CASE FOR RD6012
JT-RD6012-Case1
1. GENERAL INFORMATION
Dear customer,
Thank you for purchasing our product. In the following, we will show you
which things should be noted during the use.
Should you encounter any unexpected problems, do not hesitate to
contact us.
This case is made for an additional power supply which allows
you to connect this lab power supply directly to alternating
current.
Therefore, this safety instruction is necessary:
!
For your own safety, this product may only be
installed by a qualified electrician! Working on
electric devices / systems implies the hazard of
electric shocks which may cause serious injuries or
even death!
www.joy-it.net
Pascalstr. 8 47506 Neukirchen-Vluyn
Advertisement
Table of Contents
Related Manuals for Joy-it JT-RD6012-Case1
Summary of Contents for Joy-it JT-RD6012-Case1
- Page 1 CASE FOR RD6012 JT-RD6012-Case1 1. GENERAL INFORMATION Dear customer, Thank you for purchasing our product. In the following, we will show you which things should be noted during the use. Should you encounter any unexpected problems, do not hesitate to contact us.
- Page 2 Now you can attach the extension of the temperature sensor to get the temperature sensor outside of the case. You can also mount without these if required, which allows you to use an internal instead of an external temperature sensor. www.joy-it.net Pascalstr. 8 47506 Neukirchen-Vluyn...
- Page 3 If available, insert the WiFi module in the RD6012. Now insert the RD6012 into the case. Place the power supply unit into the case as shown in the picture and screw it on from below. www.joy-it.net Pascalstr. 8 47506 Neukirchen-Vluyn...
- Page 4 (neutral conductor) and is connec- ted to N. The other connector of the switch is connected with the long brown cable to the connector marked as L on the power supply unit. www.joy-it.net Pascalstr. 8 47506 Neukirchen-Vluyn...
- Page 5 This means that if you have an input voltage of 90 to 132 V AC, slide the switch to 115 V (left) and if you have an input voltage of 180 to 264 V AC, slide the switch to 230 V (right). www.joy-it.net Pascalstr. 8 47506 Neukirchen-Vluyn...
- Page 6 Finally, either connect the cable for the external temperature sensor and the temperature sensor from the outside at the extension, or you can connect the temperature sensor directly to the RD6012 so that it is inside the case. www.joy-it.net Pascalstr. 8 47506 Neukirchen-Vluyn...
- Page 7 Now fix the cover with the eight screws and your RD6012 is ready to use. www.joy-it.net Pascalstr. 8 47506 Neukirchen-Vluyn...
- Page 8 We will send you a parcel stamp with which you can send us your old appliance free of charge. For this possibility, please contact us via e-mail at service@joy-it.net or via telephone. Information about Package: Please package your old appliance safe for transport. Should you not...
