Goodnal STP ST041 Site Services (Ingersoll Rand SE Controller Basic Rotary Manual) Vendor Manual
Rotary Training Manual
Ingersoll Rand Global Service Education Team
Issue: 05/Davidson, December, 2008. ”Ingersoll Rand Proprietary Information
Q-Pulse Id VM412
GDSTP-24280-MAN-0005_P1
CP-1010-010, 020, 030
Basic Rotary Manual
Controls
SE Controller
SE Controller ............................................................. 3
Software .................................................................... 4
Current Status ........................................................... 6
SE Panel Display ...................................................... 7
Hidden Buttons ......................................................... 8
Warnings ................................................................... 9
Alarms ....................................................................... 10
Options ...................................................................... 12
Calibration Procedure ............................................... 14
UP Series Controller ................................................. 16
Short Test ................................................................. 17
Page 1
Active 29/10/2013
Page 1 of 17

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SE and is the answer not in the manual?

Questions and answers

Summary of Contents for Ingersoll-Rand SE

  • Page 1: Table Of Contents

    Goodnal STP ST041 Site Services (Ingersoll Rand SE Controller Basic Rotary Manual) Vendor Manual GDSTP-24280-MAN-0005_P1 CP-1010-010, 020, 030 Basic Rotary Manual Controls SE Controller SE Controller ............. 3 Software ..............4 Current Status ............6 SE Panel Display ............7 Hidden Buttons ............
  • Page 2 Goodnal STP ST041 Site Services (Ingersoll Rand SE Controller Basic Rotary Manual) Vendor Manual Page 2 of 17 Q-Pulse Id VM412 Active 29/10/2013...
  • Page 3: Se Controller

    Goodnal STP ST041 Site Services (Ingersoll Rand SE Controller Basic Rotary Manual) Vendor Manual Basic Rotary SE Controller SE Controls In this section, you will learn SE Controller major functions SE Basic hardware relationship SE Electrical Diagram SE Input/Outputs SE Controller...
  • Page 4: Software

    Goodnal STP ST041 Site Services (Ingersoll Rand SE Controller Basic Rotary Manual) Vendor Manual Basic Rotary SE Controls Software The term software refers to J5 115/120 Vac. J4 16Vac. J3 5Vdc. J2 5Vdc. J1 5Vdc. the program or set of...
  • Page 5 Goodnal STP ST041 Site Services (Ingersoll Rand SE Controller Basic Rotary Manual) Vendor Manual Basic Rotary SE Controls Display Select Button. This is used to scroll through the “SET” Buttons. package display select menu that will This is used to scroll through the operator set show the current status of the unit.
  • Page 6: Current Status

    Goodnal STP ST041 Site Services (Ingersoll Rand SE Controller Basic Rotary Manual) Vendor Manual Basic Rotary SE Controls Current Status beside Package Discharge Pressure will be on. PACKAGE DISCHARGE PRESSURE Display Select Operation AIREND DISCHARGE TEMPERATURE The operator can press the Display Select button and SUMP PRESSURE scroll through the following listed values.
  • Page 7 Goodnal STP ST041 Site Services (Ingersoll Rand SE Controller Basic Rotary Manual) Vendor Manual Basic Rotary SE Controls the above calculation. When the check is made, the line pressure must be above 90 PSI (6.2 bar), the unit If the Intellisys calculation is greater than 12 PSI (.8 loaded and the line pressure may only change 2 PSI bar), the warning message "Change Separator...
  • Page 8: Hidden Buttons

    Goodnal STP ST041 Site Services (Ingersoll Rand SE Controller Basic Rotary Manual) Vendor Manual Basic Rotary SE Controls General Conversion Factors Hidden Right (Factory Set Points) 1 BAR = 14.5 PSI Located between the Automatic Restart Indicator 1 KPA (Kilo Pascal) = BAR X 100 light and the Unloaded Stop button.
  • Page 9: Warnings

    Goodnal STP ST041 Site Services (Ingersoll Rand SE Controller Basic Rotary Manual) Vendor Manual Basic Rotary SE Controls SE Intellisys Warning Messages SERVICE DUE This warning occurs when an internal timer reaches In the event of a warning condition, the controller will 150 hours after startup of a new unit.
  • Page 10: Alarms

    Goodnal STP ST041 Site Services (Ingersoll Rand SE Controller Basic Rotary Manual) Vendor Manual Basic Rotary SE Controls SE Intellisys Alarm INGERSOLL-RAND Shutdowns ALARM INTELLISYS In event of an alarm condition the controller will execute an emergency stop LOW SUMP PRESSURE...
  • Page 11 Goodnal STP ST041 Site Services (Ingersoll Rand SE Controller Basic Rotary Manual) Vendor Manual Basic Rotary SE Controls a loose connection at junction J2, a broken wire in the temperature sensor 2ATT circuit or a faulty sensor. Starter Fault The Intellisys control system uses an auxiliary contact...
  • Page 12: Options

    Goodnal STP ST041 Site Services (Ingersoll Rand SE Controller Basic Rotary Manual) Vendor Manual Basic Rotary SE Controls Options Pressure Sensor Failure When the Intellisys controller receives a value from The SELECT OPTIONS set point will break down into pressure sensor 3APT indicating the sensor has failed...
  • Page 13 Goodnal STP ST041 Site Services (Ingersoll Rand SE Controller Basic Rotary Manual) Vendor Manual Basic Rotary SE Controls Auto Shutdown Power Conservation System (PCS) The arrow keys can be used to change values. Pressing SET for a second time will store and The auto shutdown incorporated as standard utilizes a automatically move down to the next set point.
  • Page 14: Calibration Procedure

    Goodnal STP ST041 Site Services (Ingersoll Rand SE Controller Basic Rotary Manual) Vendor Manual Basic Rotary SE Controls Calibration of the Pressure Transducer 3APT Pressure Transducer Input/Output Information The calibration procedure will only execute if the com- pressor is not running with mains power applied.
  • Page 15 Goodnal STP ST041 Site Services (Ingersoll Rand SE Controller Basic Rotary Manual) Vendor Manual Basic Rotary SE Controls 2 ATT Temperature Sensor Controller Chart A thermally sensitive resistor called a Thermistor installed to the airend discharge port continually monitors the temperature of the air/oil at the discharge...
  • Page 16: Up Series Controller

    Goodnal STP ST041 Site Services (Ingersoll Rand SE Controller Basic Rotary Manual) Vendor Manual only when the machine has shut-down due to low air UP Series SE Intellisys Controller demand. When demand for air returns, the machine Although the UP series compressor has a SE will restart and load automatically.
  • Page 17: Short Test

    Goodnal STP ST041 Site Services (Ingersoll Rand SE Controller Basic Rotary Manual) Vendor Manual Basic Rotary Short Test Short Test Answer each question as fully as you can, or tick the best option. When you finish, check your answers by reading through the section again.
