- Page 1 I n s t r u c t i o n M a n u a l C8 7 3 G, C8 6 6 G & C 8 4 8 G Contact Caple on 0117 938 7420 for spare parts or www.caple.co.uk...
-
Page 2: Table Of Contents
C O N T E N T S Introduction Warnings Environmental Protection Warranty Product Description Using your Gas Hob Cleaning and Maintenance Installation Electrical Connection Technical Specification Caple Contact Details Instruction manual C873G, C866G & C848G Please keep this instruction manual for future reference... -
Page 3: Introduction
I N T R O D U C T I O N the purchase of your new Caple hob. Congratulations on the purchase of your new Caple hob. t you take some time to read this We recommend that you spend some time reading this... -
Page 4: Warnings
O P E R A T I O N A N D M A I N T E N A N C E W A R N I N G S ELECTRICAL SHOCK HAZARD - Do not cook on a broken or cracked hob. If the hob surface Instruction manual C873G, C866G & C848G Please keep this instruction manual for future reference... - Page 5 - Never use your appliance for warming or heating the room. - Do not allow children to play, sit, stand, or climb on the appliance. - Do not store children’s toys in cabinets above the appliance Instruction manual C873G, C866G & C848G Please keep this instruction manual for future reference...
- Page 6 - Do not place or drop heavy objects on your hob. - Do not stand on your hob. - If the supply cord is damaged, it must be replaced by Caple service or similarly qualified persons in order to avoid a hazard.
- Page 7 - Danger of fire: do not store items on the cooking surfaces. - Do not steam clean. - The appliance is not intended to be operated by means of an external timer or separate remote control system. Instruction manual C873G, C866G & C848G Please keep this instruction manual for future reference...
- Page 8 “Installation”). - For any replacements or alterations that may be required, contact Caple Service and use original spare parts only. I M P O R T A N T : The rating label, with the serial number, is affixed to the underside of the hob.
-
Page 9: Environmental Protection
This appliance conforms to all current and applicable energy regulations. To view the Technical Fiche that supports the energy labelling data, please visit the product page on our website www.caple.co.uk Instruction manual C873G, C866G & C848G Please keep this instruction manual for future reference... -
Page 10: Warranty
Registration can also be completed online by visiting www.caple.co.uk. Ensure you keep your warranty card safe, you may need to show it to Caple Service together with proof of purchase. If you fail to show your warranty card you will incur all repair charges. Spare parts are only available from Caple Service and spare parts authorised centres. -
Page 11: Product Description
C 8 6 6 G C 8 8 6 G C 8 7 3 G C 8 7 3 G C 8 7 3 G C 8 7 3 G Instruction manual C873G, C866G & C848G Please keep this instruction manual for future reference... -
Page 12: Using Your Gas Hob
(maximum flame). there is no power supply, it is possible to light the burners with matches, setting the knob to the start-up point (maximum flame). Instruction manual C873G, C866G & C848G Please keep this instruction manual for future reference... - Page 13 › When the burner is lit, check that the flame is even and, before removing pots, always turn down the flame or switch off the burner. Instruction manual C873G, C866G & C848G Please keep this instruction manual for future reference...
-
Page 14: Cleaning And Maintenance
The possible lubrication of the taps must be carried out by specialised personnel only. In case of hardening or malfunctions in the gas taps, contact Caple Service. R E P L A C I N G T H E P O W E R S U P P LY C A B L E Should it be necessary to replace the power supply cable, use a standard type H05VV-F or H05RR-F cable with a section of 3 x 0.75mm... - Page 15 To be carried out by qualified personnel only. (earth) Green-yellow wire I M P O R T A N T : To be carried out by qualified personnel only. Instruction manual C873G, C866G & C848G Please keep this instruction manual for future reference...
-
Page 16: Installation
If the hob is to be installed beneath a wall-mounted kitchen cabinet, ensure there is a minimum clearance of 760mm between the worktop and the underside of the cabinet. Instruction manual C873G, C866G & C848G Please keep this instruction manual for future reference... - Page 17 B. Cladding Dimension ‘x’ = thickness of cladding material C. Worktop D. Worktop cut-out E. Minimum distance to: Combustible materials 50mm Non-combustible materials 50mm – Dimension ‘x’ Instruction manual C873G, C866G & C848G Please keep this instruction manual for future reference...
- Page 18 › Place the hob in the unit opening and fix it with screws (V) of brackets (G) (Fig.4). F I G. 4 F I G. 5 Fig.3 Fig.4 Instruction manual C873G, C866G & C848G Please keep this instruction manual for future reference...
- Page 19 Once installation is complete, apply a soapy solution to the seal to check that it is gas tight. solution to the seal to check that it is gas tight. Instruction manual C873G, C866G & C848G Please keep this instruction manual for future reference...
-
Page 20: Electrical Connection
However, the appliance can continue to operate correctly if the power cord is connected to an uninterrupted power supply. In this case, operation is normal. Instruction manual C873G, C866G & C848G Please keep this instruction manual for future reference... - Page 21 Fig.7 tap (Fig.7) and turn the by-pass screw up to a proper F I G. 7 adjustment of the lowest flame point. Instruction manual C873G, C866G & C848G Please keep this instruction manual for future reference...
-
Page 22: Technical Specification
G30 - G31 28 - 30 / 37 1000 AUXILIARY Reg. 1000 G30 - G31 28 - 30 / 37 3800 2100 TRIPLE RING 135K Reg. 3800 2100 Instruction manual C873G, C866G & C848G Please keep this instruction manual for future reference... - Page 23 N OT E S Instruction manual C873G, C866G & C848G Please keep this instruction manual for future reference...
-
Page 24: Caple Contact Details
Caple Service Fourth Way Avonmouth T: 0117 938 1900 Bristol E: service@caple.co.uk BS11 8DW www.caple.co.uk...
