BT8711
PREMIUM BOLT DOWN
TWIN SCREEN VC STAND
INSTALLATION GUIDE
SPECIFICATIONS
• Recommended for screens: 46" - 65" (117 - 165cm)
• Max load: 70kg (154lbs) per screen
• Suitable for displays with fixings up to 600 x 400mm
• Stand dimensions: H.1913 x W.2005 x D.210mm
• Integrated cable management
www.btechavmounts.com
65"
165
CM
PER SCREEN
Advertisement
Table of Contents
Related Manuals for B-Tech Mode-AL BT8711
Summary of Contents for B-Tech Mode-AL BT8711
- Page 1 BT8711 PREMIUM BOLT DOWN TWIN SCREEN VC STAND INSTALLATION GUIDE SPECIFICATIONS • Recommended for screens: 46" - 65" (117 - 165cm) • Max load: 70kg (154lbs) per screen • Suitable for displays with fixings up to 600 x 400mm 65" •...
-
Page 2: Installation Safety Instructions
Please check carefully to make sure there are no missing or defective parts - defective parts must never be used. B-Tech AV Mounts, its distributors and dealers are not liable or responsible for damage or injury caused by improper installation, improper use or failure to observe these safety instructions. In such cases, all guarantees will expire. -
Page 4: Installation Tools Required
BT8711 PARTS LIST PLEASE KEEP THIS FOR FUTURE REFERENCE INSTALLATION TOOLS REQUIRED Drill Pencil Spanner Crosshead Screwdriver Pliers/Cutter... - Page 5 ITEM PART DESCRIPTION 1.9M COLUMN END CAP COLUMN REAR COVER M6 x 12mm HEX SCREW M6 x 12mm GRUB SCREW (OPTIONAL) SQUARE NUT (OPTIONAL) COVER STRIP 3AF HEX KEY 4AF HEX KEY BOLT DOWN BASE M6 x 35mm CSK HEX SCREW 4AF HEX KEY RAIL-TO-COLUMN MOUNTING BRACKET M6 x 40mm CSK HEX SCREW...
-
Page 6: Installation Instructions
INSTALLATION INSTRUCTIONS OPTIONAL FIX REAR COVER TO COLUMNS Place item A3 into the back of item A1. Use items A5 & A6 at the top and bottom of the column slot to secure rear cover. FRONT REAR REAR FIX BASES TO COLUMNS Fix item B1 to the bottom of item A1 using item B2. - Page 7 ATTACH MOUNTING BRACKET TO COLUMNS i. Insert 4 x item C2 into item C1 and attach item C3. Screw two full turns to leave item C3 at the end of item C2. ii. Slide item C1 down the front slots of item A1 to the correct height and tighten items C2. SLOTS...
- Page 8 HOOK RAIL ONTO MOUNTING BRACKETS i. Insert 4 x item C4 into item D1 (2 in the top channel, 2 in the bottom channel) on each side of the rail. M8 SLIDING M8 x 12mm ii. Screw 2 x item C5 into item C4 in the top channel - allow at least a 6mm gap HEX SCREW INSERT so the rail can be hooked on to item C1.
- Page 9 ATTACH END CAPS Fix item A2 onto the top of item A1 using item A4. BOLT STAND TO THE FLOOR Pre-drill holes in floor and using suitable ground anchor fixings (not supplied), fix stand to floor. BASE PLATE FIXING DIMENSIONS 230mm 4 x Ø10.5 FRONT...
- Page 10 ASSEMBLE VC SHELF i. Attach item G2 to item G1 using items G5 & G6. ii. Attach item G10 to item G2. using items G7 & G8. M8 x16mm M8 NYLOC M8 METAL M8 SPRING WASHER HEX SCREW WASHER 13mm Spanner Note: The shelf adaptor can mount the shelf above or below the screens.
- Page 11 HOOK SHELF ONTO MOUNTING RAIL i. Hook item G1 onto item D1. ii. Secure shelf to rail. Use item G4 on the bottom of item G1 to secure the shelf to item D1. Optional: Level the shelf bracket by adjusting item G4 on top of item G1.
- Page 12 ATTACH INTERFACE ARMS TO SCREENS Fix item E1 to the rear of the screens using items E3 - E15. Note: Ensure the arms are facing the correct way round and the same holes are used on all arms. 600mm ADAPTOR ARMS Note: Use (if required) for 65”screens with VESA 600 x 400mm fixings i.
-
Page 13: Attach Camera
LOCK SCREENS TO RAIL ATTACH CAMERA TO SHELF Tighten the safety screws on the bottom Fix camera to item G10 using of item E1 securing the screens to item D1. M4 x 10mm either item G11 or item G12. Note: If necessary, adjust the height adjustment SCREW screws on top of item E1 to level the screen. -
Page 14: Front View
PLEASE KEEP THIS FOR FUTURE REFERENCE FRONT VIEW 180mm 8.4mm 400mm 60.8mm BOTTOM VIEW 10.5mm 60mm 230mm These instructions are intended as a guide only and B-Tech accepts no liability for the accuracy of the information contained in this document. -
