration

    Enable or disable PCIE to wake the system from S5.  High Precision Timer [ Enabled ] Enable or Disable High Precision Timer.  State After G3 [ Power Off ] This item allows users to select off, on and last state. AIMB-586 User Manual...
  • Page 70 PCI Express Clock Gating [ Enabled ] Enable or Disable PCI Express clock gating for each port.  PCIe-USB Glitch W/A [ Disabled ] PCIe-USB Glitch W/A for bad USB device(s) connected behind PCIE/PEG Port.  M.2 E -key slot AIMB-586 User Manual...
  • Page 71 Set the ASPM Level: Force L0s - Force all links to L0s State : AUTO - BIOS auto configure : DISABLE - Disables ASPM – L1 Substates PCI Express L1 Substates settings. – PCIe Speed [ Auto ] Select PCI Express port speed. AIMB-586 User Manual...
  • Page 72  LAN3 Controller  LAN4 Controller AIMB-586 User Manual...
  • Page 73 Set the ASPM Level: Force L0s - Force all links to L0s State : AUTO - BIOS auto configure : DISABLE - Disables ASPM – L1 Substates PCI Express L1 Substates settings. – PCIe Speed [ Auto ] Select PCI Express port speed. AIMB-586 User Manual...
  • Page 74 Set the ASPM Level: Force L0s - Force all links to L0s State : AUTO - BIOS auto configure : DISABLE - Disables ASPM – L1 Substates PCI Express L1 Substates settings. – PCIe Speed [ Auto ] Select Mini PCI Express port speed. AIMB-586 User Manual...
  • Page 75 3.3.2.2 SATA and RST Configuration AIMB-586 User Manual...

  • Page 76: Security Setting

    Select this option and press <ENTER> to access the sub menu, and then type in the password. Set the Administrator password.  User Password Select this option and press <ENTER> to access the sub menu, and then type in the password. Set the User Password. AIMB-586 User Manual...

  • Page 77: Boot Setting

    Quiet Boot [ Disabled ] If this option is set to disabled, the BIOS displays normal POST messages. If enabled, an OEM logo is shown instead of POST messages.  Boot Option #1/#2 Choose boot priority from boot device AIMB-586 User Manual...

  • Page 78: Save & Exit Configuration

    Select Exit Saving Changes from the Exit menu and press <Enter>. The fol- lowing message appears: Save Configuration Changes and Exit Now? [Ok] [Cancel] Select Ok or cancel.  Discard Changes and Reset Select this option to quit Setup without making any permanent changes to the system configuration. AIMB-586 User Manual...
  • Page 79 Defaults if the user's computer is experiencing system configuration problems. Select Restore Defaults from the Exit menu and press <Enter>.  Save as User Default Save the all current settings as a user default.  Restore User Default Restore all settings to user default values. AIMB-586 User Manual...
  • Page 80 AIMB-586 User Manual...

  • Page 81: Software Introduction & Service

    Chapter Software Introduction & Service...

  • Page 82: Introduction

    Introduction The mission of Advantech Embedded Software Services is to "Enhance quality of life with Advantech platforms and Microsoft® Windows® embedded technology." We enable Windows® Embedded software products on Advantech platforms to more effectively support the embedded computing community. Customers are freed from the hassle of dealing with multiple vendors (hardware suppliers, system integrators, embedded OS distributors) for projects.
  • Page 83 System Throttling Refers to a series of methods for reducing power consump- tion in computers by lowering the clock frequency. This API allows the user to adjust the clock from 87.5% to 12.5%. AIMB-586 User Manual...

  • Page 84: Software Utility

    Monitoring is a utility for customers to monitor system health, like voltage, CPU and system temperature and fan speed. These items are important to a device, if critical errors occur and are not solved immediately, permanent damage may be caused. AIMB-586 User Manual...

  • Page 85: Chipset Software Installation Utility

    Chapter Chipset Software Installation Utility...

  • Page 86: Before You Begin

    Before You Begin To facilitate the installation of the enhanced display drivers and utility software, read the instructions in this chapter carefully. The drivers for AIMB-586 are located on Advantech website. (http://support.advantech.com/Support/.) Updates are provided via Service Packs from Microsoft*.

