Introduction - Quectel FC21 Hardware Design

1

Introduction

This document defines the FC21 module and describes its air interface and hardware interfaces which
are connected to the customers' applications.
The document can help customers quickly understand module interface specifications, electrical and
mechanical details, as well as other related information of the module. In combination with Quectel
1)
EC2x&EG2X-G modules, FC21 module can help customers to design and set up LTE+Wi-Fi/BT
applications easily.
Table 1: FC21 Module
Module Wi-Fi
FC21 2.4GHz and 5GHz
NOTE
1)
In this document, EC2x refers to Quectel EC25, EC21 and EC20 R2.1 modules and EG2x-G refers to
Quectel EG21-G and EG25-G modules.
FC21_Hardware_Design
Wi-Fi&BT Module Series
FC21 Hardware Design
BT
BT 4.2
