Inserting the air filter and HEPA filter
Note
Remove any packing material from the HEPA filter. To
change the filter, proceed as described in the
Maintenance chapter under Cleaning and replacing the
HEPA filter.
Note
Do not operate the device without an air filter inserted
into the air inlet!
Without the air filter, the inside of the device will be
heavily contaminated. This could reduce the
performance and result in damage to the device.
• Before switching the device on, make sure that the air
filter and HEPA filter are installed.
Inserting the condensation tank
• Ensure that the float inside the condensation tank is
inserted correctly.
• Ensure that the condensation tank is empty and inserted
correctly.
Connecting the power cable
• Insert the mains plug into a properly secured mains
socket.

Operation

• Avoid open doors and windows.
• After being switched on, the device operates fully
automatically.
• The fan permanently runs in dehumidification mode even
after the set nominal value has been reached until the
device is switched off.
8
Operating elements
12 13 14
32 31 30
No. Designation
2 Colour LED display
for room humidity
12 Child Lock button
13 Child Lock LED
14 Humidity button
15 %/relative
humidity LED
16
LED
17
LED
18
LED
19
LED
20 Mode button
21 On/Off LED
dehumidifier TTK 99 HEPA
15 16 17 18 19
%
29 28 27 26
25 24 23
Function
Indicates the current relative room
humidity by means of 3 different
colours
Switching the locking function on or
off
Illuminated when child lock function
is activated
For setting the desired relative
humidity level
Illuminated when the relative
humidity level is set or the current
humidity level is displayed
Illuminated when the
dehumidification mode is selected
Illuminated when the continuous
operation mode is selected
Illuminated if the laundry drying
function mode is selected
Illuminated when the ventilation
mode is selected
For setting the operating mode
Illuminated when the device is
switched on
2
20
21
22