  • Page 87: Windows 10 Driver Setup

    Windows 10 Driver Setup When enter the website of Advantech, then search product AIMB-586. There is "Chipset" driver inside. AIMB-586 User Manual...
  • Page 88 AIMB-586 User Manual...

  • Page 89: Vga Setup

    Chapter VGA Setup...

  • Page 90: Introduction

    Before installing this driver, make sure the CSI utility has been installed in your system. See Chapter 5 for information on installing the CSI utility. When enter the website of Advantech, then search product AIMB-586. There is "Graphic" driver inside. AIMB-586 User Manual...

  • Page 91: Lan Configuration

    Chapter LAN Configuration...

  • Page 92: Introduction

    Introduction The AIMB-586 has dual Gigabit Ethernet LANs via dedicated PCI Express x1 lanes (Intel I219LM (LAN1), I211AT (LAN2), Realtek 8111G (LAN3/LAN4)) that offer band- width of up to 500 MB/sec, eliminating the bottleneck of network data flow and incor- porating Gigabit Ethernet at 1000 Mbps.

  • Page 93: Windows® 10 Driver Setup (Intel I219Lm/ Intel I211At)

    Windows® 10 Driver Setup (Intel I219LM/ Intel I211AT) When enter the website of Advantech, then search product AIMB-586. There is "LAN" driver inside. AIMB-586 User Manual...
  • Page 94 AIMB-586 User Manual...
  • Page 95 Appendix Programming the Watchdog Timer...

  • Page 96: Appendix A Programming The Watchdog Timer

    Programming the Watchdog Timer AIMB-586's watchdog timer can be used to monitor system software operation and take corrective action if the software fails to function within the programmed period. This section describes the operation of the watchdog timer and how to program it.
  • Page 97 Unlock NCT6776 Select register of watchdog timer Enable the function of the watchdog timer Use the function of the watchdog timer Lock NCT6776 AIMB-586 User Manual...
  • Page 98 Bit 5: Write 1 to generate a timeout signal immedi- ately and automatically return to 0. [default=0] Bit 4: Read status of watchdog timer, 1 means timer is “timeout”. Write this address to I/O port 2E (hex) to lock the AA (hex) ----- watchdog timer 2. AIMB-586 User Manual...

  • Page 99: Example Program

    Inc dx Mov al,10 Out dx,al ;----------------------------------------------------------- Dec dx ; Lock NCT6106D Mov al,0aah Out dx,al Enable watchdog timer and set 5 minutes as timeout interval ;----------------------------------------------------------- Mov dx,2eh ; Unlock NCT6776 Mov al,87h Out dx,al Out dx,al AIMB-586 User Manual...
  • Page 100 Enable watchdog timer to be reset by mouse ;----------------------------------------------------------- Mov dx,2eh ; Unlock NCT6776 Mov al,87h Out dx,al Out dx,al ;----------------------------------------------------------- Mov al,07h ; Select registers of watchdog timer Out dx,al Inc dx Mov al,08h Out dx,al ;----------------------------------------------------------- AIMB-586 User Manual...
  • Page 101 Dec dx ; Enable the function of watchdog timer Mov al,30h Out dx,al Inc dx Mov al,01h Out dx,al ;----------------------------------------------------------- Dec dx ; Enable watchdog timer to be strobed reset by keyboard Mov al,0f7h Out dx,al Inc dx In al,dx Or al,40h Out dx,al AIMB-586 User Manual...
  • Page 102 Dec dx ; Generate a time-out signal Mov al,0f7h Out dx,al ;Write 1 to bit 5 of F7 register Inc dx In al,dx Or al,20h Out dx,al ;----------------------------------------------------------- Dec dx ; Lock NCT6776 Mov al,0aah Out dx,al AIMB-586 User Manual...

  • Page 103: Appendix B Pin Assignments

    Appendix Pin Assignments...

  • Page 104: High Definition Multimedia Interface (Hdmi1)

    HDMI1_Z_CLK- HDMI1_Z_D2- HDMI1_Z_D1+ HDMI1_SCL HDMI1_Z_D1- HDMI1_SDA HDMI1_Z_D0+ +V5_HDMI HDMI1_Z_D0- HDMI1_HPD HDMI1_Z_CLK+ COM1 connector (COM1) Table B.2: COM1 connector (COM1) Signal Signal DCD# [1] DSR# [1] RXD [1] RTS# [1] TXD [1] CTS# [1] DTR# [1] RI# [1] AIMB-586 User Manual...

