6. Target Board

The C8051F41x Development Kit includes a target board with a C8051F410 device pre-installed for evaluation and
preliminary software development. Numerous input/output (I/O) connections are provided to facilitate prototyping
using the target board. Refer to Figure 2 for the locations of the various I/O connectors.
P1
J1
J3
J4
J5
J6
J7
J8
J9,
J11
J12
J13, J14 ADC external voltage reference connectors
Downloaded from Elcodis.com electronic components distributor
Power connector (accepts input from 7 to 15 VDC unregulated power adapter)
22-pin Expansion I/O connector
Port I/O Configuration Jumper Block
DEBUG connector for Debug Adapter interface
DB-9 connector for UART0 RS232 interface
Analog I/O terminal block
Connector for IDAC0 voltage circuit
USB Debug Adapter target board power connector
J10 External crystal enable connectors
Connector for IDAC1 voltage circuit
Connector block for Thermistor circuitry
J2
R21
J16
J15
J25
J15
J25
J11
J29
J17
J30
BH1
Figure 2. C8051F410 Target Board
P1.4
J6
P2.1
P2.3
J1
J3
J33
J27
J18
D12
C8051
J26
F410
J24
J23
D1
D2
J21
J32
J12
R23
J7
Rev. 0.2
C8051F41x-DK
P1.5 J5
J19
J9
J4
P1
J10
5
