Summary of Contents for Caple C864I
-
Page 2: Dear Customer
Dear customer, Congratulations on your purchase of a Caple induction hob. In order to make the best use of your appliance, please carefully read the following use and care manual and keep it for reference. -
Page 3: Table Of Contents
SUMMARY SAFETY ............................4 ......................4 RECAUTIONS BEFORE USING ........................5 SING THE APPLIANCE ................6 RECAUTIONS NOT TO DAMAGE THE APPLIANCE ................7 RECAUTIONS IN CASE OF APPLIANCE FAILURE ........................7 THER PROTECTIONS ENVIRONMENTAL PROTECTION ....................8 CE DECLARATIONS OF CONFORMITY ..................8 WARRANTY .......................... -
Page 4: Safety
SAFETY Precautions before using • Unpack the hob and all associated components, taking care not to lose or mishandle any parts. • The appliance must be installed by a suitably qualified professional and connected to the electricity supply by a qualified electrician who will comply with the local regulations. -
Page 5: Using The Appliance
Using the appliance • Always switch cooking zones off after use. • Take particular care when cooking with oils or fats that may ignite. • Cooking pans and ustensils and the hob itself become hot during use. Caution, risk of injury to people and pets both during and after use. -
Page 6: Precautions Not To Damage The Appliance
Precautions not to damage the appliance • Use of damaged pans or those with raw cast iron bottoms may damage the hob ceramic glass. • Abrasive materials such as scouring cleaners and grits may damage the ceramic glass. • Avoid dropping objects onto the ceramic glass. •... -
Page 7: Precautions In Case Of Appliance Failure
Precautions in case of appliance failure • If a fault is noticed, switch off the appliance and turn off the electricity supply. • There are no user-serviceable parts inside the appliance. Don’t open the appliance by yourself. All repairs must be performed by a suitably qualified service engineer or similar. -
Page 8: Environmental Protection
Registration can also be completed online by visiting www.caple.co.uk. Ensure you keep your warranty card safe, you may need to show it to Caple Service together with proof of purchase. If you fail to show your warranty card you will incur all repair charges. Spare parts are only... -
Page 9: Description Of The Appliance
DESCRIPTION OF THE APPLIANCE Technical characteristics Type C864I Total power 7400 W Energy consumption for the hob EC 171.8 Wh/kg 215x215 mm Front left heating zone Minimum detection Ø 110 mm Nominal power* 1850 W Booster power* 2100 W Standardised cookware category** Energy consumption EC 170.7 Wh/kg... -
Page 10: Control Panel
Control panel Control light timer Timer display Control light Power display cooking zone Control light Control light Stop & Go on/off Power selection zone “SLIDER” Power key Stop & Go On/off key and timer setting zone USE OF THE APPLIANCE Display Display Designation... -
Page 11: Starting-Up And Appliance Management
STARTING-UP AND APPLIANCE MANAGEMENT Before Using Your New Induction Hob Clean your hob with a damp cloth, and then dry the surface thoroughly. Do not use detergent, as this risks causing blue-tinted colour on the glass surface. How Induction Works An induction coil is located under each heating zone. -
Page 12: Pan Detection
Pan detection The pan detection feature ensures safety. The induction doesn’t work: • If there is no pan on the heating zone or if the pan is not adapted to the induction. In this case, it is impossible to increase the power and the display shows [ U ]. This symbol disappears when a suitable pan is put on the heating zone. -
Page 13: Booster Function
Booster function The booster function [ P ] grants a boost of power to the selected heating zone. If this function is activated the heating zones work for 5 minutes with an ultra-high power. The booster is used for example, to rapidly heat up big quantities of water. •... -
Page 14: Automatic Cooking
• Egg timer function: Example for 29 minutes: Action Control panel Display Activate the hob Press display [ zone control lights are on Select« Timer » Press display [ CL ] [ 00 ] Set the units Slide on the “SLIDER“ to [ 9 ] [ 0 fixed ] [ 9 blinking ] Confirm the units Press display [ 09 ]... -
Page 15: Recall Function
Recall Function After switching off the hob ( ), it is possible to recall the last settings. • cooking stages of all cooking zones (power) • minutes and seconds of programmed cooking zone-related timers • Automatic cooking The recall procedure is following: •... -
Page 16: Cooking Advice
COOKING ADVICE Choosing the Right Cookware Adapted materials: steel, enamelled steel, cast iron, ferromagnetic stainless-steel, aluminium with ferromagnetic bottom. Non-adapted materials: aluminium and stainless-steel without ferromagnetic bottom, copper, brass, glass, ceramic, porcelain. Look for the induction symbol on the packaging or on the bottom of the pan. To check if pans are compatible: •... -
Page 17: Examples Of Cooking Power Settings
Examples of cooking power settings (the values below are indicative) 1 to 2 Melting Sauces, butter, chocolate, gelatine Reheating Dishes prepared beforehand 2 to 3 Simmering Rice, pudding, sugar syrup Defrosting Dried vegetables, fish, frozen products 3 to 4 Steam Vegetables, fish, meat 4 to 5 Water... - Page 18 The control panel displays [ U400 ]: • The hob is not connected to the network. Check the connection and reconnect the hob. If one of the symbols above persists, contact Caple Service. T - 0117 938 7420 E - service@caple.co.uk.
-
Page 19: Installation Instructions
INSTALLATION INSTRUCTIONS The installation comes under the exclusive responsibility of specialists. The installer is held to respect the legislation and the standards enforced in their country. How to stick the gasket: The gasket supplied with the hob avoids all infiltration of liquids in the cabinet. Installation has to be done carefully, in conformity with the following drawing. - Page 20 • The safety gap between the hob and the cooker hood placed above must respect the indications of the hood manufacturer. In case of absence of instructions, use a minimum distance of 760mm. • After installation, make sure the connection cord is not being constrained e.g. by the drawer.
-
Page 21: Electrical Connection
ELECTRICAL CONNECTION • The installation of this appliance and the connection to the electrical network should only be carried out by a qualified electrician. • When installing, make sure no part of the hob is under stress or tension. • Necessary Connection data is placed on the hob casing near the connection box. •... - Page 22 Notes:...
- Page 23 Notes:...
- Page 24 Caple Service Fourth Way Avonmouth Bristol BS11 8DW t: 0117 938 7420 e: service@caple.co.uk www.caple.co.uk 22029-1 Please keep this instruction manual for future reference...