  • Page 105: Displayport1 (Dp1)

    Signal Signal DCD# [1] RXD [1] DP1_3- TXD [1] DP1_AUX_EN# DTR# [1] DP1_AUX+ DP1_AUX- DP1_HPD +V3.3_DP1 DisplayPort2 (DP2) Table B.4: DisplayPort2 (DP2) Signal Signal DP2_0+ DP2_3- DP2_0- DP2_AUX_EN# DP2_1+ DP2_AUX+ DP2_1- DP2_2+ DP2_AUX- DP2_HPD DP2_2- DP2_3+ +V3.3_DP1 AIMB-586 User Manual...

  • Page 106: Rj45 Port 3/Port4 Connector (Lan34)

    MDI_LAN4_DN2 MDI_LAN3_DN0 MDI_LAN4_DP3 MDI_LAN3_DP1 MDI_LAN4_DN3 MDI_LAN3_DN1 LAN4_CON MDI_LAN3_DP2 MDI_LAN3_DN2 LAN4_LED0_100M# MDI_LAN3_DP3 LAN4_LED2_1G# MDI_LAN3_DN3 +V3.3_DUAL LAN3_CON LAN4_LED1_ACT# LAN3_LED2_100M# MDI_LAN4_DP0 LAN3_LED1_1G# MDI_LAN4_DN0 +V3.3_DUAL MDI_LAN4_DP1 LAN3_LED0_ACT# MDI_LAN4_DN1 MDI_LAN4_DP2 Universal Serial Bus Port 5 / 6 / 7 / 8 (USB5678) AIMB-586 User Manual...

  • Page 107: Rj45 + Usb3.1 Stack Connector (Lan1_Usb12)

    Table B.7: RJ45 + USB3.1 stack connector (LAN1_USB12) Signal Signal VBUS (*) VBUS (*) D-_1 D-_2 D+_1 D+_2 RX-_1 RX-_2 RX+_1 RX+_2 TX-_1 TX-_2 TX+_1 TX+_2 (*) Depends on JUSBPWR2 Jump Setting Signal Signal MDI_0+ MDI_2+ MDI_0- MDI_2- MDI_1+ MDI_3+ MDI_1- MDI_3- AIMB-586 User Manual...

  • Page 108: Rj45 + Usb3.0 Stack Connector (Lan2_Usb34)

    Table B.8: RJ45 + USB3.0 stack connector (LAN2_USB34) Signal Signal VBUS (*) VBUS (*) D-_3 D-_4 D+_3 D+_4 RX-_3 RX-_4 RX+_3 RX+_4 TX-_3 TX-_4 TX+_3 TX+_4 (*) Depends on JUSBPWR1 Jump Setting Signal Signal MDI_0+ MDI_2+ MDI_0- MDI_2- MDI_1+ MDI_3+ MDI_1- MDI_3- AIMB-586 User Manual...

  • Page 109: Hd Audio Interface (Audio1)

    Table B.10: Front panel audio pin header (FPAUD1) Signal Signal MIC IN-L MIC IN-R FPAUD_DETECT# LINE OUT-R SENSE R1 SENSE LINE OUT-L SENSE R2 B.11 USB Power selection header #1 (JUSBPWR1) Table B.11: USB Power selection header #1 (JUSBPWR1) Signal +VDUAL Advantech define AIMB-586 User Manual...

  • Page 110: Hd Audio Interface (Spdif1)

    LAN1 LED PWR LAN2 LED PWR LAN1 LINK1000 LAN2 LINK1000 LAN1 LINK100 LAN2 LINK100 +3.3VSB B.14 LVDS VESA, JEIDA format selection pin header (JLVDS_VCON1) Table B.14: LVDS VESA, JEIDA format selection pin header (JLVDS_VCON1) Signal +3.3V OPTION AIMB-586 User Manual...

