BodyGuard 545 and BodyGuard 575
The BodyGuard 545 and 575 pumps have adjustable operating parameters. These
operating parameters and options may be viewed and adjusted to modify the
operation of the pump. The operating parameters and options available for the
BodyGuard 545, and 575 are described in the Technician Menu, Level 1 Menu and
Keypad Lock.
Technician Menu
To access the Technician Menu, press and hold the INFO key during the power on
operation until 'Technician Code' prompt appears. The display will show the software
version for 2 seconds before the access code prompt. Enter Technician Code to access
the menu.
The pump will display all the parameters that can be set, calibrated or tested. The
technician can scroll through all parameters using the ARROW keys (2 & 0 keys on
the pump).
Item Parameter
Restart Pump
1
Serial Number
2
Manual Calibration
3
Main Self-Test
4
Volume Test
5
Manual Test
6
Pressure Calibration
7
8 Volume Calibration
Software default
9
Setting
Reset Calibrations
10
Operating hours
11
Access Codes
12
Description
Exit Technician Mode.
Displays serial number & production date.
Summary of volume & pressure calibrations and ability to check/re-
enter software default calibrations after service.
Performs keypad, display, alarm sound, door sensor, air sensor,
temperature, motor & encoder, and pressure sensor tests.
Program rate & volume to be delivered during flow rate test.
Same as Main Self-Test but with a menu so technician can focus on
individual tests.
Allows manual calibration of pressure settings.
Allows manual calibration of pumping mechanism.
Caution: pressing START/OK will restore software default defaults
and delete all pre-set protocols and set-up changes.
Caution: pressing START/OK restores default settings. Pump must
be re-calibrated after reseting calibrations.
Hours from last service – reset to zero by pressing STOP/NO key.
Displays current access codes and allows change.
