Leedarson 8B-SS-ZF-H0 User Manual

Water leak sensor
Hide thumbs
1
2
3
4
5
6
7
8
Table of Contents

Advertisement

Quick Links

Download this manual
Content:
Water Leak Sensor ................................................................................................................................. 2
1. Product Introduction ................................................................................................................ 2
2. Product Profile ......................................................................................................................... 2
3. Specification ............................................................................................................................. 2
4. Features/Capabilities: .............................................................................................................. 4
5. Installation Notice .................................................................................................................... 4
6. Installation Guide .................................................................................................................... 5
7. Product usage ......................................................................................................................... 5
8. Note......................................................................................................................................... 6
We build your success in IoT.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 8B-SS-ZF-H0 and is the answer not in the manual?

Questions and answers

Related Manuals for Leedarson 8B-SS-ZF-H0

Summary of Contents for Leedarson 8B-SS-ZF-H0

  • Page 1: Table Of Contents

    We build your success in IoT. Content: Water Leak Sensor ..........................2 1. Product Introduction ........................ 2 2. Product Profile ......................... 2 3. Specification ..........................2 4. Features/Capabilities: ......................4 5. Installation Notice ........................4 6. Installation Guide ........................5 7.

  • Page 2: Water Leak Sensor

    User Manual 1. Product Introduction Using the LEEDARSON Water Leak Sensor and the LEEDARSON Application for your mobile device, you can receive immediate alerts if a leak or flooding occurs in your home (such as in a basement, near a water heater, under an old pipe, or in a bathroom). Early alerts can help you prevent leaks from turning into flood situation, extensive property damage and excessive bills.

  • Page 3: Specification

    Buzzer sound hole Specification Model Name 8B-SS-ZF-H0 Power Supply Battery Power Source 3V, AAA *2 Battery Life 5 years Communication Protocol Zigbee 3.0 Radio Frequency 2.4GHz Wireless Range 100ft (40m)LOS Operational Temperature 0℃ - 40℃ Operating Humidity Up to 85% non-condensing...

  • Page 4: Features/Capabilities

     The LEEDARSON Water Leak Sensor is a Zigbee compatible sensor.  The LEEDARSON Water Leak Sensor is powered by AAA battery with a 5-years battery life.  The LEEDARSON Water Leak “alarm” can be sent to Zigbee network devices or to any compatible alarm system hub.

  • Page 5: Installation Guide

    1. The sensor will be in pairing status when power turns on for the first time. This will cause an LED indicator light to flash once per second for 3 minutes. Use the LEEDARSON Application to search for this device If sensor pairs successfully, the light will stop blinking and then stay on for about 10 seconds.

  • Page 6: Note

    4. Once the sensor detects a water leak, the LED Indicator flashes and the alarm beeps once per second. The alarm signal will be sent to the gateway once every 5 minutes. During the alarm status, the user can mute the buzzer by using the App. If the sensor still detects a water leak after 10 minutes, the detector will trigger the alarm again and another signal will be sent to the gateway and the user.
  • Page 7 Attention RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT TYPE. DISPOSE OF USED BATTERIES ACCORDING TO THE INSTRUCTIONS This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference. (2) This device must accept any interference received, including interference that may cause undesired operation.
  • Page 8 —Increase the separation between the equipment and receiver. —Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. —Consult the dealer or an experienced radio/TV technician for help. IC NOTICE TO CANADIAN USERS Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence.