  • Page 111: Lvds Panel Connector (Lvds1)

    LVDS1_A5P LVDS1_A2N LVDS1_A6N LVDS1_A2P LVDS1_A6P LVDS1_CLK1N LVDS1_CLK2N LVDS1_CLK1P LVDS1_CLK2P LVDS1_SCD LVDS1_SDD LVDS1_PIN34 LVDS1_A3N LVDS1_A7N LVDS1_A3P LVDS1_A7P LVDS1_ENBKL LVDS1_VCON B.16 LVDS Panel Voltage Selection (JLVDS1) Table B.16: LVDS Panel Voltage Selection (JLVDS1) Signal Signal +12V EDP1 VDD +3.3V AIMB-586 User Manual...

  • Page 112: Lvds Backlight Inverter Power Connector (Inv1)

    Signal RI# [1] Advantech define Advantech define +12V Advantech define B.19 USB 2.0 Connector (USB910) Table B.19: USB 2.0 Connector (USB910) Signal Signal VBUS (*) VBUS (*) PCIE_USB_D2- PCIE_USB_D1- PCIE_USB_D2+ PCIE_USB_D1+ (*) Depends on JUSBPWR2 Jump Setting AIMB-586 User Manual...

  • Page 113: Com3 ~ Com6 Box Header (Com3456)

    RI# [5] DCD# [6] DSR# [6] RXD [6] RST# [6] TXD [6] CTS# [6] DTR# [6] RI# [6] B.21 SMBUS connector from PCH (SMBUS1) Table B.21: SMBUS connector from PCH (SMBUS1) Signal +5VSB SMB CLK SMB DAT AIMB-586 User Manual...

  • Page 114: Usb 2.0 Connector (Usb1112)

    B.23 Dual port USB3.0 header (USB1314) Table B.23: Dual port USB3.0 header (USB1314) Signal Signal VBUS (*) D+_11 RX-_5 D-_11 RX+_5 TX+_6 TX-_5 TX-_6 TX+_9 RX+_6 D-_10 RX-_6 D+_10 VBUS (*) (*) Depends on JUSBPWR2 Jump Setting AIMB-586 User Manual...

  • Page 115: Cmos Battery Connector (Bat1)

    Table B.24: CMOS battery connector (BAT1) Signal VBAT B.25 COMS Mode selection (JCOMS1) Table B.25: COMS Mode selection (JCOMS1) Signal VBAT RTC RESET# B.26 USB Power selection header #2 (JUSBPWR2) Table B.26: USB Power selection header #2 (JUSBPWR2) Signal +VDUAL Advantech define AIMB-586 User Manual...

  • Page 116: Spi Pin Header (Spi_Cn1)

    B.27 SPI Pin Header (SPI_CN1) Table B.27: SPI Pin Header (SPI_CN1) Signal Signal +3.3VSB SCLK MISO MOSI B.28 Serial ATA interface connector (SATA8) Table B.28: Serial ATA interface connector (SATA8) Signal AIMB-586 User Manual...

  • Page 117: Spi Bios Flash Socket (Spi1)

    SPI BIOS flash socket (SPI1) Table B.29: SPI BIOS flash socket (SPI1) Signal Signal MOSI MISO SCLK WP# / IO2 HOLD# / IO3 +V3.3_SPI B.30 Serial ATA interface connector (SATA7) Table B.30: Serial ATA interface connector (SATA7) Signal AIMB-586 User Manual...

  • Page 118: Power Switch/Hdd Led/Smbus/Speaker Pin Header (Jfp1)

    SMB_CLK System Reset- B.32 Power LED and keyboard lock pin header (JFP2) Table B.32: Power LED and keyboard lock pin header (JFP2) Signal LED Power Keyboard Lock B.33 CIR interface, Watchdog timer output and OBS beep (JIR1+JOBS1+JWDT1) AIMB-586 User Manual...

  • Page 119: (Jir1+Jobs1+Jwdt1)

    Table B.33: CIR interface, Watchdog timer output and OBS beep (JIR1+JOBS1+JWDT1) Signal Signal Watch Dog Reset# output IRRX System Reset input# SIO Warning Beep output SP1 Buzzer Beep IRTX input B.34 AT/ATX Mode selection (PSON1) Table B.34: AT/ATX Mode selection (PSON1) Signal +3.3V AIMB-586 User Manual...

  • Page 120: Alarm Board/Cmm Power Connector (Volt1)

    B.35 Alarm Board/CMM Power Connector (VOLT1) Table B.35: AT/ATX Mode selection (PSON1) Signal +5VSB +3.3V -12V +12V B.36 Serial ATA interface connector (SATA1~6) Table B.36: Serial ATA interface connector (SATA1~6) Signal AIMB-586 User Manual...

