INTRODUCTION

The ZEB-GO portable laser scanner provides a rapid and simple means of capturing 3D point cloud data. Data is captured as the user
walks through the area of interest. The ZEB-GO negates the need for time consuming scanner set-ups and data registration associated
with traditional terrestrial laser scanning methods.
Provided the simple guidance set out in this document are adhered to accurate 3D point clouds can be generated in a fraction of the
time taken with traditional terrestrial laser scanning methods.
1.1

SPECIFICATION

Maximum range
Points per scan line
Field of view
Scan rate
Scan range noise
Laser safety
classification
Laser wavelength
Operating conditions
Power supply
Weight
Dimensions
Battery life
© 2021GeoSLAM
Up to 30m in optimal conditions
Typical max range 15-20m
o
1080 (0.25 interval)
o o
270 x 360
40 lines/s
43,000 points/s
±30mm
CLASS I Laser Product
(21 CFR 1040.10 and 1040.11)
905nm
o o
Temperature 0 C to +50 C
Humidity <85% RH
12VDC ±10% approx. 1.5A
Scanning head 1.0kg
Carry case and contents 4.1kg
Scanning head 80x113x140mm (287mm incl handle)
Carry case and contents 470x220x180mm
Approximately 2 (4Ah) – 4 (8Ah) hours continuous use
Table 1-1: Specification
