Rekluse EXP Assembly Inspection page 5

• A damaged tab is when the EXP tab(s) have visible
signs of damage. If there are any signs of damage,
replace the EXP bases.
d. Check that all the friction pads on both sides of the EXP
assembly are still bonded onto the bases. If any of them
are missing, replace the EXP bases.
e. Check the friction pads for glazing. Due to the dark color
of the friction pad material, the pads will appear almost
black as soon as they are put in oil.
• A normal friction pad will still have a rough finish
even though the pads are black.
Doc ID: 193-300A
Revision: 121718
Normal friction pad
5
Missing
friction pad