  • Page 121: Sata Power Connector (Sata_Pwr1)

    B.37 SATA Power Connector (SATA_PWR1) Table B.37: SATA Power Connector (SATA_PWR1) Signal +V12 AIMB-586 User Manual...

  • Page 122: M.2 E Key Connector (M2E1)

    Connector Key Connector Key Connector Key Connector Key CNV_RGI_DT CNV_RGI_RSP PETp0 CNV_BRI_DT PETn0 PCH_CLINK_RST# PCH_CLINK_DATA PERp0 PCH_CLINK_CLK CNV_GNSS_BLANKI PERn0 CNV_MFUART2_TX CNV_MFUART2_RX REFCLKp0 SUSCLK(32kHz) REFCLKn0 (O)(0/3.3V) PERST0# (O)(0/ 3.3V) CLKREQ0# (I/O)(0/ W_DISABLE2# 3.3V) (O)(0/3.3V) PEWAKE0# (I/O)(0/ W_DISABLE1# 3.3V) (O)(0/3.3V) AIMB-586 User Manual...

  • Page 123: M.2 M Key Connector (M2M1)

    M.2 M Key connector (M2M1) Table B.39: M.2 M Key connector (M2M1) Signal Signal 3.3V 3.3V PERn3 PERp3 DAS/DSS# (I/O)/ LED1# (I)(0/3.3V) PETn3 3.3V PETp3 3.3V 3.3V PERn2 3.3V PERp2 PETn2 PETp2 PERn1 PERp1 PETn1 PETp1 DEVSLP (O) PERn0/SATA-B+ PERp0/SATA-B- AIMB-586 User Manual...

  • Page 124: Sata Power Connector (Sata_Pwr2)

    Connector Key Connector Key Connector Key Connector Key Connector Key Connector Key SUSCLK(32kHz) (O)(0/3.3V) PEDET (NC-PCIe/ 3.3V GND-SATA) 3.3V 3.3V B.40 SATA Power Connector (SATA_PWR2) Table B.40: SATA Power Connector (SATA_PWR2) Signal B.41 ATX 24pin power connector (EATXPWR1) AIMB-586 User Manual...

  • Page 125: Com2 Box Header (Com2)

    +3.3V -12V PSON# PWROK +5VSB +12V +12V +3.3V B.42 COM2 box header (COM2) Table B.42: COM2 box header (COM2) Signal Signal DCD# [2] DSR# [2] RXD [2] RST# [2] TXD [2] CTS# [2] DTR# [2] RI# [2] AIMB-586 User Manual...

  • Page 126: Keyboard & Mouse Connector (Kbms1)

    (JSETCOM2) Table B.44: COM2 RS232, RS422, RS485 selection pin header (JSETCOM2) Signal Signal UART_SIN [2] RXD_RS485 UART_SIN [2] RXD_RS422 UART_SIN [2] RXD_RS232 DCDB SOUT [2] COM2_DCD# COM2_SOUT COM2_TXD485- COM2_RXD485+ SIN [B] DTR [B] COM2_SIN COM2_DTR# COM2_TXD485+ COM2_RXD485- AIMB-586 User Manual...

  • Page 127: Low Pin Count Interface Connector (Lpc1)

    B.45 Low pin count interface connector (LPC1) Table B.45: Low pin count interface connector (LPC1) Signal Signal CLK (24MHz) RESET# FRAME# +3.3V SMB CLK SERIRQ SMB DAT +5VSB AIMB-586 User Manual...

  • Page 128: 16-Bits General Purpose I/O Pin Header (Gpio1)

    +5VSB B.47 Case Open selection pin header (JCASEOP_SW1) Table B.47: Case Open selection pin header (JCASEOP_SW1) Signal Normal Open Advantech define Normal Close B.48 Case Open connector (JCASE1) Table B.48: Case Open connector (JCASE1) Signal Case Open AIMB-586 User Manual...

