Original Instructions, Revision 1 August 2020
MICRO METER
i-CON
Original Operating Manual and parts list
Read carefully before installation and
operation
This document must not be copied duplicated or distributed without prior consent .
All and patent rights apply
STOCKS AG LIMITED, CROMWELL ROAD, WISBECH, CAMBRIDGESHIRE, UK.
Tel: 00 44 (0) 1945 464 909 Email: sales@stocks-ag.co.uk www.stocks-ag.co.uk
Advertisement
Table of Contents
Related Manuals for Stocks AG MICRO METER i-CON
Summary of Contents for Stocks AG MICRO METER i-CON
- Page 1 Read carefully before installation and operation This document must not be copied duplicated or distributed without prior consent . All and patent rights apply STOCKS AG LIMITED, CROMWELL ROAD, WISBECH, CAMBRIDGESHIRE, UK. Tel: 00 44 (0) 1945 464 909 Email: sales@stocks-ag.co.uk www.stocks-ag.co.uk...
-
Page 2: Table Of Contents
Index 2020 Section Page No. Index General information Technical data Intended use Unintended use Contents of the EC Declaration of Conformity Contents of the UKCA Declaration of Conformity Machine identification Warranty Safety Emergency Stop Instructions Maintenance Safety warning decals and safety signs 11-1 Clearing a blockage 11-2... -
Page 3: General Information
This Operating Manual forms part of the machine and must be readily available for the operator who must read and follow the points covered before use 3-2 Technical data Model: Micro Meter i-CON 60 litre hopper capacity; Net weight: Approx. 40kg Dimensions (W x D x H) 102 x 32 x 40 cm (Boxed;... -
Page 4: Contents Of The Ec Declaration Of Conformity
Safety of machinery – Safety distances to prevent hazard zones aaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaabeing reached by the upper and lower limbs. The manufacturer stated above holds the technical file for this machine. Signed on behalf of Stocks Ag Ltd Name: J Woolway Date:... -
Page 5: Contents Of The Ukca Declaration Of Conformity
Safety of machinery – Safety distances to prevent hazard zones aaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaabeing reached by the upper and lower limbs. The manufacturer stated above holds the technical file for this machine. Signed on behalf of Stocks Ag Ltd Name: J Woolway Date:... -
Page 6: Machine Identification
MICRO METER MK 3 MODEL 217200 SERIAL No MANUFACTURED 2021 BY:- STOCKS AG LIMITED CROMWELL ROAD WISBECH, CAMBS. PE14 OSD, UK The machine the serial number decals are mounted on the steel chassis to one side of the hopper 6-2 Warranty We provide a 12 month warranty as of the date of invoice (your invoice for the machine which will serve as a warranty certificate). -
Page 7: Safety
After working the machine ensure that any unused product is returned safely to its original packaging Stocks AG Ltd. does not accept any liability for the storage and use of the material being applied If unsure contact the material supplier for more information. -
Page 8: Emergency Stop Instructions
8 Emergency stop instructions 1. Power down the control system immediately by pressing and holding down the left-hand rubber end cap on the instrument control panel for approx. 2 seconds — then release to power off. 2. Disconnect the power supply by unplugging the power cable or removing the inline 40amp fuse. -
Page 9: Maintenance
9 Maintenance WARNING Always ensure the power supply is disconnected before any maintenance work or cleaning of this machine. Suitable protective clothing must be worn (See page 7) The machine must be checked regularly by the operator for any damage loose bolts or electrical connec- tions, vibrations, unusual sounds, and to ensure they function correctly. -
Page 10: Safety Warning Decals And Safety Signs
10 Safety Warning Decals Important ; observe this safely decals on the machine WARNING Read and understand the Operators Manual instructions before operating this machine Operator errors can result in serious injury WARNING Danger moving parts Risk of serious injury whilst the machine is in operation WARNING Risk of injury... -
Page 11: Clearing A Blockage
11-1 Clearing a blockage Disconnect the main power supply Ensure the parent machine is stationary, switched off, and parked on level ground Ensure the main power switch on the control panel is off and unplug the power supply cable or disconnecting the power cable from the vehicle battery. -
Page 12: Machine Mounting
12 Machine Mounting It is not practical to supply tailored mounting brackets for every implement on the market, and so the final attachment of the Micro Meter to the implement is the responsibility of the supplying dealer or end user. NOTE i-Con machines can be used in conjunction with two Add On units (see page 15) As Micro Meters are gravity fed machines hoses must be routed downhill with sufficient fall to allow the product to flow freely. -
Page 13: I-Con Control System
13-1 i-CON Control System All control system components integral to the applicator unit are factory fitted. The Instrument has a 4.3" Colour Touch Screen which has 4 basic menu keys (see page 16) Separate power cable and head unit leads interconnect the tractor and the Seed Applicator Unit. The following components need to be installed during fitment (packed in hopper from factory) •... -
Page 14: Machine Components
14 Machine components Feed Motor The feed motor can be turned ON or OFF, either manually via the head unit, or automatically by the remote mounted spring finger switch which can be fitted to the linkage or the implement. The feed motor must be switched ON via the head unit for the spring finger switch to work automatically. -
Page 15: I-Con Instrument Functions
15-1 i-CON Instrument functions Application Rate Forward Speed / Area and (kg/ha or Seeds/m ) and Operating Range (0-100%) % Nudge from Target Indicator Manual Pre-Start Nudge – Increase Nudge – Decrease Forward Speed or Area display Set Application Rate Metering On/Off - Function not available Metering Status... -
Page 16: Feed Shaft Speed
16-1 Feed Shaft Speed Feed shaft speed is a combination of gearbox setting and or motor speed The mechanical gearbox has 2 speeds. Two long bolts and spacers locate the motor and its mounting plate to the gearbox. To select low gear, fit these bolts in the appropriate holes through the gearbox and connect the socket to the marked low speed input shaft. -
Page 17: 17 I-Con Calibration (Page 1)
17 i-CON Calibration (Page 1 of 2) You will need a suitable container to collect the product or seed when calibrating, and an accurate set of scales which weighs in grams At the machine 1. Position a suitable container to collect seed or product from all of the feed hoses whilst calibrating 2. -
Page 18: 18 I-Con Calibration (Page 2)
18 i-CON Calibration (Page 2 of 2) 1. For a Manual Calibration Press and hold the Prime button on the junction box, the larger the quantity dispersed the higher the accuracy the final calibration factor will be, release the prime button once sufficient product has been dispensed 1. -
Page 19: Optional Add On Units
19-1 Optional Add On Unit To increase the number of outlets available Add On Units are available 1 or 2 Add On Units can be bolted to the side of the i-CON drive unit or mounted to one side and driven by the 45cm feed shaft drive extensions supplied with each Add On Unit (cut to length as required) -
Page 20: Parts Drawing
20 Micro Meter i-CON Parts drawing... -
Page 21: Parts List (Page 1)
21 Micro Meter i-CON Parts list (page 1) Item Part # Description Remarks MM002G Gearbox Complete MM150 C’ Rail 2x1m MM021 Hopper (60Ltr) MM024 Feed Drive Shaft TJ044B Metering Motor MM048 Drive Socket TJ043 ed Motor Drive Coupler MM100 Feed Cup... -
Page 22: Parts List (Page 2)
M10 Flat Washer Add On Unit only M10-024 M10 Nyloc Nut Add On Unit only Decal “Serial No. / CE UKCA Mark” not shown MD002 Decal “Stocks AG” not shown MD020 Decal “Stocks MICRO-METER” not shown MD052 Warning Decal Kit not shown MD024 Decal “Made in Britain”...
