- Page 1 C864i Caple 78CM Induction Hob Service Manual...
- Page 2 Caple C864I 78cm Induction Hob ADVICE & HELP / AFTER SALES INDUCTION TC LITE SLIDER 1. To detect the wrong breakdowns : 1-1 Connection to the electric network: • Control the tightening of the screws of the connection box • Control the section of the cables used (see manual of use) •...
- Page 3 Caple C864I 78cm Induction Hob 1-2 Installation: • Control the installation of the gasket under the glass. • If the glass is glued with silicone leave the glass in place and dismount the case under the work plan. • Control the ventilation of the air coming in of the ventilators (minimum 2 cm of space).
- Page 4 Caple C864I 78cm Induction Hob To determine the breakdown according to the indications of the control panel. Display Designation Description zero the heating zone is activated 1…9 level of power selection of the cooking level pan detection no pan or inadequate pan...
- Page 5 Caple C864I 78cm Induction Hob 2-2 Locking « L » To lock the hob: Press the key [0/I] (On/Off) Press at once simultaneously the key “P” and the display of the front right cooking zone for 4 zones hobs and rear right cooking zone for 3 zones hobs.
-
Page 6: Error Code
Caple C864I 78cm Induction Hob ERROR CODE Legend: Visual Control No appropriated measure Measure with multimetre Error Code Description Potential Failure Measure What to do… Cooking zone has overheated Temperature sensor indicates (maybe pot boiled without overheat of induction coil A cool down is necessary food,...) - Page 7 Caple C864I 78cm Induction Hob Error Code Description Potential Failure Measure What to do… Overvoltage Check the voltage Network failure Frequency problem Check the frequency Network failure Overvoltage Replace the generator Fan or control electronics Fan failure Replace the generator...
- Page 8 Caple C864I 78cm Induction Hob Error Code Description Potential Failure Measure What to do… No display Wrong connection 400V Defect mains connection Correctly execute mains connection Function Error on Touch Control Component part error replace the generator Pan not adapted...
- Page 9 Caple C864I 78cm Induction Hob Error Code Description Potential Failure Measure What to do… Data not plausible Component part error on Er 20 Flash Rom check sum wrong replace the generator Touch Control Programming options wrong Cooking level Power level returns...