  • Page 129: Atx 8 Pin Main Power Connector (Atx12V2)

    ATX 4 Pin main power connector (ATX12V1) Table B.50: ATX 4 Pin main power connector (ATX12V1) Signal +12V +12V B.51 CPU FAN connector (CPUFAN1) Table B.51: CPU FAN connector (CPUFAN1) Signal CPU FAN VCC CPU FAN SPEED CPU FAN PWM AIMB-586 User Manual...

  • Page 130: System Fan #3 Connector (Sysfan3)

    Table B.53: System Fan #1 connector (SYSFAN1) Signal SYSTEM FAN VCC SYSTEM FAN SPEED SYSTEM FAN PWM B.54 System Fan #2 connector (SYSFAN2) Table B.54: System Fan #2 connector (SYSFAN2) Signal SYSTEM FAN VCC SYSTEM FAN SPEED SYSTEM FAN PWM AIMB-586 User Manual...

  • Page 131: System Fan #4 Connector (Sysfan4)

    B.55 System Fan #4 connector (SYSFAN4) Table B.55: System Fan #4 connector (SYSFAN4) Signal SYSTEM FAN VCC SYSTEM FAN SPEED SYSTEM FAN PWM AIMB-586 User Manual...

  • Page 132: Usb Power Selection For Usb910, Usb1112, Usb1314 (Jusbpwr2)

    LVDS Panel Voltage Selec- JLVDS1 tion B.56 USB Power selection for USB910, USB1112, USB1314 (JUSBPWR2) Table B.57: USB Power selection for USB910, USB1112, USB1314 (JUSBPWR2) Function Jumper Setting Set USB VBUS as +5VSB (Default) Set USB VBUS as +5V AIMB-586 User Manual...

  • Page 133: Usb Power Selection For Lan1_Usb12, Lan2_Usb34, Usb5678

    Table B.59: LVDS VESA, JEIDA format selection pin header (JLVDS_VCON1) Function Jumper Setting Setting :+V3.3 Setting :GND (Default) B.59 CMOS clear (JCOMS1) Table B.60: CMOS clear (JCOMS1) Function Jumper Setting Keep CMOS Data (Default) Clear CMOS Data AIMB-586 User Manual...

  • Page 134: Pwrbtn#/ Reset#/Hdd Led/ Serial Bus From Hw Monitor Ic/Internal Buzzer / External Speaker Header (Jfp1)

    CIR interface, Watchdog timer output and OBS beep (JIR1+JOBS1+JWDT1) Table B.62: CIR interface, Watchdog timer output and OBS beep (JIR1+JOBS1+JWDT1) Function Jumper Setting Watchdog Timer Output (4-6) (Default) OBS BEEP (8-10) (Default) Watchdog Timer Disable (2-4) OBS BEEP(8-10) (Default) AIMB-586 User Manual...

  • Page 135: At / Atx Mode Selection (Pson1)

    (JSETCOM2) Table B.64: COM2 RS232, RS422, RS485 selection pin header (JSETCOM2) Function Jumper Setting RS-232 Mode (Default) (5-6) (7-9) (8-10) (13-15) (14-16) RS-422 Mode (3-4) (9-11) (10-12) (15-17) (16-18) RS-485 Mode (1-2) (9-11) (10-12) (15-17) (16-18) AIMB-586 User Manual...

  • Page 136: Case Open Selection Pin Header (Jcaseop_Sw1)

    B.65 COM1_RI# Pin RI# / 5V / 12V selection (JSETCOM1_V1) Table B.66: COM1_RI# Pin RI# / 5V / 12V selection (JSETCOM1_V1) Function Jumper Setting Jumper position for RI# (Default) Jumper position for +5V Jumper position for +12V AIMB-586 User Manual...

  • Page 137: Lvds Panel Voltage Selection (Jlvds1)

    B.66 LVDS Panel Voltage Selection (JLVDS1) Table B.67: LVDS Panel Voltage Selection (JLVDS1) Function Jumper Setting Jumper position for 5V Jumper position for 3.3V (Default) Jumper position for 12V AIMB-586 User Manual...
  • Page 138 No part of this publication may be reproduced in any form or by any means, electronic, photocopying, recording or otherwise, without prior written permis- sion of the publisher. All brand and product names are trademarks or registered trademarks of their respective companies. © Advantech Co., Ltd. 2019...

This manual is also suitable for:

Aimb586qg2- 00a1eAimb586wg2- 00a1eAimb-586l00a1e

Table of Contents
