Field Controls Trio Pro User Manual page 8

Operating Instructions
1 .Power On/Off
Press to turn the appliance on or off.
2. Speed
The Speed 1 and " " is fully bright by default after turning on the appliance.
Click on " " to accelerate the fan speed,while " " is to decelerate. Press the
button one time to accelerate or decelerate one gear.
3 .Slide Controls
Control the wind speed according to the speed finger slides .Slide right to increase wind
speed,instead, slide left to decrease wind speed. Fan speed increases by two fan lights,
there are four fan speeds total.
4. Turbo Mode
Press " " or " " until max speed to reach Turbo mode. The " " and all speed
indicators will be fully illuminated.
5. AUTO mode
Press "Auto" to enter AUTO mode. Auto mode will adjust the fan speed automatically
between 1 to 5 according to the air quality level.
6. UVC
The UVC lamp is ON by default when the appliance is turned on. Press the UV button to
turn on or off, indicated by the shield light indicator. If the light is on, the uVC lamp is on,
if the light is off, the UVC lamp is off. When the UVC lamp needs to be replaced, the UVC
indicator will blink notifying the user. After the UVC light is replaced, press, and hold the
UVC light change indicator for 5 seconds to reset the UVC light indicator.
7.Child Lock
After the purifier is turned on, press and hold the UVC button for 3 seconds to turn on the
child lock. Press and hold the UVC shield icon for 3 seconds again to turn child lock off.
While the child lock is on, all buttons will be disabled except to turn off the child lock.
