SECURE THE SEAT TO THE
3
SEAT ADJUSTMENT POST
1. Remove the hardware from the seat (11).
2. Lay the seat on the floor, underside up.
3. Slide the seat adjustment post
underside of the seat.
4. Place a flat washer (13) onto each stud.
5. Screw a lock nut (14) onto each stud.
6. Use the multi-tool (35) to fully tighten the lock nuts.
TOOLS & HARDWARE
(35)
(13) x3
(14) x3
12 X-FlexCycle Pro User Manual Lifepro
(12) onto the three studs on the
SECURE THE BACKREST FRAME
4
TO THE SEAT POST
1. Remove the hardware from the backrest frame (16).
2. Align the two bolt holes at the top of the seat adjustment post
with the square bolt holes in the slot at the end of the backrest frame.
3. Insert two M8×50mm bolts
backrest frame and through the seat post. Ensure the square neck of
each bolt fits into the square bolt hole in the backrest frame.
4. Place a flat washer
5. Screw a lock nut
6. Use the multi-tool
head in place with one hand as you tighten the lock nut to ensure the
square neck of the bolt stays in place.
14
13
12
11
16
(8) through the square bolt holes in the
(13) onto each bolt.
(14) onto each bolt.
(35) to fully tighten the lock nuts. Hold each bolt
8 13 14
Recovery + Fitness Collection 13 Recovery + Fitness Collection 13
(12)
TOOLS & HARDWARE
(35)
(8) x2
(13) x2
(14) x2
12
